  • Page 1 SCAN FOR A DIGITAL GUIDE OWNER’S MANUAL 25-01A...
  • Page 2 NOTES • Always handle the bulb when it is cool. Avoid touching the base of the LED bulb while it is on, as it can get very hot during operation. Take care to prevent burns or injury. • Do not apply excessive pressure to the light-emitting part of the bulb.
  • Page 3 STEP 2 Install the bulbs into the assembly. For most bulb types, use the same install steps as replacing the stock bulbs. For H3 bulbs, the collar on the LED bulb needs to be removed before installation. First, place the collar into the socket then put the factory metal clip or plastic retainer ring to place.
  • Page 4 STEP 3 Check to make sure the position of the diodes (LED chips) are in a horizontal side to side orientation. (See bulb orientation instructions). Note: If the bulb is tilted at an angle when installed on your vehicle, correct it by adjusting the bulb head.
  • Page 5 STEP 5 OPTIONAL: If you ordered additional Decoder Harnesses to correct power signals on certain vehicles, plug the Decoder Harness in to the factory socket first, then connect the LED bulb to the Decoder Harness module. (See Decoder Harness instructions for detailed steps). STEP 6 Route and secure all wiring.
  • Page 6 ORIENTATION Check to make sure the position of the diodes (LED chips) are in a horizontal side-to-side orientation. NOTE: Dual filament bulbs have two sets of LED chips. Ensure the chip alignment matches the illustration below. H13/H4/9004/9007 LOW BEAM HIGH BEAM...
  • Page 7 ADJUSTMENT Note: H15, H11B, H1, H4, and H7 bulbs do not have rapid aim. 1. Insert the bulb into the original car lamp assembly. Lock the bulb in position. 2. Check the angle of the LED chips to determine the direction and angle adjustment required.

  • Page 8: Troubleshooting

    TROUBLESHOOTING 1. Lights do not turn on: If the bulb does not light up, disconnect the electrical connector and reverse it 180°, then reinstall. 2. Incorrect beam pattern: If the beam pattern does not appear correct, or is skewed, carefully inspect the mounting and position of the bulb in the assembly.
  • Page 9 FMVSS1081 and are therefore not street legal in the USA for use as headlights. ARC Lighting LED bulbs are legal for off road use as headlights on Snowmobiles, ATVs, construction equipment and off road racing and enthusiast vehicles. International street legality will vary by country.
  • Page 10 DOT COMPLIANCE ACKNOWLEDGMENT Please check your usage on the chart below and confirm that you will not use the bulbs for illegal street usage: DOT / FMVSS1081 USAGE STREET LEGAL SALABLE REGULATED ✖ ✔ ✔ FOG LIGHTS Any vehicle STREET DRIVEN ✔...

  • Page 11: Warranty

    ARC Lighting to repair or replace the defective part. All repairs must be made under the direction of ARC Lighting. ARC Lighting is not responsible for any removal, installation, reinstallation, or transportation costs associated with the warranted claim.
  • Page 12 Thank you for purchasing ARC Lighting products. Please read this instruction manual thoroughly for proper use of the product. After completing your installation, keep this manual for future reference. For more product information and resources please visit www.arc.lighting/user-guide INCLUDES: 2X LED...
