Installing your printer onto your conveyor can seem like a daunting task. However, with the correct tools
it is very easy. Follow the steps and watch the video linked below and you will be done in no time!
1) Remove the T clamp from your printer kit and use it to mark the holes making sure it is level.
2) Use your center punch directly in the center of your marked holes. This helps prevent the drill
bit from roaming and coming off center.
3) Place a large drop of cutting oil onto the marked holes.
4) Begin drilling your holes, starting the drill slowly and increasing speed gradually.
5) Attach your printer mount (T bracket) in the holes using the two large screws in the hardware
set.

Video Instructions:

Fine tuning your printer

After you have finished installing your T6 Automatic you will need to dial in your print. Please watch the
video (T6 printer introduction) before moving forward to help familiarize yourself with the menus.

DPI

The first step to dialing in your printer is to select your preferred DPI setting, The printer will allow you
to choose 75, 150, 200, and 300 dpi. The higher the DPI value is the darker and crisper your prints will
appear.
TIP: changing DPI values after you have fine-tuned your printer will affect your settings and you will
need to re-tune your printer.

The Product Sensor

The first step to dialing in your printer to make sure that your product sensor is pointed and triggering
accurately.
TIP: A small move of the product sensor will influence the fine tuning of your printer. Be sure to install it
firmly in place as to avoid movement.
Video Instructions: setting up the photo eye

Speed And Interval (delay)

When we use the phrase "fine tune" we are referring to setting your speed and interval (delay) setting
to meet your requirements for print position. Unlike the T6 handheld the T6 automatic does not feature
an encoder wheel so we need to manually set these. Begin by setting your Interval and adjust your
speed setting after.
Installing your Titan T6 Automatic onto a conveyor
Installing your Titan T6 Automatic onto a printer stand
