PRECILUM TRILOBIT 300 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TRILOBIT
ON/OFF or DALI
Lenght = 300/600/900/1200
INSTRUCTIONS MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRILOBIT 300 and is the answer not in the manual?

Questions and answers

Related Manuals for PRECILUM TRILOBIT 300

Summary of Contents for PRECILUM TRILOBIT 300

  • Page 1 TRILOBIT ON/OFF or DALI Lenght = 300/600/900/1200 INSTRUCTIONS MANUAL...

  • Page 2: Table Of Contents

    2. SAFETY AND OPERATION 3. INSTALLATION 4. CONNECTION DIAGRAMS 5. CARE AND MAINTENANCE 6. TECHNICAL SPECIFICATION 7. WARRANTY STATEMENT Electrostatic Sensitive Device (EDS) FOR YOUR OWN SAFETY PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE BEGINNING SETUP AND INSTALLATION. TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...

  • Page 3: Introduction

    It made using highest quality materials and construction methods, bringing the flexibility to outdoor application. This powerful lighting fixture is ideally suited to use in landscape and building illumination and IP66 ensures safe operation in even the most demanding areas. TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 4 1. INTRODUCTION 1.2 Dimensions of fixture Lenght = 300 mm Lenght = 600 mm Lenght = 900 mm Lenght = 1200 mm 1200 1200 TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 5 1. INTRODUCTION 1.3 Dimensions of hanging bracket 1.3.1 Fixed bracket Bracket 40 mm: Wall mounted part: Bracket 25 mm: 113,5 1.3.2 Adjustable bracket Bracket 200 - 300 mm: Wall mounted part: TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 6 1. INTRODUCTION 1.3.3 Fixation methods Bracket 25 mm: Bracket 40 mm: Bracket 200 - 300 mm: TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...

  • Page 7: Safety And Operation

    The light fixture must be wired according to respective electrical ● standards. The manufacturer shall not be liable for any modifications of the ● product of incorrect installation of the product. Never install the luminaire on rain, fog or high humidity. ● TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...

  • Page 8: Installation

    Mount the hanging bracket according Fig.1. Use dowels and screws. ● (Fig. 1) First screw the top of the bracket, then turn the luminaire and fix the ● other side. (Fig. 2) Make sure it is mounted firmly and precicely. ● TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 9 Fasten the cable coming out from the luminaire to the bracket using ● cable-ties in such a way that it does not touch the wall. By this way water will not be leaking on the wall. (Fig. 4) TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 10 3.2.2 Wiring - DALI option – cable output in the middle DALI DALI Wire L (Live) – brown (black) Wire N (Neutral) – blue Wire PE (Earth) – yellow/green Wire DA1 (Dali) – white Wire DA2 (Dali) - white TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 11 3. INSTALLATION 3.2 Connection 3.2.1 Wiring - ON/OFF option – cable output in the middle Wire L (Live) – brown (black) Wire N (Neutral) – blue Wire PE (Earth) – yellow/green TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 12 FEMALE (OUT) - Front view MALE (IN) - Rear view (soldering) FEMALE (OUT) - Rear view (soldering) Wire L (Live) – brown (black) Wire L (Live) – black Wire N (Neutral) – blue Wire PE (Earth) – yellow/green TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 13 FEMALE (OUT) - Rear view (soldering) Wire L (Live) – brown (black) Wire L (Live) – black Wire N (Neutral) – blue Wire PE (Earth) – yellow/green Wire DA1 (Dali) – white Wire DA2 (Dali) – white TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 14 3. INSTALLATION 3.3 IP connection - cable output in the middle PRECILUM requirement: Use a SCAME IP box or similar (not included). Must be made a waterproof connection of at least IP68. We strongly recommend to use special two components silicone GEL for sealing junction boxes containing electrical connections.
  • Page 15 3. INSTALLATION 3.3 IP connection - cable output in the middle PRECILUM recommendation: Use a TECHNO® IP circular junction connector (TeeTube®) or TECHNO® IP juction box (TeeBox®). Not included! TeeTube® TeeBox® 3 poles (ON/OFF) TeeTube® (THR.390.S3T): ● https://www.techno.it/en/products/all/thr-390-s3t/ 5 poles (DALI) TeeTube® (THB.402.C1F.R): ●...

  • Page 16: Connection Diagrams

    Max. QTY – issue to be End connector specified by electr. designer Description Type of cable: - Luminaire ON/OFF – 3 x 1,5 mm (230V) DALI - 5 x 1,5 mm (230V + DALI) - Connector TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...

  • Page 17: Care And Maintenance

    5. CARE AND MAINTENANCE PRECILUM™ PRODUCTS ARE OF SUPERIOR DESIGN AND QUALITY AND SHOULD BE TREATED WITH CARE. THE RECOMMENDATIONS BELOW WILL HELP FULFILL GAIN GOOD USE AND LONGEVITY FROM THE PRODUCTS. Clean the front transparent cover at least every 6 months. Use a moist, lint-free cloth.

  • Page 18: Technical Specification

    -30°C/+45°C Materials: Housing: extruded aluminium Cover: clear tempered glass Dimensions: See dimensional drawing Enviroment: IP66 Weight: TRILOBIT 300: 0,8 kg TRILOBIT 600: 1,9 kg TRILOBIT 900: 3,0 kg TRILOBIT 1200: 3,9 kg Accesories: See website TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...

  • Page 19: Warranty Statement

    7. WARRANTY STATEMENT Precilum provides a product warranty for a period of five (5) years from date of purchase. Please refer www.precillum.com for all warranty terms and conditions. TRILOBIT INSTRUCTIONS MANUAL v1.1 WWW.PRECILUM.COM...
  • Page 20 Please check for latest updates and changes on the Precilum website. ©2021 PRECILUM s.r.o ALL RIGHT RESERVED. All specifications subject to change without notice. WWW.PRECILUM.COM...

This manual is also suitable for:

Trilobit 600Trilobit 900Trilobit 1200
