Summary of Contents for PRECILUM INGROUND 3 WHITE
- Page 1 INGROUND 3 INGROUND 6 INGROUND 9 WHITE ON/OFF Square Round INSTRUCTIONS MANUAL...
-
Page 2: Table Of Contents
5. CARE AND MAINTENANCE 6. TECHNICAL SPECIFICATION 7. WARRANTY STATEMENT Electrostatic Sensitive Device (EDS) FOR YOUR OWN SAFETY PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE BEGINNING SETUP AND INSTALLATION. INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1... -
Page 3: Introduction
1. INTRODUCTION 1.1 About the product The PRECILUM Inground range brings the INGROUND to the outdoor world of exterior lighting. With IP67 rating and drive over capability these Inground fixtures are capable of meeting most exterior applications. The refined thermal management system incorporates a sleek and robust heat-sink directly into the fixture to ensure maximum heat transfer and long life-time. - Page 4 SQUARE SHAPE 100x100 ROUND SHAPE Ø100 Ø91 Ø75 Inground 6 SQUARE SHAPE 130x130 ROUND SHAPE Ø130 Ø116 Ø96 Inground 9 SQUARE SHAPE 150x150 ROUND SHAPE Ø150 Ø142 Ø114 INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1...
-
Page 5: Safety And Operation
The manufacturer shall not be liable for any modifications of the ● product of incorrect installation of the product. Never install the luminaire on rain, fog or high humidity. ● INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1... -
Page 6: Installation
30 min. If it doesn’t work study a further drainage system. Aluminum sleeve must be installed on drainage layers, surrounding ● concrete layers and leveled with external finish. INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1... - Page 7 Fig. 3 Fig. 3 ALLOWED Edges of the plastic ● sleeve must not be installed under the surrounding floor. INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1...
-
Page 8: Fig. 4
IP juction (more about IP connection in 3.3 IP BOX connection). Put the luminaire into the ● plastic sleeve. INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1... - Page 9 Fig. 9 Tighten the screws Put on and tighten the ● screws which you removed in step 4 (Fig.4). Check if the screws are ● tight properly! INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1...
-
Page 10: Not Allowed
3. INSTALLATION ALLOWED MAX. 500kg ALLOWED ALLOWED INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1... - Page 11 3. INSTALLATION 3.2 Connection 3.2.1 Wiring - ON/OFF option Wire L (Live) – black/brown Wire N (Neutral) – blue Wire PE (Earth) – yellow/green INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1...
- Page 12 3. INSTALLATION 3.3 IP BOX connection PRECILUM requirement: Use a SCAME IP box or similar (not included). Must be made a waterproof connection of at least IP68. We strongly recommend to use special two components silicone GEL for sealing junction boxes containing electrical connections. If the IP rating of the...
-
Page 13: Connection Diagrams
4. CONNECTION DIAGRAMS 4.1 ON/OFF option 230V 3 x 1,5 mm* Description: *Must be specified by the electrical designer. - Luminaire - IP Junction box INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1... -
Page 14: Care And Maintenance
5. CARE AND MAINTENANCE PRECILUM™ PRODUCTS ARE OF SUPERIOR DESIGN AND QUALITY AND SHOULD BE TREATED WITH CARE. THE RECOMMENDATIONS BELOW WILL HELP FULFILL GAIN GOOD USE AND LONGEVITY FROM THE PRODUCTS. Clean the front transparent cover at least every 6 months. Use a moist, lint-free cloth. -
Page 15: Technical Specification
Cover: clear hardened glass+ stain. steel face ring Dimensions: See dimensional drawing Enviroment: IP67 Weight: INGROUND 3 WHITE: 0,7 kg INGROUND 6 WHITE: 0,8 kg INGROUND 9 WHITE: 1,5 kg Accesories: See website INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM... -
Page 16: Warranty Statement
7. WARRANTY STATEMENT Precilum provides a product warranty for a period of five (5) years from date of purchase. Please refer www.precillum.com for all warranty terms and conditions. INGROUND 3 + INGROUND 6 + INGROUND 9 WHITE WWW.PRECILUM.COM INSTRUCTIONS MANUAL v1.1... - Page 20 Please check for latest updates and changes on the Precilum website. ©2021 PRECILUM s.r.o ALL RIGHT RESERVED. All specifications subject to change without notice. WWW.PRECILUM.COM...
