- Page 1 Motorized Home Storage Solution Model 1400/1600 COPYRIGHT © Dec, 2019 WARNING: NO PORTON OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL PART NUMBER OF MANUAL 2101A, PRINTED IN USA Motorized Home Storage Solution Model 1400/1600...
- Page 2 The manufacturer will not be held liable for injury or property damage from negligence, improper training, equipment modifications or misuse. Motorized Home Storage Solution Model 1400/1600...
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION_______________________________________________ Foreword____________________________________________________ Contact Info__________________________________________________ 4 Data Sheet___________________________________________________ Identification_________________________________________________ Section 1: Safety______________________________________________ Safety instructions _____________________________________________ Section 2: Circuit requirements___________________________________ Additional advice______________________________________________ How to use the lift _____________________________________________ Daily inspection instructions______________________________________ Warranty_____________________________________________________ Motorized Home Storage Solution Model 1400/1600... -
Page 4: Introduction
The specifications, drawings and photographs illustrated in this manual represent auXXLift the Model 1400/1600 when the manual was prepared. However, owing to policy of continuous improvement, changes may be made at any time with no obligation on the part of LFK Engineering LLC. -
Page 5: Data Sheet
Transmitter…………………………………………….……………………………………………..433.92MHz Receiver Load per channel……………………………………………………………………………..…1HP Cord Length…………………………………………………………………….………………………..…….10 ft. Cord Gauge………………………………….……………………………………………………………16 gauge Minimum circuit size……………………………………………………………………………………15 amp Plug included……………………………………………………………………………..………….NEMA 5-15 Conversion To 220V or 440V………………………………………………………………………….…..No Motors: Type……………………………………………………………………………….………………….IP44, T-Motor Rated Power……………………………………………………………………..………………235W/(680W) Rated Current………………………………………………………………………….………………2.2A/(6A) Voltage……………………………………………………………..………………………………………..…..120V Phase…………………………………………………………………………………………………….……….Single Max RunningTime………………..………………………………………......…………….3min Motorized Home Storage Solution Model 1400/1600... -
Page 6: Identification
Identification A. Montage Rail F. Platform B. Motor Brackets G. Rope Bender C. Rope Holder H. Rope Clip D. Steel Rope I. Motor E. Frame J. Shelf Support Beam Motorized Home Storage Solution Model 1400/1600... -
Page 7: Section 1: Safety
COULD result in death or serious injury. Indicates a potentially hazardous situation Caution which, if not avoided, MAY result in minor or moderate injury. It may also be used to alert against unsafe practices. Motorized Home Storage Solution Model 1400/1600... -
Page 8: Safety Instructions
5. KEEP AREA OF WORK CLEAN AND 11. MAKE AREA WORK, CHILD AND WELL LIT. Cutter VISITOR PROOF. Move around/over/under Remote control (Transmitter) to a Equipment and dark shadows save place. may cause accidents. Motorized Home Storage Solution Model 1400/1600... - Page 9 No list of safety guidelines can be complete. Every environment is different. Like all machines there is danger associated with the Model 1400/1600. Accidents are frequently caused by lack of familiarity or failure to pay attention. Use this machine with respect and caution to lessen the possibility of operator injury.
-
Page 10: Section 2: Circuit Requirements
• For help qualified qualified electrician. electrician. Circuit Breaker……………………..…….15A Motorized Home Storage Solution Model 1400/1600... - Page 11 Watch for children and pets while operating the Motorized Home Storage System. Read the safety labels on the System. If you have any type of problems do not hesitate to call for help. auXXLifthelp@gmail.com Motorized Home Storage Solution Model 1400/1600...
-
Page 12: Additional Advice
ADDITIONAL ADVICE Keep these safety precautions in mind! Keep these safety precautions in mind! Keep these safety precautions in mind! Never operate the lift while objects or people are near moving parts. Motorized Home Storage Solution Model 1400/1600... - Page 13 Serious injury could happen to you and other people. Watch around the shelf for clearance and don’t stack too high. Between stack end and Ceiling Rail there must be a gap bigger than 2 inches. Motorized Home Storage Solution Model 1400/1600...
- Page 14 When you are unsure please use a scale. For the 1600 Version is the max load 600lbs 1800=800lbs A000=1000lbs Even out the weight of your items. When you are unsure please use a scale. Motorized Home Storage Solution Model 1400/1600...
-
Page 15: How To Use The Lift
To lower the platform, press 3 on the remote and relieve the key desired height of the lift is reached. To stop the lift at any time because of problems or the desired height is reached relieve the button on the remote. Motorized Home Storage Solution Model 1400/1600... -
Page 16: Daily Inspection Instructions
7. Please check if the cables are overlapped. If so lower the lift all the way to the ground and raise it back up. The cables should be not overlapped anymore. If problem consists please call customer service. Motorized Home Storage Solution Model 1400/1600... -
Page 17: Warranty
Damages to the product, property or persons resulting from improper use (overloading), installation errors or buyer negligence are not covered by this warranty. Motorized Home Storage Solution Model 1400/1600...
