- Page 1 Cw60 AutomAtiC tempering mAChine use And mAintenAnCe mAnuAl Lange Elzenstraat 123 • 2018 Antwerpen • Belgium • Tel. +32 (0)3 216 44 27 Fax +32 (0)3 216 98 33 • www.chocolateworld.be • info@chocolateworld.be...
-
Page 2: Certificate Of Conformity
CertifiCate of Conformity Certificate of conformity according to eu standards Continuous CyCle tempering mAChine We, Chocolate World NV, Lange Elzenstraat 123, 2018 Antwerp, Belgium, hereby declare that the mentioned product: Cw60 type: serial nr year of construction: date: Qualifies for the following guidelines: •... -
Page 3: Conditions Of Warranty
The CW60 is a continuous cycle tempering machine used for processing chocolate. The tempering machine is composed out of a tank with a capacity of 40 kg, where the chocolate is melted by electrical heating systems. A screw of Archimedes (circulation pump), made out of... - Page 4 numbers And nAmes mAChine pArts Control panel Vibrating motor Chocolate dosing spout Main Switch Rotating arm Cooling unit Slider Vibrating table Stainless steel tank Scraper Housing Vibrating mat Wheels Vibrating spring Dosing pedal Electrical connection vibrating table + heating Keyhole Plexiglass lid Emergency stop...
- Page 5 numbers And nAmes mAChine pArts Coolant reservoir Motor + gearbox Water cooling motor pump Sensor for tempering temperature Print plate Sensor for heating regulator Warming of heating regulator Valve Condenser...
- Page 6 numbers And nAmes mAChine pArts Heating area Tank cooling water Cooling pump Cooling water tap Rotating arm motor Sensor cooling tank Condenser Ventilator Compressor...
- Page 7 power And print plAte ConneCtions Exit 220 Volts (vibrating table) Transformer 220V - 24V Heating chocolate pump Secondary connection Cooling water pump transformer 24V Heating melting tank Auxiliary exit 24V Refrigerator system Heating spout Chocolate pump Interrupter pedal Rotating arm Communication cable Primary connection transformer 220V Safety contact...
-
Page 8: Technical Characteristics
teChniCAl ChArACteristiCs • Tank capacity: 60 kg of chocolate • Hourly production: up to 200 Kg • Standard dosing function • Power required Kw 3.5 (3 phase) Microprocessor technology • featuring digital temperature display Dosing pedal • • Heated vibrating table frontpAnel Tank temperature indication display Chocolate temperature indication display (tempered chocolate) -
Page 9: Installation
instAllAtion • Remove all packaging from the machine and remove the vibrating table (14) from the back of the machine. Take off the plexiglass lid (19) and make sure nothing prevents the arm from rotating. • Clean the machine as described on p.11 •... - Page 10 Cw60 tempering mAChine For correct use of the machine, respect following instructions: The machine is not made for chocolate mixed with an additional product. Color powder is not a problem. Remark: nuts, beans etc, will collect in one way and the pump will block complete.
- Page 11 switching off the machine after daily production: • Press button G to switch off the tempering function. • Wait a couple of minutes, and allow the temperature seen on display B to become equal to the tempera- ture seen on display A. Then switch off the pump (F) followed by the rotating arm (D). •...
- Page 12 mAintenAnCe And CleAning of the tempering mAChine To clean the exterior of the machine first use a cloth soaked in warm water to remove excess chocolate. To polish the machine use a soft cotton cloth drained in an alcoholsolution. Do not use any kind of aggressive soaps or abrasives (PH7: neutral value). The interior of the tank can be cleaned with a dry clean cotton towel.
- Page 13 piCtogrAms Warning symbols have been placed on the machine. The first symbol can be found above the melting tank and warns for potential danger of the rotating arm. The other symbols are the leds situated on the control panel and warn for parts in movement and in function. disposAl And destruCtion The coolant liquid needs to be disposed according to the local law and legislation.
- Page 14 dosing heAd Dosing head Sieve Dosing plate 3x8 Dosing plate 3x7 Heating sticks Screws vibrAting tAble: spAre pArts Scraper Sliders...
