FABRIC BUILDING INSTRUCTIONS
MODEL: SH-RO46
L4 x W6.1 x H 3.55
PICTURE MAY NOT REFLECT THE EXACT MODEL
TO OUR NEW AND VALUED CUSTOMER
Thank you for purchasing your new Instant Shelter. We know you will have as much plea-
sure owning your new shelter as we had in making it for you. Our shelters have been
designed for rapid assembly and minimal maintenance. We have rigorous quality control
at every step of the shelters manufacturing process to insure you the best unit money can
buy. Our parts are triple checked prior to packaging to insure you will have everything you
need before you start. In the unlikely event that a part is damaged or missing,you should
immediately contact your place of purchase for a speedy replacement.
Advertisement
Related Manuals for Shelldome SH-RO46
Summary of Contents for Shelldome SH-RO46
- Page 1 Covering Your World FABRIC BUILDING INSTRUCTIONS MODEL: SH-RO46 L4 x W6.1 x H 3.55 PICTURE MAY NOT REFLECT THE EXACT MODEL TO OUR NEW AND VALUED CUSTOMER Thank you for purchasing your new Instant Shelter. We know you will have as much plea- sure owning your new shelter as we had in making it for you. Our shelters have been designed for rapid assembly and minimal maintenance. We have rigorous quality control at every step of the shelters manufacturing process to insure you the best unit money can buy. Our parts are triple checked prior to packaging to insure you will have everything you need before you start. In the unlikely event that a part is damaged or missing,you should immediately contact your place of purchase for a speedy replacement.
-
Page 2: About Safety
Covering Your World About Safety HEAD PROTECTION IS RECOMMENDED! Working with or under heavy parts included with this shelter can cause serious head injury. WEAR GLOVES You will be working with metal parts which may have SHARP edges CHECK WITH YOUR LOCAL AUTHORITIES Underground POWER CABLES or GAS LINES may result in injury while securing the shelter. It may also result in having to move the building. A cursory check with the local building authorities will help alleviate these concerns. CLIMBING EQUIPMENT It is highly recommended that scaffolding, ladders and mechanical lifting equipment conform to all local building codes when erecting the shelter. Safety straps and harnesses should be used at all times. The metal structure of the shelter has not been designed for human weight. Erecting shelter during wind or rain is unsafe and could result in serious injury. CHECK LOCAL WEATHER CONDITIONS Check your local weather forecast prior to planning your building day. Wind, snow and/or rain may cause unsafe conditions that could lead to serious injury. STORING HAZARDOUS MATERIALS Check all local building codes prior to storing any hazardous material. Shelter may require additional ventila- tion to meet local codes. SEVERE WEATHER CONDITIONS Working in and around the portable shelter during severe weather is not recommended. Serious injury ... - Page 3 Covering Your World SHELTER RELOCATION Should the shelter require relocation or disassembly for any reason, it is strongly recom- mended that the structure and its cover are thoroughly inspected prior to rebuilding. PERIODIC SHELTER INSPECTION As with all structures, periodic inspection of the cover and all structural-components is highly recommended. Tightening the cover and the structure will prolong the life of your investment. Safety PLEASE BE CONSCIOUS! Common Sense is the knack of seeing things as they are, and doing things as they ought to be done. THANK YOU FOR CHOOSING OUR SHELTER UNPACKING & IDENTIFYING PARTS Prior to assembling your New Portable Shelter, unpack all crates and complete an inven- tory of all parts according to the following list and diagrams...
- Page 4 Covering Your World PARTS LIST FOR SH-RO46 Dimensions Diagram Q'TY Parts# Descriptions ( in mm ) Φ 45x1550 Top roof arched rafter(left) Φ 45x1550 Roof arched rafter Φ Roof arched rafter(lower end) 45x1550 Φ 45x1140 Side upper curved rafter Φ...
- Page 5 Covering Your World PARTS LIST FOR SH-RO46 Dimensions Descriptions Diagram Q'TY Parts# ( in mm ) Cover conduit Φ28x1020 Φ28x1020 Cover conduit Zipper tool(open/close) Φ16x1000 Fixer Φ45 Door sliding cable（S:18pcs） Φ6x5000 Φ6x3260 Roof bracing cable kit Side wall bracing cable Φ6x2460...
- Page 6 Covering Your World PARTS LIST FOR SH-RO46 Dimensions Descriptions Diagram Q'TY Parts# ( in mm ) Cover locker-up Ball Type Bungee Φ 5x33 Main Cover door cover upper cover Wrench #13 - 16...
- Page 7 Covering Your World PARTS LIST FOR SH-RO46 L4 x W 6.1x H3.55m SH-RO46...
- Page 8 Covering Your World SH-RO46 Main Dimension(mm) ※サイズは約です。必ず現物で合わせてください。...
- Page 9 Covering Your World Base drawing ※サイズは約です。必ず現物で合わせてください。...
- Page 10 Covering Your World Frame Assembly Steps Step 1: Measure according to above drawing, then Place and connect base rails as illustrated below with #15,#16,#17,Fix to ground with #27,Then install the ratchet on it. Step 2: Install the first row of rafters with#1,#2,and #3,#4,#5,then put into base feet,(It is very important to hold the first row of rafter with wood, rope and etc to avoid the hurts and damage of falling down.)
- Page 11 Covering Your World Step 3:Install the second row of rafter with #1,#2 and #4,#5,put into the base feet, then connect with first row with #11and #12,brace them with #24,#25. Step 4:The same step to install other rows of rafters.
- Page 12 Covering Your World Step5: Install the door frames as illustrated below，then fasten all the screws and parts. Tips: The tools below may needed while installing the shelter.
- Page 13 Covering Your World Roof Cover Assembly TIPS : Slide the roof cover over assembled frame from one side insert the conduit to pocket on side: #19 #20 Pocket for side wall conduit Ratchet tie down for tension- ing the Side wall (roof cover)
- Page 14 Covering Your World Step 2 : Attach the cover (#35/#36) to the frame as following : Note:#39 for main roof cover tensioning. #40 for front and end covers tensioning. Your assembled shelter will be similar to the illustration as below : Illustration for Ratchet...
