- Page 1 Covering Your World FABRIC BUILDING INSTRUCTIONS MODEL:SH-RO205015 W6.1xL15.2xH4.6(m) PICTURE MAY NOT REFLECT THE EXACT MODEL...
- Page 2 Covering Your World TO OUR NEW AND VALUED CUSTOMER Thank you for purchasing your new Instant Shelter. We know you will have as much pleasure owning your new shelter as we had in making it for you. Our shelters have been designed for rapid assembly and minimal maintenance.
- Page 3 Covering Your World CLIMBING EQUIPMENT It is highly recommended that scaffolding, ladders and mechanical lifting equipment conform to all local building codes when erecting the shelter. Safety straps and harnesses should be used at all times. The metal structure of the shelter has not been designed for human weight. Erecting shelter during wind or rain is unsafe and could result in serious injury.
- Page 4 Covering Your World SHELTER RELOCATION Should the shelter require relocation or disassembly for any reason, it is strongly recommended that the structure and its cover are thoroughly inspected prior to rebuilding PERIODIC SHELTER INSPECTION As with all structures, periodic inspection of the cover and all structural components is highly recommended.
- Page 5 Covering Your World PARTS LIST FOR SH-RO205015 Dimensions Descriptions Diagram Q'TY BOX Parts# ( in mm ) Φ 60x1600 Top roof arched rafter(left) Φ60x1600 Roof arched rafter Φ60x1600 Lower Roof arched rafter (end) Φ60x1450 Side upper curved rafter Φ60x1450 Side upper curved rafter(end) Φ60x1800...
- Page 6 Covering Your World PARTS LIST FOR SH-RO205015 Dimensions Descriptions Diagram Q'TY BOX Parts# ( in mm ) Φ25x1935 Cover conduit Φ25x1935 Cover conduit Φ16x1800 Zipper tool(open/close) Fixer (for door frame) Φ6x3600 Door sliding cable（S:14pcs） Φ6x3630 Roof bracing cable kit Φ6x3260...
- Page 7 Covering Your World L15.2 x W 6.1x H4.6m SH-RO205015...
- Page 8 Covering Your World SH-RO205015 Main Dimension（mm）...
- Page 9 Covering Your World Frame Assembly Steps Step A : Assemble roof rafter#1,#2 and #3，then connect with purlin#12 and #13 and purlin #12，then brace the roof with cables. Step B: Install side curved rafter#4、#5 Notice: Apply heavy duct tape on all pipe connections and clamps that may contact the cover. (tape are not included in the packaging, please buy it on market)
- Page 10 Covering Your World Step C ：Install side vertical rafters #6 and connect with purlin. Step D: Put the base rails #15、#16、#17 in position, put the above frame into base feet. Then install the door frame as shown below.(fasten each part by screws)
- Page 11 Covering Your World Step E : Install ratchet #27 on base rails with screws#31，fix the base rail on solid ground with anchor#28. Tips: The tools below may needed while installing the shelter。...
- Page 12 Covering Your World Roof Cover Assembly TIPS : Slide the roof cover over assembled frame from one side and insert the conduit to pocket: #19and#20 Pocket for side wall conduit Ratchet Tie-Down for Tensioning the side wall (roof cover)
- Page 13 Covering Your World TIPS : Secure the ends to frame with bungee and Velcro and attach the door cover to the doorframe as following : Attach door cover to frame with bungee.
- Page 14 Covering Your World Attach door cover to frame with Ball Bungee and velcro. Insert the strap(sewed on cover) through the ring and into the ratchet and tie.
