ALDI guarantees that our exclusive brand products are developed to our
stringent quality specifi cati ons. If you are not enti rely sati sfi ed with this
product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our
aft er sales support by calling the supplier's Customer Service Hotline.
Made in China
WORKZONE® is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
5
AFTER SALES SUPPORT
60339
1300 855 831
support@scheppach.com.au
MODEL:
YEARS
HBS20
04/2018
WARRANTY
User Manual
BANDSAW
HBS20
Original operating manual
Vers.No. 1712220
Contents
Overview
04
Utilisation
05
06
09
10
11
12
13
14
19
19
24
24
27
28
28
29
29
30
31
33
34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WORKZONE HBS20 and is the answer not in the manual?

Questions and answers

Related Manuals for ALDI WORKZONE HBS20

Summary of Contents for ALDI WORKZONE HBS20

  • Page 1: Table Of Contents

    If you are not enti rely sati sfi ed with this Intended use product, please return it to the nearest ALDI store within 60 days from the date of purchase, for a full refund or replacement, or take advantage of our Safety regulations aft er sales support by calling the supplier’s Customer Service Hotline.
  • Page 2 HBS20 AFTER SALES SUPPORT  support@scheppach.com.au 1300 855 831  MODEL: HBS20 PRODUCT CODE: 60339 04/2018...
  • Page 3 <Chapter> HBS20 AFTER SALES SUPPORT  support@scheppach.com.au 1300 855 831  MODEL: HBS20 PRODUCT CODE: 60339 04/2018...

  • Page 4: Explanation Of Symbols

    HBS20 Explanation of symbols Explanation of Symbols Caution - Read the operating instructions to reduce the risk of inquiry! Wear ear-muffs. The impact of noise can cause damage to hearing. Wear a breathing mask. Dust which is injurious to health can be generated when working on wood and other ma- terials.

  • Page 5: Introduction

    Introduction HBS20 I. Introduction Congratulations on choosing to buy a WORKZONE product. ® All products brought to you by WORKZONE are manufactured to the highest stand- ® ards of performance and safety, and as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 5 Year Warranty.

  • Page 6: Layout

    HBS20 Layout II. Layout (Fig. 1-16) Clamping screw Top saw band roller Rubber surface Saw band guard Top saw band guide Table insert Saw table Bottom saw band roller Foot 10. Cover locking mechanism 11. Side cover 12. On/off switch 13.

  • Page 7: Scope Of Delivery

    Layout/Scope of delivery HBS20 38. Allen screw for top guide pins 39. Retainer (top) 40. Allen screw for top retainer (2x) 41. Allen screw for bottom support bearing 42. Bottom support bearing 43. Screw for bottom retainer 44. Saw band protection 45.

  • Page 8: Intended Use

    HBS20 Intended use IV. Intended use The bandsaw is designed to perform longitudinal and cross cuts on timber or wood-type materials. To cut round materials you must use suitable holding devices. The machine is to be used only for its prescribed purpose. This machine is for do- mestic DIY use only.

  • Page 9: Safety Regulations

    Safety regulations HBS20 V. Safety regulations ATTENTION! The following basic safety measures must be observed when using electric tools for protection against electric shock, and the risk of injury and fire. Read all these notices before using the electric tool and keep the safety instructions for later reference.
  • Page 10 HBS20 Safety regulations rials similar to wood, or plastics. – If connections for dust extraction and a collecting device are present, make sure that they are connected and used properly. – When processing wood, materials similar to wood, and plastics. operation in enclosed spaces is only permitted with the use of a suitable extraction system.
  • Page 11 Safety regulations HBS20 – Only use approved and appropriately identified extension cables for use out- doors. – Only use cable reels in the unrolled state. 18 Remain attentive – Pay attention to what you are doing. Remain sensible when working. Do not use the electric tool when you are distracted.
  • Page 12 HBS20 Safety regulations • Give these safety regulations to all persons who work on the machine. • Do not use this saw to cut fire wood. • The machine is equipped with a safety switch to prevent it being switched on again accidentally after a power failure.
  • Page 13 Safety regulations HBS20 • Never use guards to lift or transport items. • Ensure that the saw band guards are used and correctly adjusted. • Keep your hands a safety distance away from the bandsaw blade. Use a push stick for narrow cuts. •...

  • Page 14: Before Starting The Equipment

    HBS20 Before starting the equipment/Attachment VI. Before starting the equipment Make sure the machine stands securely, i.e. bolt it to a workbench or solid base. There are four holes for this purpose in the machine foot. • The saw table must be mounted correctly. •...
  • Page 15 Attachment HBS20 Tensioning the saw band (Fig. 1a) • ATTENTION! If the saw is at a standstill for an extended period the saw band ten- sion must be relieved, i.e. before switching the saw on it is necessary to check the saw blade tension.
  • Page 16 HBS20 Attachment cover locking mechanisms (10) with the help of the screwdriver (29). Adjusting the saw band guide (Fig. 5 - 8) • Both the support bearing (36 + 42) and the guide pins (37 + 46) must be readjust- ed after every saw band change.
  • Page 17 Attachment HBS20 Adjusting the bottom guide pins (46) (Fig.7+8) • Disassemble saw table (7). • Undo screw for bottom retainer (43). • Move bottom retainer (47), bottom guide pins (46), until the front edge of the bottom guide pins (46) is approx. 1 mm behind the tooth base of the saw band. •...
  • Page 18 HBS20 Attachment Which saw band to use • The saw band supplied in the bandsaw is intended for universal use. The following criteria should be considered when selecting the saw band: • It is possible to cut tighter radii with a narrow saw band than with a wide saw band. •...

  • Page 19: Operation

    Operation/Working instructions HBS20 VIII. Operation On/Off switch (12)(Fig. 15) • To turn the machine on, press the green button “1“. • To turn the machine off again, press the red button “0“. • The bandsaw is equipped with an undervoltage switch. With a power failure, the bandsaw must be switched back on again.
  • Page 20 HBS20 Working instructions user. • Collect unused saw bands and store them safely in a dry place. Check for faults (teeth, cracks) before use. Do not use faulty saw bands! • Wear suitable gloves when handling saw bands. • All protective and safety devices must be securely mounted on the machine be- fore beginning work.
  • Page 21 Working instructions HBS20 Only draw the workpiece back once the saw band (21) has come to a standstill. • When sawing, the workpiece must always be guided by its longest side. • ATTENTION! When processing narrower workpieces it is essential to use a push stick.

  • Page 22: Technical Data

    HBS20 Technical data X. Technical data AC motor 230-240 V~ 50 Hz Power S1 250 W / S2 30 min 350 W Revolutions n 1400 min Saw band length 1400 mm Saw band width 3.5 - 12 mm Saw band width max. 12 mm Saw band thickness (recommended) 0.35 mm...

  • Page 23: Transport

    Technical data/Transport/Cleaning and maintenance HBS20 Wear hearing protection. The effects of noise can cause a loss of hearing. Keep the noise level and vibra- tion to a minimum! • Only use faultless devices. • Maintain and clean the device at regular intervals. •...

  • Page 24: Storage

    bgs700 HBS20 Storage/Electrical connection <Chapter> XIII. Storage Text Store the device and its accessories in a dark, dry and frost-proof place that is in- accessible to children. The optimum storage temperature is between 5 and 30˚C. Store the electrical tool in its original packaging. Cover the electrical tool in order to protect it from dust and moisture.

  • Page 25: Disposal And Recycling

    <Chapter> Electrical connection/Disposal and recycling bgs700 HBS20 Text Please provide the following information in the event of any enquiries: • Type of current for the motor • Machine data - type plate XV. Disposal and recycling The equipment is supplied in packaging to prevent it from being damaged in tran- sit.

  • Page 26: Troubleshooting

    bgs700 HBS20 Troubleshooting <Chapter> XVI. Troubleshooting Text Fault Possible cause Remedy Motor does not Motor, cable or plug defective, Arrange for inspection of the machine work. fuses burnt by a specialist. Never repair the motor yourself. Danger! Check fuses and replace as necessary. Housing cover open (limit Close housing cover exactly.
  • Page 27 HBS20 <Chapter> bgs700 Text AFTER SALES SUPPORT  support@scheppach.com.au 1300 855 831  MODEL: HBS20 PRODUCT CODE: 60339 04/2018...

  • Page 28: Warranty Details

    BAND SAW Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 60 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.

  • Page 29: Repair And Refurbished Goods Or Parts Notice

    Please be assured though, refurbished parts or replacements are only used where they meet ALDI’s stringent quality specifications. If at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint.
  • Page 30 Overview Utilisation Pack contents/parts HBS20 Contents of Box 1 x Bandsaw 1 x Saw table 1 x Push stick 1 x Parallel stop 1 x Open-ended spanner 10 / 13 mm 1 x Allen key 3 mm 1 x Allen key 4 mm 1 x Screwdriver 1 x Instruction manual 1 x Warranty card...
