SELECTING A CHANNEL/FREQUENCY

I Memory mode/VFO mode

The transceiver has 2 operating modes: memory mode
and VFO mode. Memory mode is used to select pre-
programmed marine channels in one of the 3 channel
groups; VFO mode is used to select frequencies
around preprogrammed channels.
Push [CH/FREQ] to toggle between memory and VFO
modes.
• "FREQ" appears when in VFO mode.
• In VFO mode only simplex operation is possible.

I Selecting a channel

The transceiver has 150 channels divided into 3
groups of 50 (max.) channels. However, the number of
channels in each group can be restricted in set mode
(pgs. 13, 14) depending on your needs.
NOTE: When channel 0 and/or 2182 kHz is se-
lected with the [2182KHz] switch, channel selection
is NOT possible. In such cases, push [2182KHz] in
advance.
➀
Push [CH/FREQ] to select memory mode, if neces-
sary.
➁
Rotate the [GROUP] selector to select the desired
channel group; then rotate the [CHANNEL] selector
to select the desired channel.
SQ L
Memory mode
CH/FREQ
S Q L
Group A
D U P
S Q L
Group B
SIMP
S Q L
Group C
D U P
S Q L
Group B, channel 1
D U P
S Q L
Group B, channel 2
D U P
S Q L
Group B, channel 50
3
CH/FREQ
SIMP
SQ L
VFO mode
Rotate
[GROUP]
to select a
channel group
Rotate
[CHANNEL]
to select a
channel within
a group
5
