Poollock V5A Short Installation Manual page 4

A
DETAIL
Pocket profile 10
Pocket end
pulley plug
Liner lock profile
Pocket end pulley
B
DETAIL
Leading bar end cap
Glider bracket
Pocket track
C
DETAIL
Separating wall
1.3
Between Guide
and Pocket profile
Guide
Under track
PVC Locking insert
This thicker side down!
Glider
Locking hole
Pocket profile
(Mechanism)
Pocket profile 0
or
Pin
6.2
DETAIL
Roll-up tube
Roll-up tube end cap
4
Pocket end pulley plug alternative
D
must be tightened to squeeze
rubber pads together
Rubber pad
4.1
Shaft
