Poollock V5A Short Installation Manual page 3

1. Before installation & Pocket profile installation
1.0 Measure the pool, and diagonal, and pit. Verify that it is according to the order.
1.1 TL (Track length) = 20mm + separating wall + pool length + 25mm
1.2 Pocket profile length = TL + 125mm
1.3 Install Pocket profile flush with inner pit wall.
1.4 Pocket profile has to be installed parallel (within 20mm).
1.5 TT (track groove to track groove) has to be kept as ordered.
1.6 Install Pocket profile and End wall insert first, then finish the pool. Finish the installation when the pool is completed.
1.7 Make sure that Pocket profile is clean and clear of any debris or concrete before you start to install.
2. Tracks & Mechanism installation
2.1 Mount the Guide on the track first. Mount the Guide plate on the Guide or mount the Guide-bracket to the mechanism.
Install first part of Under track with Guide and Guide bracket. Guide bracket will show you correct position of
2.2
mechanism (if guide bracket is used, if not see detail C on page 4).
2.3 Fix the mechanism in front, bottom and back. Mechanism has to be installed in correct depth (430mm).
2.4 Make sure that the mechanism is installed in level and in line with the tracks.
3. Lid bracket installation
3.1 Install "Lid-brackets" and "Lid-bracket End-set" before installing roll-up tube.
Install Lid brackets according to joints on the Lid. Evenly divide the rest of Lid bracket along the pit back wall.
3.2
3.3 Leave the brackets open so you can easily insert Roll-up tube.
4. Roll-up tube installation
4.1 Fix Roll-up tube to the shafts using the Rubber-pads, and washers, and attached screws (see page 4 detail D)
4.2 Centre Roll-up tube and fix it in the position by tightening Lock rings on both sides (see page 2)
5. Cover installation
5.1 Unfold the cover canvas behind the pit so the cover front with plastic Gliders is on the top (obs - correct side up)
5.2 Be very careful when unwinding the ropes from the reel. The ropes must be unwound (not pulled to the side) to prevent rope
twisting (not following this can cause serious problem).
5.3 Pull the rope through the tracks, around the pulley and back to the pit (see page 2)
5.4 Put the Glider through the Guide and fix the top part of the Guide. Make sure that all screws are completely tight and
supporting plate or Guide-bracket is installed.
6. Leading bar installation
6.1 Put the cover into the groove in Leading bar.
6.2 Fix the Leading bar to the Glider-bracket (see page 4 detail B)
6.3 Manually pull the cover on to the pool.
7. Power pack and hoses installation
7.1 Install the Power pack to desired location and connect the hoses. Fill the tank with oil (thin hydraulic oil SAE 15-30). Before
connecting cover or rope to the mechanism, Run the Power pack one way only for 3 min. Make sure that the oil tank is
full after test run. Refill oil as necessary depending on hose length.
8. Installation of the canvas to the Roll-up tube
8.1 Find centre of the tube and centre of the cover.
8.2 Fix the centre of canvas to the centre of Roll-up tube first, and fix the rest of the canvas to the tube (the canvas is
wider then the tube)
8.3 Roll the cover on the tube.
9. Rope installation
9.1 Pull the ropes through the pulleys and equalizer (see page 5)
9.2 Connect the ropes to the rope drum (see page 5)
10. Lid brackets & Lid installation
10.1 Install Lid brackets and Lid according to the actual Lid brackets and Lid you have.
3
