Poollock V5A Short Installation Manual page 2

1.5 Pocket end pulley
1.2 (hidden inside
TT (Track to track)
Pocket track)
A
End wall
Pocket profile
(TL+125mm)
Under track
(inside Pocket profile)
is mounted
PVC Locking insert
1.1
Glider
-grey: 2x65=130mm
-white: 2x40=80mm
Leading Bar (TT-100mm)
Movable 20mm
B
Leading bar endcap Glider bracket
Guide
Separating wall
C
96
96
Roll-up Tube incl. endcaps (TT-70mm)
(cut alutube TT-78mm)
D
Movable 20mm
Shaft
166
TT (Track to track)
500
LEFT SIDE MECHANISM RIGHT SIDE MECHANISM
2
