- Page 1 Operating Instruction JK802/804/808 Multi-channel Handheld Temperature Meter...
-
Page 2: Safety Summary
JK802 /804/808 User's Guide Safety Summary Warning Danger： The following general safety precautions must be observed during all phases of operation, service, and repair of this instrument. Failure to comply with these precautions or with specific WARNINGS elsewhere in this manual may impair the protection provided by the equipment. In addition it violates safety standards of design, manufacture, and intended use of the instrument. -
Page 3: Certifiaction, Limited & Limitation Of Liability
For warranty service or repair, this product must be returned to a service facility designated by Jinko. The buyer shall prepay shipping charges to Jinko and the Buyer shall pay all shipping charges, duties, and taxes for products returned to Jinko from another country. -
Page 4: Table Of Contents
JK802/804/808 User's Guide Contents Safety Summary................................2 CERTIFIACTION, LIMITED & LIMITATION OF LIABILITY..................3 Contents..................................... 4 Installation and Setup Wizard Packing List.............................6 Power Supply............................6 Operation Environment.........................6 Cleaning..............................7 Replace Battery............................7 Adjusting Tilt Stand..........................7 2.Overview Overview..............................9 MainSpecification...........................9 MainFunction............................9 FUNCTION...........................9 Sorting Setting...........................10... - Page 5 Installation and Setup Wizard BEEPSubsystem ........................31 RATESubsystem ........................31 UNIT SubSystem ........................31 CHANON SubSystem ......................32 HIGH SubSystem ........................32 LOWSubSystem ........................32 FETC? SubSystem ......................... 32 SYST System SubSystem .....................33 IDN? Subsystem ........................33 RST Subsystem ........................33 Error Subsystem ........................33 Specification General Specification .........................35 Accuracies ............................
-
Page 6: Installation And Setup Wizard
JK802 /804/808 User's Guide Installation and Setup Wizard This chapter provides the following information: Packing List Power Requirements Operation Environment Cleaning Replace Battery Adjusting Tilt Stand Packing List After you receive the instrument, carry out checks during unpacking according to the following procedure. -
Page 7: Cleaning
Installation and Setup Wizard Cleaning Do not attempt to clean the internal of JK802/804/808 Warning: Don’t Use Organic Solvents (such as alcohol or gasoline) to clean the Instrument. Use a dry cloth or a cloth slightly dipped in water to clean the casing. - Page 8 JK802/804/808 User's Guide Folded up the bottom of the bracket to achieve degree 45 position Figure 1‑ 3 Position of Degree 45...
-
Page 9: Overview
Overview Overview This chapter provides the following information: Overview Main Specification Main Function Overview Thank you for purchasing JK802 /804 / 808 Multi-channel Handheld Temperature Meter The JK802/804/808 adopts high-performance ARM microprocessor control, collects multi-channel temperature data simultaneously. JK802/804/808 can be compatible with a variety of temperature sensors, fast response, data stability while with the burnout detection function. -
Page 10: Sorting Setting
JK802/804/808 User's Guide Sorting Setting Build-in sorting data, each temperature data can be set both up limit and low limit Correction Function Each channel data can been corrected by the user. System Setup Keypad Lock Function Switch in Both Chinese and English... -
Page 11: Startup
Startup Startu This chapter describes: Front Panel Summery LCD Screen Interface Extern power and Battery Power up Connection of the Thermocouple Front Panel Summery Figure 3-1 Front Panel... -
Page 12: Lcd Screen
JK802/804/808 User's Guide Table 3-1Description of the Front Panel TFT-LCD Screen Select Keys Measurement Key——Enter Measurement Page (Page 15:[MEAS] Page) System Key ——Enter System Setting Page (Page 20: [SYSTEM] Page) Power On/Off Battery Charging Indicator Sensor access terminal Background Brightness——30%,50%,70%,... -
Page 13: Interface
Startup Interface Figure 3-3 Interface panel Table 3-3Interface panel description Remote Control Interface(USB-HID) USB Memory Interface Power Adapter Jack(+9VDC) RESET MICROSD Memory Interface Extern power and Battery The Battery can only be charged by Power Adapter JKL909。 While using the external power supply, the power adapter is also charging the battery. -
Page 14: 3.4.1 Charge Li Battery
The key is also orange which charging even when the Attention! LCR meter is off previously.) Power up Press the Power key softly to start it. Connection of the Thermocouple JK802 having 2 input ports JK804 having 4 input ports JK808 having input ports... - Page 15 Startup Table 3-4 Interface baffle description “＋” positive pole of the thermocouple “－”negative pole of the thermocouple Warning : Do not exceed channel isolation voltage 100V, otherwise it will damage the instrument.
-
Page 16: Meas] Page
JK802/804/808 User's Guide [MEAS] Page This section includes all measure result display information. <Measure Display>Page <MEAS DISPLAY> When press the [Meas] key, the <MEAS DISPLAY> page appears. <MEASURE DISPLAY> page mainly highlights the measurement results, and current sorting results will be displayed in different font and color. -
Page 17: Chan【01
[MEAS] Page Figure 4-3 JK808<MEAS DISPLAY> Page CHAN【01】 Steps to Set Sensor Model Step 1 Press[Meas] key to enter <MEASURE DISPLAY>page Step 2 Use the cursor keys to select[01]field Step 3 Use side soft keys to select Soft key Function Close the current channel Open the current channel *The same steps to close or open other channels... -
Page 18: Setup]Page
JK802/804/808 User's Guide [SETUP]Page This section includes all setup functions At any time,press [SETUP]to enter <SETUP> page. <SETUP> Page <Setup>Page In < SETUP> page, the Instrument does not display any results,testing is not in progress. The setup includes MODEL –Chose the type of the thermocouple UNIT –Temperature Unit Setting... -
Page 19: [Unit]Setting
[SETUP]Page TC-N Setting the thermocouple N type TC-R Setting the thermocouple R type TC-S Setting the thermocouple S type TC-E Setting the thermocouple E type TC-B Setting the thermocouple B type [UNIT]Setting Units Includes:(℃),(K),(F) Steps to set beep feature Step 1 Press [Setup] key to enter <SETUP>... -
Page 20: [Low] Setting
JK802/804/808 User's Guide Step 3 Use soft keys to select Soft Key Function UPPER Use touch screen to type in VALUE RESET Restore Defaults [LOW] setting Steps to set Lowlimit Step 1 Press [Setup] key to enter < SETUP > page Step 2 Use cursor keys to select [-200.0] field... - Page 21 [SETUP]Page MODEL-TC-T（℃） CH01 CH02 CH03 CH04 CH05 CH06 CH07 CH08 2013-12-04 15:00:00 28.0 28.1 100.5 19.2 32.4 54.3 21.6 41.9 2013-12-04 15:00:05 28.1 28.0 100.4 19.2 32.4 54.2 21.5 42.0 2013-12-04 15:00:10 28.0 28.1 100.5 19.1 32.3 54.2 21.5 42.0 2013-12-04 15:00:15 28.0 28.1...
-
Page 22: System]Page
JK802/804/808 User's Guide [SYSTEM]Page This section includes all system information. At any time, press [SYST] key to enter [SYSTEM] page. <SYSTEM CONFIG> page Following information can be configured in the <SYSTEM CONFIG> page. System date and time configuration [DATE/TIME] LANGUAGE... -
Page 23: [Time]
[SYSTEM]Page +1Day INCR+ -1Day DECR- [TIME] Procedure to set time Step 1 Press [SYST] key to enter<SYSTEM CONFIG> page. Step 2 Select[TIME] Step 3 HOUR +1Hour INCR+ HOUR -1Hour DECR- MINUTE +1Minute INCR+ MINUTE -1Minute DECR- SECOND +1Second INCR+ SECOND -1Second DECR- [LANGUAGE]... -
Page 24: [Touch Panel]
JK802/804/808 User's Guide [TOUCH PANEL] The LCR meter can work well without touch panel. But you cannot type number without touch panel. When you need to input numbers, the touch panel will be activated even it is shut down in system setting. -
Page 25: Dim Display [Dim]
[SYSTEM]Page Also, press ]to change the brightness. Figure6-2The Brightness key Procedure to change brightness Step 1 Press [SYST] key to enter<SYSTEM CONFIG> page. Step 2 Select [BRIGHTNESS] field. Step 3 30% of full brightness 50% of full brightness 70% of full brightness 100% Full brightness DIM DISPLAY [DIM]... - Page 26 JK802/804/808 User's Guide [APO]off Tips: Timer will be reset when press any keys or touch screen.
-
Page 27: Rem
This chapter provides the following information to remotely control the JK802/804/808 via the USB interface. USB-HID The USB-Serial Interface allows you to connect JK802 /80 4/808 to a USB port on you PC. You needn’t to install a driver in Windows system. - Page 28 RemoteControl recvBuffer,...
-
Page 29: Command Set
JK802 /804/808 User's Guide IN_REPORT_LEN, &recvBytes, &ol); Use ReadFileto read HID equipment. Report based on the data fransferred from WriteFile( hD reportBuf, OUT_REPORT_LEN, &sendBytes, &ol); WriteFile is used to transfer an output report to HID equipment. Communication Parameters VIP:0825 PID:0826... - Page 30 #define program pack() Here,...
-
Page 31: Notation Conventions And Definitions
Instrument response pack is 64 bytes, not sufficient for 0x00fill out. (Not ASCII“0”) A response pack (from instrument): ASCII format: JK802,REV A1.0,00000000,Jinko Instruments Inc. To test instrument USB-HID, we have free “Jinailian HID communication tester” software, you can download from:www.jk17.com... - Page 32 RemoteControl Table7-2 Notation Conventions and Definitions <> Name of a parameter The content is optional Select from several options...
-
Page 33: Parameter Types
JK802/804/808 User's Guide Parameter types Parameters may be of four types as follows. Table7-3 Available data type Format Samples <NR1> Integer 100,+100,-100 <NR2> Rational 1.23,+1.23,-1.23 Floating- <NR3> 1.23E4,+1.23E4,-1.23E4,-1.23e-4 point Floating- 1.23K,1.23N,1.23U (magnification in <NR4> point with following Table) magnificatio Table7-4 Magnification... -
Page 35: Modelsubsystem
RemoteControl Error subsystem MODELSubsystem model <tc-t|tc-k|tc-j|tc-n|tc-e|tc-s|tc-r|tc-b> To set the model sHead Model sPar <tc-t|tc-k|tc-j|tc-n|tc-e|tc-s|tc-r|tc-b> model? To check the current model sHead Model? sPar a R esponse <tc-t|tc-k|tc-j|tc-n|tc-e|tc-s|tc-r|tc-b> BEEPSubsystem beep <on|off> To set the beep sHead Beep sPar <on|off> beep? To check the current beep sHead beep? sPar... -
Page 36: Chanon Subsystem
JK802/804/808 User's Guide sHeader Unit? sPara Response <(℃)|(K)|(F)> CHANON SubSystem Chanon<integer> To set the channel status sHead chanon sPar <integer> 8-bit data , each bit representing a channel 0: off 1: Open Example: 11111110 , channel 1 is closed , 2 to... -
Page 37: Syst System Subsystem
Tips: unlock！ Power key cannot be locked IDN Subsystem To check version information sHead IDN? sPar a R esponse JK802,REV A1.0,<Serial Number>,Jinko Instruments Inc. RST Subsystem To start in heat sHead sPar Error Subsystem To check the message sent previously... - Page 38 JK802/804/808 User's Guide 7, Invalid command...
-
Page 39: Specification
Specification Specification This chapter describes the specifications and supplemental performance characteristics of the JK802/804/808: Specifications Dimension General Specification The Data is Achieved under the Following Conditions: Temperature: 23℃±5℃ Humidity: 65% R.H. Warm-up Time: >60 minutes Calibration Time： 12months Test Environment: Temperature and humidity range: 15℃~35℃,80% RH or less... -
Page 40: Accuracies
JK802/804/808 User's Guide Accuracies Instrument Accuracy does not include the standard contact compenstation Precision. Range（℃） Accuracy（℃） Model -150℃ to 0℃ ±1.0℃ 0℃ to 400℃ ±0.8℃ -100℃ to 0℃ ±1.2℃ 0℃ to 1350℃ ±0.8℃ -100℃ to 0℃ ±1.0℃ 0℃ to1200℃ ±0.7℃... -
Page 41: Dimension
Specification Dimension Jinko Instruments Changzhou Jinailian Electronic Technology Co.,Ltd JK802/804/808 User’s Manual English Edition...
