Jinko JK7123 User Manual

Program controlled withstand voltage insulation ground tester
Hide thumbs

Advertisement

Quick Links

Download this manual
Program Controlled Withstand Voltage Insulation Ground Tester
USER MANUAL
JK7123
OPERATION MANCAL
Program Controlled
Withstand Voltage Insulation Ground Tester
Vear2.0
Changzhou Jinailian Electronic Technology Co., Ltd
No.C3,Building 22,New Impetus Pioneering Center, No.1,Qingyang North
Road,Tianning District,Changzhou,Jiangsu,CN
TEL: 0086-519-85563477
FAX: 0086-519-85565067
https://jinailian.en.alibaba.com
www.jk17.com
www.jaldz.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the JK7123 and is the answer not in the manual?

Questions and answers

Related Manuals for Jinko JK7123

Summary of Contents for Jinko JK7123

  • Page 1 Program Controlled Withstand Voltage Insulation Ground Tester USER MANUAL JK7123 OPERATION MANCAL Program Controlled Withstand Voltage Insulation Ground Tester Vear2.0 Changzhou Jinailian Electronic Technology Co., Ltd No.C3,Building 22,New Impetus Pioneering Center, No.1,Qingyang North Road,Tianning District,Changzhou,Jiangsu,CN TEL: 0086-519-85563477 FAX: 0086-519-85565067 https://jinailian.en.alibaba.com www.jk17.com...

  • Page 2: Chapter I Safety Rules

    Program Controlled Withstand Voltage Insulation Ground Tester Chapter I Safety Rules The contents of this manual are subject to change without notice. If the manual is not exhaustive, please contact us directly. Rules and matters that should be noticed before high voltage test! !! !! 1.1 General provisions Before using this tester, please read the instructions carefully to understand the operating procedures and related safety signs to ensure safety.
  • Page 3 1.3 Test environment 1.3.1 Working position When operating the instrument, make sure that the instrument is placed in a place where ordinary personnel cannot touch it at will. If this is not possible due to production line arrangements, the test area must be isolated from other facilities and a "high-voltage test work area"...
  • Page 4 even more severe when you get an electric shock. 1.4.4 Medical regulations The tester must not be operated by a person with a heart attack or with a pacemaker. 1.5 Test safety procedures Never use the tester on a live circuit board or device! !! The ground wire of the tester must be connected in accordance with regulations.
  • Page 5 Chapter II Introduction to Safety Regulations 1.1 The importance of testing In today's high consumer awareness, every manufacturer of electrical and electronic products must do its best to make the product safe. Each product must be designed to the best of its ability to prevent the user from being exposed to electric shock.
  • Page 6 the formal production test, because the product's safety is determined at the design and test stage. Although only a few samples are used for product design judgment, online testing during production should strictly require that all products must pass safety standards to confirm that no defective products will flow out of the production line.
  • Page 7 must be supplied, the current required by the instrument will be much larger than the current used in the DC test. This will increase the danger to the operator. 2.3.2 Characteristics of Direct Current (DC) Test During the DC withstand voltage test, the stray capacitance on the DUT is filled. The capacitive current caused by the DC withstand voltage test will drop to zero after the stray capacitance is filled.
  • Page 8 should be safer. The higher the insulation resistance value, the better the insulation of the product. The insulation resistance value measured by the insulation resistance test is the equivalent resistance value formed by various related networks connected between the two test points and their surroundings.
  • Page 9 times the rated input current of the appliance, and the resistance value of the contact point is still 100mΩ, and the test time is 60 seconds. Most of these are electrical appliances, which are dangerous, so the requirements for specifications are higher than general appliances. In the current safety regulations in the world, some specifically require that the contact resistance of the ground wire be measured first.

  • Page 10: Chapter Iii Technical Specifications

    Chapter III Technical Specifications 3.1 Product Introduction Programmable withstand voltage insulation grounding tester is a testing instrument for testing the safety parameters of electronic products. Can be used for household appliances, electronic instruments, electronic equipment, electronic components, wire and cable and other electrical products withstand voltage and insulation testing.
  • Page 11 Range:0-5.00KV AC 0-6.00KV DC Resolution: 0.01KV Voltage display Accuracy：士(3% set value+3 character) Range:0.01-20.00mA AC 0.01-10.00mA DC Resolution:0.01mA Current display Accuracy 士(2% set value+3 characters) Insulation resistance test Rated output:1000V DC Range:500 - 1000V DC Resolution:1V Voltage setting Range Accuracy:±(2% set value+5V) Range:0.50KV –...
  • Page 12 Chapter IV Panel Description 4.1 Front panel structure 4.1.1 Schematic diagram of the front panel 4.1.2 Front panel description 1. Start switch The green momentary contact switch contains a PASS indicator. Its functions are: As a start switch for test voltage output; When the DUT passes the test, this green indicator light will be on.
  • Page 13 "high-voltage output is dangerous." 12. Ground resistance detection high-end Combine with 8 to detect ground resistance. 13/14. Ground resistance current output Output 3-30A AC current 4.2 JK7123 rear panel structure 4.2.1 Schematic diagram of JK7123 rear panel...
  • Page 14 4.2.2 Description of the rear panel 1 ~ 5 output interface (spare) same as before 6. Remote control signal terminal (PLC) interface It is a standard 9PIN D-type terminal block. Provide normally open (N.O.) contacts for remote monitoring signals of PASS (test passed), FAIL (test failed) and control contacts for TEST (reset) and RESET (reset).
  • Page 15 Chapter V Operating Procedures and Steps 5.1 Operation Instructions This series of withstand voltage tester is mainly used for general production line or quality inspection, its operation and setting are very simple. Irrational settings and operations will not respond. 5.2 Operation steps Follow this procedure and steps to operate the instrument: 1.
  • Page 16 6. After the test is completed, the instrument will automatically turn off the output, the green indicator light on the start switch will light up, and a "beep, beep" sound will be emitted at the same time, indicating that the test object passes the test, and the display will show "PASS" and test result data.
  • Page 17 Chapter VI Remote Input and Output Signals 6.1 Input and output signals On the back panel of the tester, there are remote monitoring and remote control terminal blocks. It can connect the working state of the instrument to the monitoring center for monitoring, and can be connected to the remote control for operation.
  • Page 18 This tester is equipped with a remote control contact, and the TEST and RESET functions of the instrument can be operated by an external remote control device. A "momentary contact" switch must be used as the controller. Please pay special attention to never connect any other power source, if you connect other power sources, it will cause damage to the internal circuit of the instrument or malfunction.
  • Page 19 Chapter VII Automatic Discharge Circuit 7.1 Discharge Principle After the test, especially the DC withstand voltage test, a large amount of electrical energy will remain on the test object and the circuit, and the test line must be removed before the work of removing the test line.
  • Page 20 Chapter VIII Test Parameter Setting and Display 8.1 Test parameter description After power-on, the program will automatically enter the parameters set during the last test before the last shutdown, and the LCD will display: AC withstand voltage test DC withstand voltage test ACW SETUP XXX.XS DCW SETUP...
  • Page 21 manually reset. The "+" and "-" keys are operation keys for group selection and input keys for parameter values. "+" Key: The number will increase when you press this key, and "-" key: The number will decrease when you press this key. Each time you press the "+" and "-" keys, the last digit on the display will "increase 1"...
  • Page 22 3. Test Mode Selection After pressing the "SET" key, the program will enter the test mode selection, and the LCD will display: AC withstand voltage test DC withstand voltage test Test Mode = ACW Test Mode = DCW Select by ∧ or ∨ Select by ∧...
  • Page 23 Insulation resistance test Ground resistance test HI-Limit = XXXXMΩ HI-Limit = XXXmΩ Range: 0-2000 0=OFF Range:1-300 Please use the "+" or "-" key on the panel to enter the upper limit value to be set. If the upper limit of the insulation resistance is set to "0", the program does not determine the upper limit of the insulation resistance.
  • Page 24 display: AC/DC withstand voltage or Ground test Dwell Time = XXX.XS 0.5-999.9 0=Constant Note: The insulation resistance test does not have this function, the program will automatically skip this setting and go directly to the next setting. Please use the "+" or "-" key on the panel to enter the test time value to be set, the unit is second.
  • Page 25 After setting the output frequency and pressing the "SET" key, the program will enter the arc sensitivity setting mode, and the LCD will display: AC withstand and DC withstand voltage mode Arc Sense= X Please use the "+" or "-" key on the face plate to input the arc sensitivity value to be set.The arc Range:0-9 0=OFF sensitivity is divided into 1-9, there are 9 segments to set, 9 is the highest sensitivity, 1 is the...
  • Page 26 X.XXKV XX.XXmA X.XXKV XX.XXmA Insulation resistance test Ground resistance test SETUP XXX.XS GND SETUP XXX.XS MX X.XXKV XXXXMΩ XX.XXA XXXmΩ If you press the "Start" switch, the instrument will start the test. If you press the "SET" key, the instrument will immediately enter the parameter setting mode and you can set the parameters. 2.
  • Page 27 current or insulation resistance value exceeds the upper limit set value, it will be determined by the program as a test failure caused by the leakage current or insulation resistance upper limit. If its leakage current Or the insulation resistance value is still within the upper detection range of the instrument, the display will show: AC withstand voltage test DC withstand voltage test...
  • Page 28 show: Insulation resistance test LO-Fail XXX.XS MX X.XXKV <1MΩ 7. Voltage breakdown (BREAK) If the leakage current of the object under test during the AC / DC withstand voltage test is far beyond the range that the instrument can measure, and the arc current is far beyond the normal value that the instrument can measure, it will be judged by the program as resistant.
  • Page 29 Chapter IX Calibration Procedures and Procedures Before leaving the factory, the instrument has been calibrated in accordance with the relevant national standards and regulations. The accuracy of the instrument and the meter fully meets the specifications of the national standard. It is recommended that the instrument be calibrated at least once a year.
  • Page 30 Please use the "+" or "-" key on the panel to input the standard voltage into the calibration program, press the "+" key to increase the number, and the "-" key to decrease the number. Please confirm the number is correct before pressing the "EXIT" key to close the output and save the input data.
  • Page 31 Please use the "+" or "-" key on the panel to input the standard value of the standard ammeter into the calibration program, the unit is mA. Please confirm the number is correct before pressing the "EXIT" key to close the output and save the input data. If the data is not saved, press the "Reset"...
  • Page 32 Please use the "+" or "-" key on the panel to input the standard value of the standard ammeter into the calibration program, the unit is mA. Please confirm the number is correct before pressing the "EXIT" key to close the output and save the input data. If the data is not saved, press the "Reset"...
  • Page 33 Please use the "+" or "-" key on the panel to input the standard voltage into the calibration program, and its unit is V. Please confirm the number is correct before pressing the "EXIT" key to close the output and save the input data. If the data is not saved, press the "Reset" switch to turn off the output.
  • Page 34 turn off the output. 9.11 50MΩ correction of insulation resistance: Press the "SET" key, the program will enter the insulation resistance 50MΩ correction mode, and the display will show: CAL IR R3 = 50.00MΩ <TEST> to Calibrate Connect a standard resistance of about 50MΩ / 0.25W to “H.V.” and “Measured End” on this instrument, and then press the “Start”...
  • Page 35 saved, press the "Reset" switch to turn off the output. CAL GND V = 6.000V <TEST> to Calibrate 9.13 Correction of AC voltage to ground Press the "SET" key, the program enters the ground resistance AC voltage correction mode, and the display will show: Connect a standard voltmeter capable of measuring 10VAC to the test end of the instrument, and then press the "Start"...
  • Page 36 9.15 Calibration completed After the calibration is completed, the input power must be turned off and then on again, otherwise the test mode cannot be entered. The program does not accept unreasonable input. 9.14 Please pay special attention to the following: (1) "Start"...

  • Page 37: Chapter X Maintenance Guide

    Chapter X Maintenance Guide 10.1 Daily Maintenance 1. The tester should be used in a well-ventilated, dry, dust-free, and strong electromagnetic interference environment. 2. If the tester is not used for a long time, it should be powered on periodically. It is usually powered on once a month for at least 30 minutes.
  • Page 38 Accessories The instrument comes with the following items when it leaves the factory: 1.Power cord x 1e 2.Test lead x 1 set 3.Instruction manual x 1 4.Warranty card x 1 5. Certificate of conformity x 1 6.Test report x 1...
