Hanover Outdoor Furniture IMPORTANT If you have any problems with this product (missing or damaged parts, assembly issues, etc.), PLEASE DO NOT RETURN TO THE RETAILER/STORE from where you purchased the product. 1‐800‐416‐3511 Please call our Toll‐Free Customer Service Hotline at: Between 9:00 AM and 5:00 PM Eastern Time, Monday through Friday www.hanover‐products.com Or visit our website at: To expedite any future warranty claims, please retain the Instruction Sheet, Warranty Card and receipt for future use. For additional on‐line support on assembly, troubleshooting and care & maintenance of your outdoor furniture, please visit our website at: www.hanover‐products.com. 6/1/2015 (a) ...
Page 4
ASSEMBLY INSTRUCTIONS Attach the leg support to the chair legs(B1 & B2) by using the 1/4"x20 mm bolts and washers as shown in Fig 1 Guide these bolts through the holes in the leg support into pre-drilled holes in the chair legs. Hand tighten only Attach the support bar to the chair legs by using the 1/4"x20 mm bolts and washers as shown in .
Page 5
PARTS IDENTIFICATION LIST * NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE PARTS LIST DESCRIPTION ORDER PART # AR19986 CHAIR FRAME LEFT LEG AR19987 RIGHT LEG AR19988 SUPPORT BAR AR19989 LEG SUPPORT AR19990 1/4" X 20 MM HW0465 BOLT 5/16"...
Page 6
ASSEMBLY INSTRUCTIONS CSA Model 99010 BRX01700 Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference DANGER WARNING: If you smell gas: Improper installation, adjustment alteration, 1. Shut off gas to the appliance. service or maintenance can cause injury or 2.
TABLE OF CONTENTS Important Safety Information Important About Propane Specifications Parts Identification List Installation 7-11 Batteries Lighting Instructions Maintenance Troubleshooting Guide Warranty...
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54; International Fuel Gas Code. ; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable. The appliance must be isolated from the gas supply piping system by closing its equipment shutoff valve during any pressure testing of the gas supply system at test pressure equal to or less than 1/2 psi (3.5kPa).
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A self contained LP-gas cylinder for use with this appliance must have a capacity of 20 lbs. and must be equipped with a Type 1 connector and an OPD (overfill protection device). See Figure 1. The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S.
PARTS IDENTIFICATION LIST PART DESCRIPTION PART# CONTROL KNOB FP0245 GAS VALVE FP0307 THERMOCOUPLE FP0004 LP REGULATOR HOSE FP0308 ELECTRODE FP0003 ORIFICE ELBOW FP0310 IGNITION MODULE FP0006 PROPANE ORIFICE FP1283 FOOTCAP FC0743 LAVA ROCK SET FP1573 “AAA” BATTERY(1.5V) HW0705 1/4" X 15 MM BOLT HW0034 1/4"...
Page 11
TILE TOP FP1837 MIDDLE SUPPORT FP1838 BACK PANEL FP1839 SIDE PANEL-1 FP1840 SIDE PANEL-2 FP1841 DOOR PANEL FP1842...
INSTALLATION Identify parts packed in carton against the parts list. Remove all protective materials and set parts on a flat, non-abrasive surface. Attach the back panel to side panels by using four 1/4"x45 mm bolts and Ø6.5x1.0 mm washers as shown in Figure 2. Guide bolts through holes in back panel, into pre-drilled holes in the side panels.
Page 13
With the help of another person, carefully place the table rim onto the firepit base. After making any necessary adjustments to the alignment of the table rim and the assembled base, use four 1/4"x15 mm bolts and Ø18xØ6.5x1.5 mm washers as shown in Figure 6.
Page 14
After making any necessary adjustments to the alignment of the firepit base and table rim, use the hex bolt driver to tighten all bolts. Do not over tighten. Over tightening may strip bolts. Cover all bolts with covers. Slide the tank drawer out and place the LP tank in the drawer. Connect the regulator as shown in Figure 6.
Note the clear bumpers spaced evenly throughout the inside of the table top. Carefully place tiles inside table rim, resting on the clear bumpers as shown in Figure 8. Figure 8 10. Pour the lava rocks into the burner completely covering the burner. See Figure 9. Figure 9 11.
LIGHTING INSTRUCTIONS Warning: If these instructions are not followed exactly, a fire or explosion may result in causing property damage, personal injury or loss of life. 1. Make sure the control knob is in the "OFF" position. See Figure 12 Open the tank valve all the way.
TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Check that gas tank valve is open. Turn control knob to “ON” Burner won’t light No Propane Gas at Burner and push control knob in. Make sure tank has propane gas. Check that battery installed with negative (-) end first and has a charge.
1 YEAR LIMITED WARRANTY What is Covered Under This Warranty? The item you have purchased is warranted against defects in materials and workmanship for the following parts as outlined below only when unit is installed and operated in accordance with the instructions in this Owner’s Manual and in compliance with local building and fire codes: ...
