- Page 1 OPM110 Optical Power Meter User Guide _ Version 1.1 Ascentac Inc. www.ascentac.com +886-7-398-1000 +886-7-398-3965 sales@ascentac.com...
- Page 2 Ascentac. Disclaimer Ascentac shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this user guide.
- Page 3 The label with S/N has been altered or damaged. Notice: Ascentac makes no warranty of any kind with regard to the content in this document, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 4 Service & Support If you have any questions or need any assistance, please contact our service center. Kaohsiung Office TEL: +886-7-398-1000 FAX: +886-7-398-3965 Address: 11F.-1, No.80, Minzu 1st Rd., Sanmin Dist., Kaohsiung City 80761, Taiwan (R.O.C.) Please prepare below information before you contact us and describe the problems.
-
Page 5: Table Of Contents
Content 1. Safety Information ........................1 2. Introduction ..........................2 Features ..............................3 Application ............................3 3. Layout ............................4 Appearance ............................4 Instruction ............................. 5 4. Display ............................6 5. Operation ........................... 7 Power-on............................... 7 Power-off (Default: 10 mins) ......................7 Switching Wavelength ........................ -
Page 6: Safety Information
Do not use damaged power cords, accessories or other peripheral equipment. Make sure the product is operated on the permitted ambient conditions. Never directly look into the optical outputs interface. Dangerous laser radiation: 1 | OPM110... -
Page 7: Introduction
It can be used for absolute and relative optical power measurement. Ascentac OPM110 Series has built-in visual fault locator (VFL) and features excellent mobility owing to its mini-size and light weight. It can be powered by dry batteries. Its low power consumption and auto shutdown function allow extended operation in the field. -
Page 8: Features
Maximum Dynamic Range of 76 dB Wavelength memory function Auto shutdown for extending the battery life Display Units: dB, dBm, mW 2.2 Application Optical power or loss measurement in telecom or CATV installation and maintenance 3 | OPM110... -
Page 9: Layout
3. Layout 3.1 Appearance Front Back 4 | OPM110... -
Page 10: Instruction
Short press to set reference value. Data saving Long press to save measurement results. Item Function Description VFL optical connector Universal 2.5mm OPM optical connector Universal 2.5mm Battery Dry batteries: AAA-size x 3 USB Type C interface Power supply 5 | OPM110... -
Page 11: Display
4. Display Battery status 1550nm Wavelength Measured value Reference value 6 | OPM110... -
Page 12: Operation
5.2 Power-off (Default: 10 mins) Long press [ ] key to turn off the meter. Note 1. Please turn off the laser before turning off the meter. 2. Without any operation, the meter will be automatically turned off after 10 minutes. 7 | OPM110... -
Page 13: Switching Wavelength
If the value is less than 0.1mW, the measurement unit will be uW. If the value is less than 0.1uW, the measurement unit will be nW. If the value is less than 0.1nW, the measurement unit will be pW. 8 | OPM110... -
Page 14: Turning On Vfl (Default: Off)
] key to select the desired modulation output. CW 1 Hz 2Hz OFF CW Note Without flashing: CW Flashing once a second: 1Hz Flashing twice a second: 2Hz Without this mark: Off 9 | OPM110... -
Page 15: Setting Reference Value (Default: Off)
REF setting. In the condition of that the displayed measurement unit is mW, short press [ ] key and then the unit of reference value will be dBm and the unit of measured value will be dB. 10 | OPM110... -
Page 16: Saving Measurement Result
] key to save the measurement result. 1550nm 1550nm -10.00 SAVE 0001 OK Note Saving data includes the number of the record, wavelength and the measured value. The number of the record will be from 0001 to 9999. 11 | OPM110... -
Page 17: Specification
850, 1300, 1310, 1490, 1550, 1625, 1650 Optical Connector Universal 2.5mm 6.2 Visual Fault Locator (VFL) Visual Fault Locator Wavelength (nm) 650±10 (Visible) Output Power (mW) Modulation Output CW(Continuous Wavelength), 1Hz, 2Hz Distance (km) Optical Connector Universal 2.5mm 12 | OPM110... -
Page 18: Other
Working Temperature (°C) 0 to +50 Storage Temperature (°C) -10 to +60 Relative Humidity (%) 5 to 95, Non-condensing Dimensions and Weight Size (H x W x D) (mm) 128 x 52 x 22 Weight (g) (batteries excluded) 13 | OPM110...
