I-Tech UltraView iAP1200 User Manual page 14

AP-12AV/ DP-12AV / OP-12AV Series
(1) DC IN
(2) PC IN
(3) S-Video IN
(4) RCA IN
Jan 05
4. Using the System
B. I/O Outlet
(2)
(1)
： This is for connecting the power cable.
： This can be connected with the D-Sub 15 pin signal connector.
： This can be connected with the S-Video cable connector.
(for AV series only)
： This can be connected with the composite cable connector.
(for AV series only)
