FP-T88FVA
User manual
Version: 1.0.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP-T88FVA and is the answer not in the manual?

Questions and answers

Related Manuals for Exorigo-Upos FP-T88FVA

Summary of Contents for Exorigo-Upos FP-T88FVA

  • Page 1 FP-T88FVA User manual Version: 1.0.2...
  • Page 2 2016-12-13 1.0.2 J.Słocka Update Exorigo-Upos has made every effort to ensure that the information contained in this document is correct And reliable. However, Exorigo-Upos assumes no responsibility for any consequences whatsoever From the use of this information, and reserves the right to make changes without prior notice to interested parties.

  • Page 3: Table Of Contents

    User manual – FP-T88FVA TABLE OF CONTENTS INTRODUCTION ..........................5 1.1................................... 5 ENERAL RULES 1.2.................6 ETHOD OF USING FISCAL DAILY REPORT AND PERIODIC REPORT 1.3. FP-T88FVA ............................9 EALING THE PRINTER PLACEMENT OF PARTS AND SUBASSEMBLIES ................10 2.1.
  • Page 4 User manual – FP-T88FVA TECHNICAL SPECIFICATION ....................36 10.1.............................. 36 ECHANICAL SPECIFICATION 10.2..............................37 LECTRICAL SPECIFICATION 10.3..........................37 ONDITIONS OF WORK AND STORAGE 10.4. F ................................37 ISCAL PARAMETERS 10.5. R ..................................38 ECEIPT PRINTER 10.6. R ....................................

  • Page 5: Introduction

    User manual – FP-T88FVA Introduction The FP-T88FVA fiscal printer from Exorigo-Upos is a taxpayer's device for recording the turnover earned from the sale of goods and services and the amount of tax due to it. For a fiscal printer to perform this function, you must have a computer, sales program, and electronic copy archiving program.

  • Page 6: Method Of Using Fiscal Daily Report And Periodic Report

    User manual – FP-T88FVA 3. The "Service Book" of the cash register also includes the identification of a service technician authorized to substitute the service of the printer. 4. The user of the fiscal printer is obliged to carefully store the "Cashier's Checkbook" in its place of use and to protect it from unauthorized access.
  • Page 7 User manual – FP-T88FVA during the day. The report does not need to be prepared if there is no recordable sale of a fiscal printer on a given day.. Taxpayers are also required to print out periodic reports for monthly periods after the sale ends on the last day of the month.
  • Page 8 User manual – FP-T88FVA Documents header (name, address, NIP(Tax Id. No.), logo) Printout no., date range Report no., report’s date VAT rates example The amount of sales at a given tax rate or tax exemption, for inactive rates the item may be omitted or -.

  • Page 9: Sealing The Fp-T88Fva Printer

    1.3. Sealing the FP-T88FVA printer Access to the FP-T88FVA fiscal printer is blocked with a modeling seal that obscures one of the screws securing the base. This seal is a service seal and should have an embossed identifier from the manufacturer or service technician.

  • Page 10: Placement Of Parts And Subassemblies

    User manual – FP-T88FVA Placement of parts and subassemblies 2.1. FP-T88FVA general view 166mm 195mm 128mm 160mm 151mm Side view. Exorigo-Upos S.A.
  • Page 11 User manual – FP-T88FVA 55mm 355mm 145mm 141mm 178mm 142mm Back view. Exorigo-Upos S.A.

  • Page 12: Unpacking And Prepairing For Work

    Before you start selling, connect the printer to a power source for 24 hours to charge the batteries. The set includes: FP-T88FVA fiscal printer with integrated display, − roll of thermal paper, − 24VDC external power supply, −...

  • Page 13: Instalation Requirements

    − The FP-T88FVA fiscal printer can be connected to any PC with a serial port for communication with the printer and a software application that controls the printer functions (according to printer specifications).

  • Page 14: Choosing The Workplace For Printer

    User manual – FP-T88FVA 3.3. Choosing the workplace for printer Notes on choosing a workplace for your printer: • The printer should be positioned horizontally, • The device can work up to 2000m n. M. • Avoid using the printer in a place with high humidity, •...

  • Page 15: Operational Panel

    User manual – FP-T88FVA • In order to avoid paper jam, do not cover the handpiece with the handpiece through which the paragliders go or place objects, • The device may only be connected to the power source indicated in the user manual, no...
  • Page 16 User manual – FP-T88FVA Power indicator Error indicator Autonomic mode panel on the right side End of paper indicator of the printer Feed button Cover open button Label the microSD card slot on the left side of the printer INDICATORS •...

  • Page 17: Operating The Printer

    User manual – FP-T88FVA free space. BUTTONS • Paper feed - used to pull out the paper, inactive when the paper cover is open, the end of the paper has been detected, or the button has been disabled programmatically (for example, when the fiscal receipt is open).

  • Page 18: Shut Down

    User manual – FP-T88FVA temperature. 5.2. Shut down Turn off the printer by following the instructions below: Disconnect power from the printer by unplugging the power cord from the AC 230V power outlet. 2. Hold down one of the menu button for about 5 seconds.
  • Page 19 User manual – FP-T88FVA 1. Press the lid (cover) open button. 2. The receipt cover opens to the maximum position. Exorigo-Upos S.A.
  • Page 20 User manual – FP-T88FVA 3. Insert the roller into the container so that the paper rolls off the bottom of the roll. 4. Before closing the cover, hold the end of the paper out of the printer. Exorigo-Upos S.A.
  • Page 21 User manual – FP-T88FVA 5. The cover should snap. Exorigo-Upos S.A.

  • Page 22: Service And Maintenance

    User manual – FP-T88FVA 6. Release the protruding piece of paper with the serrated edge of the printer. When replacing a roll for a new one, be sure to first remove the residue from the used roll of paper. 5.5. Service and maintenance Cleaning of the thermal head and pressure roller.
  • Page 23 User manual – FP-T88FVA element grzejny Removing jammed paper Switch off the printer. 2. Open front cover by pressing the open lid (cover) button. 3. Remove paper and put roll back in. Removing jammed paper that prevents the cover from opening Switch off the printer.

  • Page 24: Operating The Display Screen

    User manual – FP-T88FVA Operating the display screen 6.1. Basic principles of use The display is an integral part of the fiscal printer. Every display failure involves the possibility of interrupting the printer operation and preventing further sales. Because the display design makes it susceptible to inappropriate use, it is important to follow some basic rules.

  • Page 25: Basic Principles Of The Fiscal Printer's Work

    User manual – FP-T88FVA Basic principles of the fiscal printer's work 7.1. Terms explaination • Non-fiscal mode - The fiscal printer is in this mode of operation since it was released by the manufacturer until it was fiscalized. Working in this mode, the document printer prints a header without a line containing the user's NIP ("Non-fiscal print"...

  • Page 26: Vat Invoice Printing Principles

    User manual – FP-T88FVA The FP-T88FVA fiscal printer runs in non-fiscal mode at the beginning, before performing fiscal operations. In this mode, the printer performs all of its functions but does not store sales information to the fiscal memory. As a result, you can not print reports that use previously-made fiscal records, such as periodic reports..
  • Page 27 User manual – FP-T88FVA Paper: The invoice is printed on a roll of paper. It is a one-layer, thermal paper. Invoice cancellation: The invoice will be automatically canceled 30 minutes after the sale starts and ongoing. Power failure: After power failure, the printer resumes printing the invoice, which can then be completed.

  • Page 28: Electronic Copy (Electronic Journal)

    8.1. System overview The FP-T88FVA saves copies of printouts on the microSD card, built into the printer. The dump is under the control of the EJ server program built into the cash register program. The microSD card is not sealed and is available to the taxpayer.

  • Page 29: Data Secured Copy

    You can view and verify the data saved by the printer and generate reports and other printouts using EJViewer2. The program, together with the Installation and Operation Manual of EJViewer2, is available at www.exorigo-upos.pl. There are also other programs that help you work with your printer.

  • Page 30: Standalone (Autonomous) Mode

    User manual – FP-T88FVA EJViewer2 system requirements: - Windows XP or later - 500MB free disk space - 1GB of RAM - 2GHz CPU - any optical drive. Standalone (autonomous) mode In the fiscal printer work program, the user interface is implemented as a menu displayed on the customer display.

  • Page 31: Menu Operations

    User manual – FP-T88FVA 9.1. Menu operations The buttons are used to control the printer from the menu: ENTER THE MENU Pressing both buttons for 2 seconds puts the printer into Menu mode. BUTTON „SWITCH” Press the button to move to the next menu item or the next set value of the parameter.
  • Page 32 User manual – FP-T88FVA Total periodic rteport From number to number From date to date Full range Back Back Back Other reports Information report Statistics report Fiscal memory statistics report Stocktake report Blocked articles report Printer’s SHA-1 Back EJ printouts...
  • Page 33 User manual – FP-T88FVA Cahe Last prints Back EJ drive Initialize the drive Close the drive Back Configuration Interface RS-232C A Protocol FP-210 FPE-1 FPE-2 Transmition: speed pairity data bits stop bits 115200 9600 19200 28800 38400 57600 Handshk.: Software...
  • Page 34 User manual – FP-T88FVA FPE-1 FPE-2 Back Cutter Cutter: option Auto Aplication command Cutter: cutting Partial Feed only Back Printouts Line spacing Dense Normal Print cancell after power off Back Network Address DHCP support? Printer’s IP Mask Gateway Options Back...
  • Page 35 User manual – FP-T88FVA Current: on Back Back Save changes EXIT MENU Warning! EJ prints (copies of receipts, invoices, 24-hour daily report) are only available in EJ state: "waiting for data dump" - EJ STATUS LED glows in green. Exorigo-Upos S.A.

  • Page 36: Technical Specification

    User manual – FP-T88FVA Technical specification Only removing the power cord plug will completely disconnect the power supply. Before connecting the machine to mains 230V AC, make sure the power cord is not damaged and the mains socket should be easily accessible..

  • Page 37: Electrical Specification

    User manual – FP-T88FVA Weight:......... 3 kg (including roll of paper and the display) 10.2. Electrical specification Power type:....Mains - battery, external power supply + 24V DC, 2.1A Napięcie:....... 24 V, constant current Power consumption: - max…………..…..…. 50,4 W - typical……………………….

  • Page 38: Receipt Printer

    User manual – FP-T88FVA Receipt summary:..........0,01 .. 54975581,38 Payment:............Daily amounts (total):………......Battery life (rechargeable), supporting 5 lat volatile memory and clock:……………………………….. Battery operating 48 hrs, 6200 lines of print time:........... (24 hrs after charging) Maximum number of items on a receipt or invoice 10.5.

  • Page 39: Sockets Overview

    User manual – FP-T88FVA Sockets overview Szuflada Ethernet USB-B RS232A 24V DC RJ12 RJ45 RJ45 Power supply 11.1. Drawer connector The printer is equipped with a signal interface for connecting the drawer. Opening the drawer, reading the status, and setting the pulse opening parameters of the drawer are functions provided by the printer communication interface.

  • Page 40: Usb Connector

    User manual – FP-T88FVA (in port B looped DTR-DSR) 11.3. USB connector USB Type B connector Pin # Description VBUS Urządzenie zostało oznakowane znakiem CE, potwierdzającym zgodność urządzenia z obowiązującymi wymogami dyrektyw Unii Europejskiej. Exorigo-Upos S.A.
