Summary of Contents for Exorigo-Upos FP20
- Page 1 UPOS-FP20 Online User manual...
- Page 2 User manual - UPOS-FP20 ONLINE The company Exorigo-Upos has put all efforts so that the information included in this document be correct and reliable. However, the company Exorigo-Upos does not bear any liability for consequences arisen out of use of the information, as well as it reserves the right to make changes without prior informing the interested parties.
- Page 3 User manual - UPOS-FP20 ONLINE History Changes Homologation Changes Version Date Date 05-11-2019 1.0.0 10-12-2019 First draft Update: 2 Construction of the fiscal printer, 1.1 Terms of use, 1.2 Sealing the printer, 1.4 Basic terms of operation of the printer, 1.0.1...
-
Page 4: Table Of Contents
User manual - UPOS-FP20 ONLINE TABLE OF CONTENT GENERAL INFORMATION ......................5 1.1. TERMS OF USE ................... 5 1.2. SEALING THE PRINTER ................6 1.3. EXPLANATION OF TERMS ................7 1.4. BASIC TERMS OF OPERATION OF THE PRINTER ..........8 1.5. -
Page 5: General Information
User manual - UPOS-FP20 ONLINE 1 GENERAL INFORMATION The fiscal printer UPOS-FP20 ONLINE of the company Exorigo-Upos is the tax payer’s equipment for recording turnover from sales of goods and provision of services, as well as relevant tax amounts in real-time. So that the fiscal printer can fulfill its function, it is required to install a software for operation of sales on a computer and to have a stable internet connection. -
Page 6: Sealing The Printer
1.2. SEALING THE PRINTER Access to the interior of the fiscal printer UPOS-FP20 ONLINE is locked by a seal of modeling clay covering one of the screw fixing the base. The seal is the service seal and it has the engraved ID number of service provider’s, issued by a national manufacturer... -
Page 7: Explanation Of Terms
User manual - UPOS-FP20 ONLINE 1.3. EXPLANATION OF TERMS • Non-fiscal mode of operation – The printer is in this operation mode from the assembly by the manufacturer until conducting fiscalization by the authorized service provider. Working in this mode, the printer prints on the printouts the header without the line including the user’s Tax Id. -
Page 8: Basic Terms Of Operation Of The Printer
User manual - UPOS-FP20 ONLINE 1.4. BASIC TERMS OF OPERATION OF THE PRINTER The manufacturer enters into the fiscal memory of each printer the serial number and unique number. The numbers are visible outside the printer and are entered into ‘The fiscal cash register service book’... - Page 9 User manual - UPOS-FP20 ONLINE Optional graphics Name of the tax payer Address of the sales point Following number of printout Designation of the daily fiscal report Number of the fiscal day Duration of the particular fiscal day Definition of the goods and services tax rate...
-
Page 10: Reaching The Capacity Of The Fiscal Memory
User manual - UPOS-FP20 ONLINE Important: Note that the Daily report is printed automatically during closing the period called the Fiscal Day and such manner of receiving the printout should not be treated as the manner of settlement of internal periods, e.g. particular changes within the calendar day. -
Page 11: Construction Of The Fiscal Printer
User manual - UPOS-FP20 ONLINE 2 CONSTRUCTION OF THE FISCAL PRINTER The fiscal printer is built of an "easy load" thermal printing mechanism equipped with an automatic cutter, a customer display in an integrated version with the printer, with a... - Page 12 User manual - UPOS-FP20 ONLINE Version with external, free-standing display. It is also available, a built-in version with an external display.
-
Page 13: Interface Connectors
This connector is installed as standard, in every configuration of the fiscal printer UPOS- FP20 ONLINE. This is an Ethernet interface, working in the IEEE 802.3 100BASE-TX standard. The additional connector is construction option and can be used as 100BASE-... -
Page 14: Control Panel
User manual - UPOS-FP20 ONLINE Type: RS-232 Socket: Type RJ-45 Pin # Designator Description Data Set Ready Data Carrier Detected Data Terminal Ready Signal Ground Receive Data Transmit Data Clear to Send Data Request to Send Data USB connector Type:... - Page 15 User manual - UPOS-FP20 ONLINE Location of Autonomous Menu buttons. Selec The LEDs on the top receipt cover indicate the status of the printer. Below is the description of the individual signals and buttons. Operating Panel of the Printer Mechanism:...
-
Page 16: Unpacking And Preparing For Work
User manual - UPOS-FP20 ONLINE The location of the autonomous menu buttons on the free-standing display is shown below. 3 UNPACKING AND PREPARING FOR WORK NOTE! Unpacking and preparing the printer for work may be held only by the authorized service provider. -
Page 17: Connecting The Printer With The Computer
User manual - UPOS-FP20 ONLINE 3.2. CONNECTING THE PRINTER WITH THE COMPUTER The fiscal printer UPOS-FP20 ONLINE may be connected with the computer through the interfaces: RS-232 (serial port) USB (virtual serial port) Ethernet Work with the printer is possible only upon its detection by the appropriate cash register’s application (adjusted to the printer’s functionality). -
Page 18: Basic Principles Of The Printer's Operation
User manual - UPOS-FP20 ONLINE • using the printer in the place with high humidity and exposed to electrostatic discharge should be avoided, • using the printer in the place with too high or too low temperature should be avoided, •... -
Page 19: Operation Of The Fiscal Printer
User manual - UPOS-FP20 ONLINE 4 OPERATION OF THE FISCAL PRINTER Only unplugging the power supply cable results in full disconnection of power from the device. Before connecting the device with electric network 230 V AC, it should be checked whether the power supply cable has not been damaged and the network socket should be in an easily accessible place. -
Page 20: Switching Off The Printer
User manual - UPOS-FP20 ONLINE NOTE! Charging batteries is possible only when the printer is plugged into the 230 V (AC) network . One should not let the battery become completely discharged, as duration of full charging lasts approx. 24 hours. It is recommended to turn on external power supply even when the printer is not used or when it is switched off. -
Page 21: Service Actions
User manual - UPOS-FP20 ONLINE Replacement of paper may be conducted with the printer switched on or switched off. Before loading a new roll of paper, first rotate the customer display to allow free access to the inside of the printer (in the case of integrated display), and then do the following: 1. - Page 22 User manual - UPOS-FP20 ONLINE Failure to conduct the activities may even lead to damage of the printer due to user’s fault and result in loss of warranty. And in the event of failure to conduct the service inspection, the user is exposed to sever financial consequences. For the service technician’s arrival, the user should prepare the cash register book each time.
-
Page 23: Customer Display
5. Close the cutter cover and start the printer. 4.7. CUSTOMER DISPLAY The UPOS-FP20 ONLINE printer is equipped with a customer display, which shows the current state of the printer. The display is an integral part of the fiscal printer and performs the following functions:... -
Page 24: Update Firmware
User manual - UPOS-FP20 ONLINE • reading the cash register work program version, • informing about the course of some processes, • displaying information about errors, • provides support for the autonomous menu, • enables the display of non-sales advertising content if no sales operations are being performed and no error messages are displayed. -
Page 25: Menu Structure
User manual - UPOS-FP20 ONLINE Exit from the Menu Selection of the order ‘END MENU’ causes leaving the autonomic mode „CHANGE” key Pushing the button causes moving to the following item of the menu or change of the set value of the parameter. - Page 26 User manual - UPOS-FP20 ONLINE Wróć wyżej ^ Wyślij do CREJ > Konfiguracja > Interfejsy > RS-232C-A Trans.: 115200 N 8 2 9600 19200 E 28800 38400 57600 Handshake Programowe Sprzętowe Wróć wyżej ^ Obcinacz Opcja Cięcie Wróć wyżej ^ Wydruki Odstęp linii...
-
Page 27: Daily Report
User manual - UPOS-FP20 ONLINE włącz wyłącz Wróć wyżej ^ Wróć wyżej ^ Uruchamianie Weryfikacja pamięci chronionej: Tak/Nie włącz wyłącz Wróć wyżej ^ Wróć wyżej ^ Wróć wyżej ^ Zapis zmian: ZAKOŃCZ MENU Item Description menu Raporty Enables to print the fiscal reports (daily and periodical detailed) and finansowe collective periodical reports. -
Page 28: Technical Specifications
User manual - UPOS-FP20 ONLINE 2. Select the first item ‘Financial reports’ with the button 3. Select the third item ‘Periodical report’ with the button 4. Select between the item ‘Periodical detailed report’. 5. Select the required manner of printing: a. -
Page 29: Printer's Parameters
User manual - UPOS-FP20 ONLINE the paper manufacturer and the way the printouts should be stored should be specified by its manufacturer. 6.2. PRINTER’S PARAMETERS Mechanic specifications Construction: compact, free-standing Dimensions: height x width x length [mm] Mechanism: 144 x 199 x 147... -
Page 30: Description Of Emergency Situations
User manual - UPOS-FP20 ONLINE Amount of transaction for one item 0,01 .. 429496,7249 Total of the receipt 0,01 .. 1717986,91 Amount of payment 0,01 .. 1717986,91 Daily amounts (summary): 0,01 .. 42949672,95 Minimum life time of the battery: 5 years... - Page 31 User manual - UPOS-FP20 ONLINE Printer’s cover is open 0x8105 Check the cover closing Paper jam 0x8106 See section 4.5 Overheating of the printing head 0x8107 Turn off the printer and wait a few minutes See section 4.5, restart the printer, call the...
-
Page 32: Additional Software
MemoryViewer Software for local review and print of content of the fiscal and protected memory. The fiscal printer UPOS-FP20 ONLINE has achieved homologation based on the decision of the Central Office of Measures: PT 41/2019 z dn. 05.11.2019r.
