Body and Yoke Press
Read and understand these instructions
before operating or servicing these machines.
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
An LSG Company
831 South First Street, P.O. Box 32270
Louisville, KY 40232-2270
Phone: (502) 587-1292
Sales Fax: (502) 585-3625
Service/Parts Fax: (502) 681-1275
Combination
Sleever, Bosom,
WARNING
www.cissellmfg.com
CSBBYMV
CAB438C
CAB438C
Part No. AJ0976
March 2004
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cissell CSBBYMV
Summary of Contents for Cissell CSBBYMV
- Page 1 (If this machine changes ownership, this manual must accompany machine.) An LSG Company 831 South First Street, P.O. Box 32270 Louisville, KY 40232-2270 Phone: (502) 587-1292 Sales Fax: (502) 585-3625 Service/Parts Fax: (502) 681-1275 Combination www.cissellmfg.com CSBBYMV CAB438C CAB438C Part No. AJ0976 March 2004...
-
Page 3: Table Of Contents
Table of Contents © Copyright 2004, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. AJ0976 ©... - Page 4 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT AJ0976...
-
Page 5: Explanation Of Safety Messages
Explanation of Safety Messages Precautionary statements (“DANGER,” “WARNING,” and “CAUTION”), followed by specific instructions, are found in this manual and on machine decals. These precautions are intended for the personal safety of the operator, user, servicer, and those maintaining the machine. - Page 6 Safety Information 11. Install the press according to the INSTALLATION INSTRUCTIONS. All connections for steam, electrical power and grounding must comply with local codes and be made by licensed personnel when required. 12. Replace worn power cords and/or loose plugs. 13.
-
Page 7: Overall Dimensions And Connecting Data
Overall Dimensions and Connecting Data BASE PAD (6 PLACES) 4 x 6 in. (102 x 152 mm) 18.25 in. (464 mm) BASE MANUAL SPRAY ASSEMBLY LEFT END GUARD 20.63 in. (525 mm) FRONT ELEVATION AJ0976 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Operation 2.75 in. -
Page 8: Dimensions And Specifications
Operation Dimensions and Specifications DIMENSIONS OF BUCK BEFORE PADDING IS APPLIED NOTE: Actual pressing is 33.75 in. (318 mm) from top. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT STANDARD BUCK – 18 in. 18 in. (457 mm) STANDARD, TAPER- BODY, PULLOVER AND... -
Page 9: Utility Specifications
Utility Specifications Electric Voltage/Hertz/Phase Minimum Supply Circuit Conductor Ampacity Maximum Rating of Circuit Breaker Protection Device Dual Element Fuse Full Load Amps Average Running Amperes Number of Primary Power Connections Wire Size Motor Sleeve Blower Sidebag Blower Compressed Air Air Pressure Minimum Free Air Consumption Suggested Operating Pressure Steam... -
Page 10: Shipping Information
Operation Shipping Information Length Width Height Weight NOTE: Applicable codes, ordinances, specifications and/or other governing data related to installation must be complied with. The materials listed in Table 1 may or may not conform to these requirements. Materials Required Quantity Lockout type fused disconnect switch suitable for the electric service connected to the press (refer to wiring schematic in control box) (not required if circuit breaker is used) -
Page 11: Moving And Locating Press
Receiving Inspection The press is shipped assembled and enclosed in a plastic cover and crate. Upon delivery, inspect crate and contents for shipping damage. If crate or cover is damaged, or signs of possible damage are evident, have carrier note the condition on the shipping papers before shipping receipt is signed, or advise carrier of condition when discovered. -
Page 12: Anchoring And Leveling Press
Operation Anchoring and Leveling Press Refer to Figure 3. REMOVE ACCESS PANEL TO INSTALL CENTER LEVELING BOLT CENTER LEVELING BOLTS LEFT END LEVELING BOLTS 1. Place machine in desired location. 2. Trace the 6anchoring holes onto the floor. 3. Move the press aside. 4. -
Page 13: Connecting Steam Supply And Returns
10. Place level along inside carriage rail at C and raise or lower either end of press as necessary. Turn leveling bolts equal amounts to maintain alignment at A and B. 11. Use a level to recheck A, B, and C. 12. -
Page 14: Connecting Electrical Service
Operation Connecting Air Service Air service connected to press must have a minimum constant pressure of 75 psi (5.17 bar) and be of ample volume to meet requirements listed in Utility Specifications section. Air pressure should be reduced to 65 psi (4.48 bar) at air inlet regulator. It is the responsibility of the customer to connect the air line with galvanized pipe, brass, aluminum or stainless steel pipe, copper tubing, fittings, shut-off valve,... -
Page 15: Buck Indexing Mechanical Check-Out
Routing Blower Exhaust from Press Blower exhaust can add unwanted heat and noise into a room. Route blower exhaust from press upward near ceiling or to outside. Running exhaust outside is recommended. If running exhaust outside, make sure rain cannot get in. Install exhaust piping from exhaust muffler as follows: 1. -
Page 16: Electrical Check-Out
Operation 1/8 in. (3 mm) Figure 6 8. Press the head release button. Heads should open and buck should return to the dressing station. 9. Simultaneously press and release both buck in buttons. As buck travels into cabinet, press red safety bar which is near the operator. -
Page 17: Steam Injection And Temperature Check-Out
Steam Injection and Temperature Check-Out The following checks ensure that the steam supply to the press is of sufficient temperature. WARNING To avoid possible serious injury or death, perform the following BEFORE proceeding to check out: • Shut off AND lock out ALL electrical power to press. -
Page 18: Break-In Adjustments
Operation Break-In Adjustments As new press is used, working surfaces “seat-in” and friction decreases. This usually results in increased working speed. These conditions are considered normal in a new press and do not indicate a need for constant maintenance. This initial “break-in” period will vary with usage, but generally occurs during the first week of operation.
