F
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part #
Description
F
A
T
AN
SSEMBLIES AND
HERMOSTATS
A. 9W Standard Fan Assembly
0440420
Fan Motor, Evaporator
(MO.4410302)
0376413
Fan Blade (FB.0376413)
0123592
Relay, DPDT 208V coil
(RL.4440495)
0253603
Relay, DPDT 120V coil
(RL.4440267)
B.
Optional Adjustable
Refrigeration Thermostat
C. 0398557
Standard Non-adjustable
Defrost Thermostat
(CT.4440611)
Note: Revision B adds capacity and weight (
©2008 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
B
C
C
A
Wiring Item #
).
Page 5
D
Item Part #
H
EATERS
(1)
D. 0483959
(4)
E. Rear Rail Heaters
0415540
0109417
0109418
F. 0483952
(2)
(3)
L
B
AMPS AND
ALLASTS
None
M1XLD-GE
Technical Data Sheet
P/N 0490770_B
NSF
®
Certified
March 2008
E
Description
Wiring Item #
4 ft, 8 ft and 12 ft
Modular Electric
Defrost Heaters, 208V, 685W
(HE.4850633)
4 foot case (HE.4850482)
8 foot case (HE.4850422)
12 foot case (HE.4850423)
Front Glass Anti-Sweat Heater (7)
(GL.4978826)
P/N 0490770_B
(5)
(6)
