LFA 447
•
Place the sample holder plates (round or square) into the sample tray and insert the
samples (round or square, as shown in Figure 6 and Figure 7) with corresponding mask.
The sample tray can also be moved (removed or installed) by means of the extractor tool.
sample holder plates
(round or square inserts)
Figure 6: put in the sample holder plates
masks
samples
(round or square)
Figure 7: insert the samples
The operating principle of the different sample holder is described in
chapter 3 of this manual.
01/09 J:\LFA447\CHAPTER4.doc
Operating the Instrument
sample tray
10
