Advanced Air 0160 Installation, Operation And Maintenance Manual

Air control fire damper
Hide thumbs Also See for 0160:

Advertisement

Quick Links

Download this manual
AIR CONTROL
MODEL 0160
FIRE DAMPER
INSTALLATION, OPERATION
AND MAINTENANCE MANUAL
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 0160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advanced Air 0160

Summary of Contents for Advanced Air 0160

  • Page 1 AIR CONTROL MODEL 0160 FIRE DAMPER INSTALLATION, OPERATION AND MAINTENANCE MANUAL...
  • Page 2 Index Page Introduction and Health & Safety Fire damper – Model 0160 Two hour flexible wall – AFS with drop rods one side Two hour flexible wall – AFS with drop rods in wall Two hour flexible wall – multi-section AFS with drop rods two sides Two hour rigid wall –...
  • Page 3 Introduction Advanced Air (UK) Ltd have been manufacturing a comprehensive range of fire dampers and fire smoke dampers since 1975. We have always taken pride in our products and tested to the highest standards, originally to BS476 and now more stringent testing to CE labelling under the Construction Product Regulation which was introduced 1st July 2013.
  • Page 4 FIRE – 0160 ADJUSTABLE FRAME SYSTEM FOR TWO HOUR FLEXIBLE SUPPORTING CONSTRUCTION (SUPPORT ONE SIDE) Preparation Nom. duct width Opening width min. Opening width max. 100-1,000mm Nom. duct +194mm Nom. duct +350mm Ensure that the damper is kept in a clean dry environment and Nom.
  • Page 5 FIRE – 0160 ADJUSTABLE FRAME SYSTEM (IN WALL) FOR TWO HOUR FLEXIBLE SUPPORTING CONSTRUCTION Preparation Nom. duct width Opening width min. Opening width max. 100-1,000mm Nom. duct +194mm Nom. duct +350mm Ensure that the damper is kept in a clean dry environment and Nom.
  • Page 6 FIRE – 0160 MULTI-SECTION ADJUSTABLE FRAME SYSTEM FOR FLEXIBLE SUPPORTING CONSTRUCTION Preparation Nom. duct width Opening width min. Opening width max. 1001-2,000mm Nom. duct +194mm Nom. duct +350mm Ensure that the damper is kept in a clean dry environment and Nom.

  • Page 7: Rigid Construction

    FIRE – 0160 ADJUSTABLE FRAME SYSTEM FOR TWO HOUR RIGID SUPPORTING CONSTRUCTION Preparation Nom. duct width Opening width min. Opening width max. 100-1,000mm Nom. duct +194mm Nom. duct +350mm Ensure that the damper is kept in a clean dry environment and Nom.
  • Page 8 FIRE – 0160 HEVAC FOR RIGID SUPPORTING CONSTRUCTION (WALL) Preparation Nom. duct width Opening width min. Opening width max. 150mm thickness 100-1,000mm Nom. duct +160mm Nom. duct +185mm Ensure that the damper is kept two hour rated rigid in a clean dry environment and Nom.
  • Page 9 FIRE – 0160 DRYWALL PLATE INSTALLATION FOR FLEXIBLE SUPPORTING CONSTRUCTION Preparation Nominal duct width Opening width maximum 100-1,000mm Nominal duct +90mm Ensure that the damper is kept in a clean dry environment and Nominal duct height Opening height maximum M10 drop rod...
  • Page 10 FIRE – 0160 ADJUSTABLE FRAME SYSTEM FOR RIGID SUPPORTING CONSTRUCTION (FLOOR) Preparation Nom. duct width Opening width min. Opening width max. 100-1,000mm Nom. duct +100mm Nom. duct +350mm Ensure that the damper is kept in a clean dry environment and Nom.
  • Page 11 FIRE – 0160 HEVAC FOR RIGID SUPPORTING CONSTRUCTION (FLOOR) Preparation Nom. duct width Opening width min. Opening width max. 100-1,000mm Nom. duct +160mm Nom. duct +185mm Ensure that the damper is kept in a clean dry environment and Nom. duct height Opening height min.

  • Page 12: Maintenance

    Remove the access door to internally inspect the damper. • The 0160 fire damper is fitted with an EML fusible link, this link is provided with a release latch on the • Visually inspect all damper components for signs of corrosion, obstructions and build-up of dirt/dust.
