- Page 1 AIR CONTROL MODEL 0400 FIRE DAMPER INSTALLATION, OPERATION AND MAINTENANCE MANUAL...
- Page 2 Index Page Introduction and Health & Safety Circular fire damper – Model 0400MAN Two hour flexible wall Two hour rigid wall Circular fire damper – Model 0400FME Two hour flexible wall Two hour rigid wall Operation and Maintenance Model 0400MAN Model 0400FME Wiring information Model 0400FME...
-
Page 3: Health And Safety
Introduction Advanced Air (UK) Ltd have been manufacturing a comprehensive range of fire dampers and fire smoke dampers since 1975. We have always taken pride in our products and tested to the highest standards, originally to BS476 and now more stringent testing to CE labelling under the Construction Product Regulation which was introduced 1st July 2013. -
Page 4: Installation Sequence
FIRE – 0400MAN CIRCULAR FIRE DAMPER IN FLEXIBLE SUPPORTING CONSTRUCTION Preparation Nom. duct diameter Opening size 100mm 155 x 155mm Ensure the that damper is kept in a clean dry 15mm thick gypsum boards 125mm 180 x 180mm environment and that there is no damage to the 150mm 205 x 205mm damper. - Page 5 FIRE – 0400MAN CIRCULAR FIRE DAMPER IN RIGID SUPPORTING CONSTRUCTION Preparation Nom. duct diameter Opening size 100mm 155 x 155mm Ensure the that damper is kept in a clean dry 125mm 180 x 180mm 135mm minimum thickness environment and that there is no damage to the two hour rated rigid supporting 150mm 205 x 205mm...
- Page 6 FIRE & SMOKE – 0400FME CIRCULAR DAMPER IN FLEXIBLE SUPPORTING CONSTRUCTION Preparation Nom. duct diameter Opening size 100mm 155 x 155mm Ensure that the damper is kept in a clean dry 15mm thick gypsum boards 125mm 180 x 180mm environment and that there is no damage to the 150mm 205 x 205mm damper.
- Page 7 FIRE & SMOKE – 0400FME CIRCULAR DAMPER IN RIGID SUPPORTING CONSTRUCTION Preparation Nom. duct diameter Opening size 100mm 155 x 155mm Ensure that the damper is kept in a clean dry 125mm 180 x 180mm 135mm minimum thickness environment and that there is no damage to the two hour rated rigid supporting 150mm 205 x 205mm...
-
Page 8: Maintenance
Re-fit the access door. • If the damper has not closed, the blade may have been incorrectly positioned, or the damper may be faulty. Please contact Advanced Air for advice. The damper is fully closed The damper is fully open... - Page 9 Incorrect set up of the actuator – the actuator has been adjusted by others from the Factory Set • Refit the access door and complete maintenance reports as appropriate. position. • For other faults contact Advanced Air Sales Office. • Complete any relevant reports.
- Page 10 WIRING INSTRUCTIONS – 0400FME Wiring detail for dampers fitted with spring return actuators AA230TS4 or AA24TS4. G:\PRODUCTS\DMP - 0400 Series\02 Drawings\D0400 - ES - Electrical Schematics\D0400 ES001 Wiring diagram fire smoke damper actuator\D0400 ES001 rev B Wiring diagram 0400 FME.dwg...
