READY To ASSEMBLE HEADBOARD Assembly Instructions Manual

READY
PARTS LIST
1 HEADBOARD PANEL 1 PC
2 LEFT LEG
3 RIGHT LEG
4 SPACER BLOCK
NOTE: WE INCLUDE SPARE HARDWARE IN CASE THE ALLEN WRENCH, JCB , BARREL NUT, WOODEN DOWEL, WOOD BUTTON OR WASHER ARE DAMAGED DURING ASSEMBLY.
Step 1
Insert Wooden Dowels (A) to locator holes on (1)(4) as shown below.
4
Attach spacer block (4) to the Legs (2)(3) as shown below, using JCB (B) tighten
Step 2
with Allen wrench (I).
B
4
Headboard & Bed
HEADBOARD
ASSEMBLY INSTRUCTIONS
Before assembling your Headboard, please read through these
instructions carefully. Familiarize yourself with the different parts.
Instructions apply for all sizes of bed
Wooden Dowel 10 X 30mm - 6 pcs
A
JCB M6 X 50mm (2") - 2 pcs
B
1 PC
1 PC
JCB M6 X 70mm (2 3/4") - 4 pcs
C
2 PCS
D
Barrel Nut - 4 pcs
Spare - 1 pc
A
A
A
4
Full > Queen > King
Spare - 2 pcs
Spare - 1 pc
G
Spare - 1 pc
E
Wood Button - 4 pcs
Spare - 1 pc
1
2
B
HARDWARE
F
JCB M6 X 25mm (1") - 4 pcs
H
Flat Washer - 4 pcs
Spare - 1 pc
I
Allen Wrench - 1 pc
Spare - 1 pc
A
3
Spare - 1 pc
Split Washer - 4 pcs
Spare - 1 pc
Adult Assembly
A
Wooden Dowel
B
JCB M6 X 2"
I
Allen Wrench
Page 1 of 6
