READY
TO
ASSEMBLE
Please note that you will require a Phillips head screwdriver and an allen wrench.
02
03
04
04
HARDWARE
A
1 1/2" Allen screw - 8 pcs
Spare - 1 pc
Step 1
Step 2
Assemble support leg (03 / 04) and center rail (02).
Using Allen screw (A).
Tighten with the Allen wrench (C).
Repeat for other center rail.
C
Allen wrench
SLAT KIT FULL BED
ASSEMBLY INSTRUCTION
Before assembling your bed slat kit, please read through these
instructions carefully and familiarize yourself with the different parts.
01
03
NOTE: WE INCLUDE SPARE HARDWARE IN CASE THE ALLEN WRENCH, ALLEN
SCREW OR WOOD SCREW ARE DAMAGED DURING ASSEMBLY.
B
Assemble bed frame according to bed assembly instructions.
If using mattress and foundation set the bed up low and use short support leg.
If using Storage Drawers or Trundle Bed choose the tall support leg.
03 / 04
( FULL )
01
SLAT SECTION
02
CENTER RAIL
03
TALL SUPPORT LEG
04
SHORT SUPPORT LEG
1 1/4" Wood screw - 8 pcs
Spare - 2 pcs
C
A
03 / 04
PARTS LIST
PO :
C
Allen wrench - 1 pc
Spare - 1 pc
A
02
2 SET
2 PCS
4 PCS
4 PCS
Adult assembly
A
1 1/2" Allen screw
Page 1 of 2
