I I l l l l u u s s t t r r a a t t i i o o n n d d e e p p i i c c t t s s a a n n M M 3 3 X X - - 1 1 2 2 E E P P
w w i i t t h h t t h h r r e e e e N N i i g g h h t t C C u u r r t t a a i i n n s s i i n n s s t t a a l l l l e e d d . .
PARTS LIST (per curtain)
Item
Quantity
Description
1.
2
Night Curtain Bracket
(Factory Installed)
2.
1
Night Curtain
3.
1
Wrench
4.
1
Spindle Lock
5.
1
Handle Hook
6.
2
Screw (#6 x
©2006 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
3
/
)
8
Night Curtain
Medium Temperature
Multi-deck Cases
Standard Canopy
with
P/N 0466017A
Excel
for
April 2006
