A. 9W Fan Assembly
0047000
Fan Motor, Evaporator
0315470
Fan Blade
embossing toward motor
B. 0411744
Standard Non-adjustable
Defrost Thermostat
C. 0137880
Optional Adjustable
Refrigeration Thermostat
Note: Changed items have been underlined.
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
®
Merchandisers
B
C
Wiring Item #
D
Item Part #
L
B
AMPS AND
ALLASTS
D. 0428648
(1)
D. 0428649
E.
(2)
(3)
Data Sheet Set
P/N 0378418C
NSF
®
E
A
Description
Wiring Item #
Ballast, Electronic
2 lamps
Ballast, Electronic
3 lamps
Fluorescent Lamp
Replace with like fixtures
P/N 0378418C
M3G
Certified
June 2004
(4)
(4)
(5)
