Chapter 6
Configuration Procedures
Selecting the Current Map
Access-T lets you activate either of the two DS0 maps, or enable automatic
switching of the maps as described in the previous procedure. To select which
DS0 map is currently active, follow these steps:
1. Select
2. Select
3. Select
4. Move the selection bar to
Sending the DS0 Map to the Far End
The
SEND
currently-active DS0 map to the far-end Access-T, rewriting the currently-active
map. (For example, if the near end has MAP1 active and the far end has MAP2
active, MAP1 from the near end will rewrite MAP2 at the far end.) You cannot
change the far-end's inactive map until it becomes active.
6-20
from the Main Menu Line.
SYSTEM
DS0 CONFIGURATION
.
CURRENT
Selecting or
MAP1 MAP2
enables automatic switching between maps 1 and 2 based on the
TIME
user-specified start and stop times, as described in the previous
procedure. The active map will always have an asterisk (
CAUTION:
extended period while in time switching mode. If
a test is running when the selected start and stop
time occurs, switching of the DS0 map will not
occur until the test is turned off.
command (
SYSTEM–DS0 CONFIGURATION–SEND
Note: The command should be used only between units
SEND
that have identical DTE port and aux port hardware (i.e., both
ends of the link have two DTE ports and one aux port).
CAUTION: The SEND command also transmits the cur-
rent configuration of all the DTE port, overwritting the
far-end's DTE port settings. This command should only
be used if you wish to send DTE port and mapping
configurations to the far end. Refer to Sending the DTE
Port Configuration to the Far End for more information.
.
, , or
MAP1 MAP2 TIME
sets the chosen map as always active. Selecting
Do not leave a test active for an
ACST-0351-005
June 1996
and press the key.
Enter
) next to it.
*
) lets you transmit the
