- Page 1 INSTRUCTION MANUAL for Installing STATIONARY LOFT LADDER HARDWARE QG.830 Series...
- Page 2 Instruction Manual for Installing Stationary Loft Ladder Hardware Shown: QG.830.08 Installation Tools Needed: 5mm and 4mm wrenches Step 1: Ladder Length Calculation All ladders using the Stationary Loft hardware are custom, made-to-order ladders. In order for the ladder to properly move between stored and climbing positions (see figures 1a and 1b) , it is critical to order the correct ladder length based on the planned location of the flat plate.
- Page 3 Figure 1a Figure 1b Storing Position Climbing Position 3. Measure from the floor surface where the ladder will be standing to the bottom edge of where the Flat Plate will be installed on the header board (see figure 3) . 4.
- Page 4 Step 2: Installing the Sliding Upper Guide Hardware to the Ladder 1. On the back edge of both the ladder side rails, measure down ¾” down from the tip of the ladder and scribe a straight line ( see figure 4a and 4b) . 2.
- Page 5 5. Complete the installation of the Sliding Upper Guide to the ladder using the ¼” x 20 bolts and acorn nuts by following the detailed recommended procedure below . Using a ¼” drill bit and the holes in the top roller guide as a drill guide, drill a ¼” hole halfway through the thickness of the ladder slide rail (see figure 6a).
- Page 6 Step 3: Installing the Bottom Foot on the Ladder 1. From the front edge of the ladder side rails, draw a line on the bottom of the rail ¼” in from the edge (see figure 7) . Figure 7 2. Align the front edge of bottom foot hardware to the scribed line, pushing the bottom foot hardware tight and flush to the bottom surface of the ladder (see figure 8) .
- Page 7 Step 4: Installing the Ladder onto the Header Board of the Loft 1. Align the ladder in the desired position in front of the opening to the loft. 2. Stand the ladder upright in the vertical stored position (see figure 10) and using the supplied #10 x ¾...
- Page 8 Measurements for Flat Plate Stationary Ladder Hardware Flat Plate Dimensions 3 3/8” overall height 2” cc ” cc ” overall width Pin to attach Sliding upper Guide to Flat Plate Sliding Upper Guide Flat Plate...
- Page 9 More Non-Rolling Options DOUBLE HOOK LL.DHGUIDE.08 Starting at $33.00 TOP SLIDING HOOK LL.THGUIDE.08 Starting at $189.00 Rolling Options ROLLING HOOK LL.RHGUIDE.08 Starting at $115.00 TOP ROLLER SWIVEL LL.SWGUIDE.08 Starting at $195.00 TOP ROLLER LL.TRGUIDE.08 Starting at $115.00...
- Page 10 Application Photos of Rolling Ladders...
- Page 12 Also available from CSH: Mini Barn Doors InvisiDoors Rolling Barn Doors 1170 Wauwatosa Rd. Cedarburg, WI 53012 (262) 365-7960 cshardware.com REV. 1.13.20...
