- Page 1 QUIET GLIDE ROLLING LADDER INSTRUCTION MANUAL QG.200-300-500-700 Series Hardware...
- Page 2 ENERAL NSTALLATION PECIFICATION UIDE For QG.200, 500, 700 Series Hardware Kits Step 1: Track Installation Special Application Notes/Cautions: • 7" clearance is required above the track's centerline when the ladder is in the storage position (to avoid contacting ceiling or crown molding), and at least 3" is needed when the ladder is fully angled for climbing.
- Page 3 Splice and End Cap Installation Special Application Notes/Cautions • If installing a Standard Double Roller or Swivel Roller (200 or 700 Series), ladder will need to be placed onto the track before adding End Caps. 1. To connect track rails using the Quiet Glide Splice Kit (QG.41), follow these steps: ·...
- Page 4 2. Slide all of the brackets into the channel in the metal track (if not done from Splice Kit steps), approximating the spacing on your mounting surface. Brackets should be no more than 32" apart. (Figure 2a-b) Figure 2a Figure 2b 3.
- Page 5 Step 2: Ladder Assembly (if applicable) Storage: • Store the ladder in its original packaging in a humidity-controlled environment until ready to finish/assemble. • Lay the stored ladder on a dry, level surface, preferably off the floor (do not lean against wall for any extended period, this can cause bowing/warping of the ladder).
- Page 6 5. Slide the steps into the dados, verifying that the compound miter is lined up in the proper orientation with the dado. (Figure 7-8). Confirm that the ladder side rails are all lying flat in contact with the spacers and the bottom of the ladder side rails are even with each other and perpendicular to the sides.
- Page 7 8. When all the steps have been installed, tighten the truss rods completely. (Figure 13) If assembled properly, the ladder side rails will be in tight contact with the plywood spacers (all 4 contact points). There will also be a slight, even gap between the table and the edge of the steps.
- Page 8 3. Using a ¼” drill bit, drill the holes for the ¼-20 KD bolts on the sides of the ladder (Figure 19-21) Recommended procedure for this: • Using the holes in the top roller guide as a drill guide, drill a ¼” hole half way through the thickness of the ladder slide rail.
- Page 9 Hook your ladder onto the track. Congratulations on completing your Quite Glide Ladder! Please consider leaving a review on Google Reviews or cshardware.com! Any questions? Please call CSH Customer Service at 262-375-7960 M-F 8:00am-4:30pm CST or email service@cshardware.com...
- Page 10 Dimensional Specifications Top Ladder Hardware Top Swivel Roller 7/8” Top Roller 7/8” Rolling Hook 7/8” 5-1/2” 6-1/2” 2-1/8” dia 6-1/2” 6-1/2” 4” CC 4” 2-1/2” 2” dia 4” CC 5-1/2” 5-1/2” 1-3/4” 5-1/2” 4” 1-3/4” 1-3/4” 5-1/2” Double Hook 53/64” Adjustable Hook 7/8”...
- Page 11 Hand Rail dimensions Rail Height and Distance for 8’, 9’, 10’ standard ladders Stock 1-1/4” x 1-1/4” with 3/16” radius corners 5/8” radius ends * +/- 1" 114"* 45°angle 2- Predrilled holes 3/8” (10’ ladder) (approximately) 2-1/8”CC on each end 5”...
- Page 12 Revised 6.20.23...
