SENSORWORX SWX-950 Installation & Operation Instructions page 8

CONFIGURATION SETTINGS
DETAILED FUNCTION TABLES FOR HYBRID (-AX) MODELS
FUNCTION #11: AUXILIARY INPUT WIRE MODE
On hybrid power packs (i.e. -AX option models) the functionality of the brown low voltage
input wire is configurable between the below functionality.
SETTING # MODE
3 Switch Input (0.5 second maximum pulse)
4 Switch Input (1.0 second maximum pulse)
5 Switch Input (2.0 second maximum pulse)
6 Override On / Logic High
7 Override On / Logic Low
8 Override Off / Logic High
9 Override Off / Logic Low
FCC INFORMATION (FCC ID: 2AVRY-SWX0003)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
1. This device many not cause harmful interference, and
2. This device must accept any interference received, Including interference that may cause undesired operation
Changes and Modifications not expressly approved by BLP Technologies can void your authority to operate this equipment under Federal Communications Commission's rules.
In order to comply with FCC/ISED RF Exposure requirements, this device must be installed to provide at least 20 cm separation from the human body at all times.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
ISED CANADA INFORMATION (IC: 26012-SWX0003)
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two
conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.
In order to comply with FCC/ISED RF Exposure requirements, this device must be installed to provide at least 20 cm separation from the human body at all times.
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes :
1. L'appareil ne doit pas produire de brouillage;
2. L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
3. Afin de se conformer aux exigences d'exposition RF FCC / ISED, cet appareil doit être installé pour fournir au moins 20 cm de séparation du corps humain en tout temps
SENSORWORX | 3 Essex Sq, Essex, CT 06426
203.678.4224 | www.sensorworx.com
© 2020 BLP Technologies, Inc. All rights reserved.
(
CONT.)
DESCRIPTION
For momentary switches, the power pack will toggle on the leading edge of a pulse on the brown input wire. For maintained switches, any
change of state on the brown wire that lasts longer than the respective setting's maximum pulse length will be read as one toggle action.
Lights are held on at Function 6, HIGH TRIM LEVEL and occupancy is ignored when auxiliary switch input wire is logic high (5-24VDC).
Lights are held on at Function 6, HIGH TRIM LEVEL and occupancy is ignored when auxiliary switch input wire is logic low (< 5VDC).
Lights are switched off (according to Function #5, TURN OFF SCHEME) and occupancy is ignored when auxiliary switch input wire is logic
high (5-24VDC).
Lights are switched off (according to Function #5, TURN OFF SCHEME) and occupancy is ignored when auxiliary switch input wire is logic
low (< 5VDC).
Five-Year Limited Warranty.
Complete Warranty Terms Located at: sensorworx.com/warranty
INS950 | REV 001–200611
