SENSORWORX SWX-950 Installation & Operation Instructions page 3

MODEL #: SWX-950-AX-D2
LOW VOLTAGE SENSOR
(e.g. SWX-201-1)
SWX-801
LOW VOLTAGE SWITCH
POWER PACK CAPACITY
SWX-950-AX series power packs can supply power to several occupancy sensors and additional secondary relay packs. Following the below formula ensures adequate power will be
available. Note the SWX-950-AX's relay has already been factored into the formula.
[ (# of PIR SENSORS*) x2mA ]
PIR SENSORS OR
LOW VOLT. WALL SWITCHES
POWER
#
REQUIRED
15 30mA
15 30mA
0 0
7 14mA
*or low voltage wall switches
APPLICATIONS
COMPATIBLE WIRELESS DEVICES
The below chart lists the devices that can be used in a SENSORWORX wireless application. Note that sensors and remote switch & dimmer
devices are transmit only devices and therefore must be linked to a load controller for switching or dimming of lighting.
MODEL #
SWX-201-B
SWX-401-B
SWX-402-B
SWX-851-xx
SWX-852-B-xx
SWX-854-B-xx
SWX-950
SWX-950-D2
SWX-950-AX
SWX-950-AX-D2
+ [ (# of DUAL TECH SENSORS) x10mA ]
EXAMPLE COMBINATIONS
DUAL TECH SENSORS
+
POWER
#
REQUIRED
+ 0
+ 0
+ 9
+ 8
DESCRIPTION
Small Motion 360° Sensor, PIR
Wide View Sensor, PIR
Long Range Hallway Sensor, PIR
Wall Switch Load Controller, No Neutral Required, <xx = color>
Remote Switch (On/Off), <xx = color>
Remote Dimming Switch (On/Off, Raise/Lower), <xx = color>
Power Pack Load Controller, 20A
Power Pack Load Controller, 20A, 0-10V Dimming
Hybrid Wireless/Wired Power Pack Load Controller, 20A
Hybrid Wireless/Wired Power Pack Load Controller, 20A, 0-10V Dimming
CLASS 2
WIRING
SWX-950-AX-D2
HYBRID
WIRELESS/WIRED
DIMMING
POWER PACK
** IF NO SENSORS ARE WIRED
OR WIRELESSLY LINKED, CONNECT
WHITE WIRE TO RED.
+ [ (# of SWX-910) x55mA ]
SECONDARY PACKS
+
#
0 + 0
0 + 1
90mA + 0
80mA + 0
CLASS 1
WIRING
*
*
0-10V DIMMABLE LOAD
* CAP UNUSED BLACK OR YELLOW WIRE
< [ (# of SWX-950-AX) x90 mA]
SWX-910 TOTAL
=
POWER
POWER
REQUIRED
REQUIRED
0 = 30mA
55mA = 85mA
0 = 90mA
0 = 94mA
WIRELESS TYPE
Transmit
Transmit
Transmit
Transmit & Receive
Transmit
Transmit
Receive
Receive
Transmit & Receive
Transmit & Receive
OR
POWER
SUPPLIED
<
BY ONE
SWX-950-AX
< 90mA
< 90mA
< 90mA
< 90mA
POWER TYPE
Battery
Battery
Battery
120-277 VAC
Battery
Battery
120/277 VAC
120/277 VAC
120/277 VAC
120/277 VAC
