200/83 kHz Split Sonar View

Split Sonar View displays sonar returns from the 83 kHz wide beam on the
left side of the screen and displays sonar returns from the 200 kHz narrow
beam on the right side of the screen. Depth is displayed in the upper left hand
corner. You can use the Split Sonar View to make side by side comparisons
between the sonar returns from the 83 kHz wide beam and the 200 kHz
narrow beam.
The digital readouts in the Split Sonar View cannot be customized; therefore,
information such as water temperature and voltage are unavailable in the Split
Sonar View.
Depth
83 kHz
Sonar
History
Window
Views
200/83 kHz Split Sonar View
20
Upper Depth
Range
200 kHz Sonar
History Window
Lower Depth
Range
