Automated AI Temperature Sensing System (AATSS)
Model V2 USER MANUAL
Please Note:
This Manual is to ensure that the user can use the product correctly, to avoid danger or
property loss in operation. So please read it carefully before using this product and keep
it for future reference. Without written permission, no entity or individual is allowed to
extract, copy, translate or modify all or part of this manual in any way. Unless otherwise
agreed, the company does not provide any express or implied statement or guarantee
for this manual
Attention
① Do not splash liquid or metal on the outer screen to avoid scratches or damages
② Use specialized detergent to clean the equipment to avoid watermarks
③ Please ensure that the equipment is well grounded to avoid interference and
damage to video and audio signals
COPYRIGHT RICHTECH 2020
- 1 -
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RICHTECH V2
Summary of Contents for RICHTECH V2
- Page 1 Automated AI Temperature Sensing System (AATSS) Model V2 USER MANUAL Please Note: This Manual is to ensure that the user can use the product correctly, to avoid danger or property loss in operation. So please read it carefully before using this product and keep it for future reference.
- Page 2 1. About AATSS model V2 The V2 is designed for easy integration into your local area network and existing access control systems. Combining high-precision infrared temperature detection with face recognition technology and a full suite of software functions, the AATSS V2 is the finalized all-in-one solution for fully-automated quick contactless temperature screening.
- Page 3 2.1.2. Slip the V2 interface cables through the center hole of the Stand Base 2.1.3. Affix the V2 to the Stand Base and secure from the bottom using the helix nut provided COPYRIGHT RICHTECH 2020 - 3 -...
- Page 4 2.1.4. Connect the USB, Ethernet, and Power Cable to the Stand Base connectors 2.1.5. Pass all the data interface cables through the hole in the stand backside cover. COPYRIGHT RICHTECH 2020 - 4 -...
- Page 5 2.1.6. Secure the backside cover using screws 2.1.7. Complete installation, adjust the screen to the side with the blue light bar. COPYRIGHT RICHTECH 2020 - 5 -...
- Page 6 30 - 40 seconds. If you need to manage the V2 through a network, connect the base to your router through an ethernet cable. For how to set up the network, please refer to the following Software section.
- Page 7 Note: We recommend using Windows 10 when managing the AATSS V2. 3.1. Network Preparation After connect the V2 and the router using an ethernet cable, you must make sure the V2 is within the same intranet as your computer. See Section 3.2.
- Page 8 You will need to change your computer’s static IP address to be on the same network segment as V2. You can change your IP address to 192.168.1.XXX (XXX here could be from 2~254, but not 8 to avoid conflict with V2. So for example, 192.168.1.200 will work).
- Page 9 After installing the plug-in, visit 192.168.1.8 again to open the login page. Initial username is admin, and the password is blank. After logging in, change your login information at: Remote Settings -> System Configuration -> User Management. COPYRIGHT RICHTECH 2020 - 9 -...
- Page 10 3.4. Network Configuration The default IP address of the V2 is 192.168.1.8. If you want to change the IP address to a different one, you can so in Remote Settings -> Network Configuration. Please ask your network administrator about which IP address is allowed on your network.
- Page 11 You can search data by time, face library, employee name, etc. 3.7. Temperature Monitoring The default normal temperature value is set to 96.1~99℉. It’s not recommended to change this default value. Tick Enable from Temperature Monitoring option to active high temperature alarm. COPYRIGHT RICHTECH 2020 - 11 -...
- Page 12 3.8. User Management V2 allows one administrator account and five more normal user accounts. Only the administrator account can modify device parameters, all the other accounts can only view the data. To check each account’s login history, please go to: Remote Settings->System Configuration->Log Query...
- Page 13 To setup email notification, you can input your email account information from: Remote Settings -> Network Configuration -> Email Config Please make sure the V2 can access internet through your local network. 3.10. Local Settings To keep snapshots on local computer, please choose the disk and directory where you want to store pictures.
- Page 14 3.11. Firmware Updates To update V2 with latest firmware, please get the firmware package from your reseller or official website. Install it from: Remote Settings -> System Maintenance -> Firmware update. System will restart automatically when the update completes. COPYRIGHT RICHTECH 2020...
- Page 15 Press for 5 seconds to restore default factory configuration P5: Alarm o -GND o +ALMO o Alarm output 1: Output 3.3V when its inactive; output 0V when it’s active P6: Ethernet Port o Supports 100M network COPYRIGHT RICHTECH 2020 - 15 -...
- Page 16 4.2. Sample integration Most electronic door system can be controlled through the relay interface. With our embedded program, you only need to connect the V2 with your existing door control system through relay interface ① and ②. Here is an example of the hardware integration and software configuration.
- Page 17 4.2.1. Hardware integration Open door control system Install V2 onto door base Get V2 Interfaces ready Find DC/Ethernet/Relay Interface COPYRIGHT RICHTECH 2020 - 17 -...
- Page 18 Connect network cable with Ethernet port Connect door control interface with ① and ② Connect 12V DC Power Adapter COPYRIGHT RICHTECH 2020 - 18 -...
- Page 19 • Face recognition: Detect if the visitor’s face matches whitelist group & ignore temperature • Temperature: Detect if visitor’s temperature is normal only & ignore face recognition • Temperature & Face: Only allow people from whitelist with normal temperature to enter COPYRIGHT RICHTECH 2020 - 19 -...
