- Page 1 English WRAP 12 User guide POMI Industri ApS Abildvadvej 5, Thorup, DK-9610 Nørager Tel. +45 98 55 20 00, Fax +45 98 55 22 00, Mobile +45 40 34 20 10 E-mail: pomi@pomi.dk - Homepage: www.pomi.dk...
-
Page 2: Table Of Contents
Contents POMI W 12 W ..........................3 RAPPER ............................3 AFETY INSTRUCTIONS EU DECLARATION OF CONFORMITY ...................... 4 ..........................5 ACHINE IDENTIFICATION ................................5 ØR START ....................6 ONVERSION FROM TRANSPORT TO WRAPPING ................................7 RAPPING 7.1......................7 OSITIONING OF BALES FOR WRAPPING ............................. -
Page 3: Pomi Wrap 12 Wrapper
1. POMI Wrap 12 Wrapper Congratulations - You have chosen a line wrapper machine. It can be used for wrapping straw. If used for anything else, you must have a written authorization from the manufacturer. The manufacturer disclaims any liability for damage to products and/or crops. -
Page 4: Eu Declaration Of Conformity
3. EU DECLARATION OF CONFORMITY Manufacturer: POMI Industri ApS Abildvadvej 5, Thorup DK-9610 Nørager Tel. +45 98552000 Company Hereby declares that Machine: Wrapper machine Make type, series no., year a) is manufactured in accordance with decisions made in the Council’s Directive of 14 June 1989 about mutual approach of the member states’... -
Page 5: Machine Identification
4. Machine identification When ordering parts please state the serial number. You will find the serial number on the type plate on the left side of the machine (see ill.). The motor no. is found on the left side of the motor. Serial no.___________________ Motor no.__________________ 5. -
Page 6: Conversion From Transport To Wrapping
6. Conversion from transport to wrapping Position the machine with a tractor or loader in the correct direction, in stacking position. Disconnect the tractor and remove the cable. Push the emergency stop. Start the motor according to the motor instruction. ... -
Page 7: Wrapping
7. Wrapping Start by fastening the foil to the two rods on the pusher. Wrap 8 layers of foil. Unfasten the foil and let the machine run automatically until the foil reaches the end of the spears. If the stack is supposed to curve, place the bales with air between them on one side and squeeze them hard together on the other side. -
Page 8: Closing The Foil Tube
8. Closing the foil tube When the foil tube is long enough to fully cover the ends of the last bales, wrap some extra rounds at the end of the foil tube to give a strong end surface. Cut off the foil at a suitable length. Set up the machine to run by itself so that it runs as free of the stack as possible. -
Page 9: Machine Operations Year 2014-2015
Machine operations year 2014-2015 10.1. Electrical box Emergency stop Depressing this button will stop all functions in the electrical box. To reactivate turn the switch from locked position, and re-activate the function requested. Ready When the emergency stop is released the lamp ready is lit. -
Page 10: Hydraulic System
10.3. Hydraulic system In front of the machine, 2 or 4 hydraulic handles are positioned. 1. Adjusts the height of the tower in the front. 2. Adjusts the height of the tower in the rear end. 3. Raises the support in the front. 4. -
Page 11: Foil Guard
10.4. Foil guard A foil guard is positioned in one corner, it consists of a bar sensoring the wrapped foil, if only 1 layer of foil is used. If the foil tears the bar will fall down and activate a switch that stops the machine. -
Page 12: Machine Operations Year 2016
Machine operations year 2016 - 11.1. Electrical box operations Depressing this button will stop all functions in the electrical box. To reactivate turn the switch from locked position, and re-activate the function Emergency stop requested. When the emergency stop is released the lamp under is lit and the machine is ready. -
Page 13: Electrical Box Operations
11.1. Electrical box operations Here you can change 2 times. The one who regulate how far the pusher go out before the foil starts to run and how long time it takes to move the pusher back. Press ESC until start appears. Press ▼... -
Page 14: Remote Control
11.2. Remote control Button Function Same function This button starts the wrapping process. It can also stop it again if pushed once again. When pushing this button, the wrapper rotates the foil. Push this button to activate the chains on the spears. When pushing this button the pusher arms retract. -
Page 15: Funktionsoversigt Fjernbetjening
11.3. Funktionsoversigt Funktionsoversigt fjernbetjening There is a functional overview included. This you can bring along in the loading machine. There is a functional overview included. This you can bring along in the loading machine. There is a functional overview included. This you can bring along in the loading machine. 11.1. -
Page 16: Hydraulic System
11.2. Hydraulic system In front of the machine, 5 hydraulic handles are positioned. 1. Raise the support in the right rear end. 2. Raise the support in the left rear end. 3. Raises the support in the front. 4. Is to fold the machine up and down. 5. -
Page 17: Foil Guard
11.3. Foil guard A foil guard is positioned in one corner, it consists of a bar sensoring the wrapped foil, if only 1 layer of foil is used. If the foil tears the bar will fall down and activate a switch that stops the machine. -
Page 18: Maintenance
Maintenance Clean around the motor daily or when needed, to avoid fire. Grease the bearings daily. Lubricate the pusher arms and chains with chain oil. When replacing chains, only use original chains. After the first day adjust, the wheels, after that adjust twice a year. Tightening torque = 100 Nm. -
Page 19: Good Advice
Good advice To ensure the optimum protection against the wind it is recommended to work against the most dominant wind direction so the foil forms a roof. It is recommended to work on a plane surface where any water will sink into the ground. -
Page 20: Optional Equipment
Optional equipment 15.1. Bale fork The operator is responsible for ensuring that the bale fork complies with the local rules for transport on roads. 15.2. Foil roll basket The basket contains app. 30 rolls and 4 rolls of bottom foil. The inside dimentions of the basket: 1150 x 2700 mm Height = 800 mm. -
Page 21: Problems
Problems Problem Solution Machine Check at the rear of the machine if The machine will not run emergency stop is pressed. Change the fuel filter Insufficient motor output. Clean air filter Check the hydraulic pressure (120 bar). The pusher arms cannot push the bales..
