- Page 1 English Stack 200 Instruction Manual POMI Industri ApS Abildvadvej 5, Thorup, DK-9610 Norager Phone +45 98 55 20 00, Mobile +45 40 34 20 10 E-mail: pomi@pomi.dk - Website: www.pomi.dk...
-
Page 2: Table Of Contents
Table of Contents 200 ............................3 TACK ..........................3 AFETY INSTRUCTIONS EU DECLARATION OF CONFORMITY ....................4 ......................... 5 ACHINE IDENTIFICATION ..............................6 OMPUTER ............................7 ENSOR OVERVIEW ........................... 8 ALE STACKER START .......................... 10 HE HYDRAULIC SYSTEM 8.1......................... 10 HE TRAILER VALVE BLOCK 8.2. -
Page 3: Pomi Stack 200
Pomi Stack 200 Thank you for choosing the Stack 200 bale stacker from POMI for your straw and silage needs. Using the bale stacker for any other purposes is subject to prior written permission from the manufacturer. Safety instructions FOR YOUR OWN SAFETY ... -
Page 4: Eu Declaration Of Conformity
EU DECLARATION OF CONFORMITY Manufacturer: POMI Industri ApS Abildvadvej 5, Thorup DK-9610 Nørager Tlf. +45 98 55 20 00 Company Hereby declares that The following machine: Stack 200 Make type, serial no., year has been manufactured in conformity with the provisions of Council Directive 2006/42/EEC... -
Page 5: Machine Identification
Machine identification When ordering parts, please state the serial number of the machine. You will find the serial number on the left side of the machine, as shown in the picture below. Serial no.___________________... -
Page 6: Computer
Computer 1. Start/pause (the external button has the same function). 2. Menu 3. Bale clamp out/in 4. Tip the bale onto the loading platform. 5. Lift the loading platform up and down / tip the bales onto the trailer. 6. Tilt the trailer 7. -
Page 7: Sensor Overview
Sensor overview This is an overview of the sensors on the Stack 200. -
Page 8: Bale Stacker Start-Up
Bale stacker start-up Use the start button to start and pause the loading program. Press this button to start automatic loading. The external button ( 1 ) has the same function. Use the Menu to choose between the two loading programs. - Page 9 When the loading platform is full, it tilts upwards until sensor B4 is activated. It is then lowered until it reaches sensor B5. When the loading platform stops in the top position, the trailer is full. It is therefore important to enter in the PLC how many layers and stacks you want to load onto the trailer.
-
Page 10: The Hydraulic System
The hydraulic system 8.1. The trailer valve block Use the hex screw ( 1 ) to adjust the oil flow when using a load sensing control system (LS). The pressure control valve ( 2 ) is set to 180 bars. 8.2. -
Page 11: Hydraulics Diagram
8.3. Hydraulics diagram Left side Right side Drawbar Retention fork Bale push-off mechanism Bale clamp (master/slave system) - Page 12 Tilt trailer Tilt loading platform Blocking of suspension Bend fork yoke Tilt loading platform Support wheel...
-
Page 13: Electric Box
Electric box In the PLC on the electric box you set how many layers and stacks you want to load onto the trailer. Here you also set the closing and opening time for the bale clamp. If you need to change any of the values, press and hold the ESC button until a row lights up. - Page 14 Then, using the up and down arrows, move to the row you want to change and press OK. Then there is only one number marked where you can move the selection with the left/right arrows, and change the value with the up/down arrows. Press OK, and exit by pressing the ESC-button.
-
Page 15: Wiring Diagram
9.1. Wiring diagram Sensor Tilt fork yoke UP Sensor Tilt fork yoke DOWN Sensor Tilt loading platform UP Sensor Tilt loading platform DOWN Sensor Bale push-off Sensor Pressure Sensor Tilt trailer Start/Pause Change program... - Page 16 Bale clamp CLOSE Bale clamp OPEN Bend fork UP Bend fork DOWN Tilt loading platform UP Tilt loading platform DOWN Tilt trailer UP Tilt trailer DOWN Retention fork forward Retention fork backwards...
- Page 17 Drawbar IN Drawbar OUT Support wheel DOWN Support wheel UP Left side DOWN Left side UP Right side UP Right side DOWN Bale push-off mechanism IN Bale push-off mechanism OUT...
- Page 18 Bypass valve Bale clamp CLOSE Bale clamp OPEN Retention fork Retention fork reflux valve Tilt trailer UP Tilt trailer DOWN Tilt trailer UP...
- Page 19 Tilt loading platform DOWN Bend for yoke / Tilt fork yoke UP Bend for yoke / Tilt fork yoke DOWN Bale push-off mechanism OUT...
- Page 20 Drawbar IN Drawbar OUT Support wheel DOWN Support wheel UP Left side DOWN Left side UP Right side UP Right side DOWN Bale push-off mechanism IN Bale push-off mechanism OUT...
- Page 21 EMERGENCY STOP...
-
Page 22: Technical Specifications
1. Technical specifications Max. hydraulic operating pressure 180 bars Power 12 V Transport width 2.5 meters Operating width 2.7 meters Height 3.9 meters (4.15 meters) Length 9.10 meters Weight 6000 kg Max. Load 8000 kg Wheels 4, 400/60-15.5 Noise level Below 70 dB...
