WRAP 5
Instructions 2001
English
POMI Industri ApS
Abildvadvej 5, Thorup, DK-9610 Nørager
Tel. +45 98 55 20 00, Fax +45 98 55 22 00, Mobile +45 40 34 20 10
E-mail:
pomi@pomi.dk
- Homepage:
www.pomi.dk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WRAP 5 and is the answer not in the manual?

Questions and answers

Summary of Contents for POMI WRAP 5

  • Page 1 WRAP 5 Instructions 2001 English POMI Industri ApS Abildvadvej 5, Thorup, DK-9610 Nørager Tel. +45 98 55 20 00, Fax +45 98 55 22 00, Mobile +45 40 34 20 10 E-mail: pomi@pomi.dk - Homepage: www.pomi.dk...
  • Page 2: Table Of Contents

    Contents WRAP 5 WRAPPER ..........................3 SAFETY INSTRUCTIONS ........................3 EU DECLARATION OF ACCORDANCE ..................... 4 MACHINE IDENTIFICATION ....................... 5 BEFORE START ............................5 CHANGE FROM TRANSPORT TO WRAPPING ................6 WRAPPING ............................... 7 7.1..................... 8 OSITIONING OF BALES BEFORE WRAPPING 7.1.1.
  • Page 3: Wrap 5 Wrapper

    1. Wrap 5 Wrapper Congratulation - You have chosen a line wrapper machine. It can be used for wrapping straw. If used to anything else you must have a written authorization from the manufacturer. A tube of foil is made then the bales are entered and put on the ground. The pusher arms push the machine forward so that space is made for more bales.
  • Page 4: Eu Declaration Of Accordance

    3. EU DECLARATION OF ACCORDANCE Manufacturer: POMI Industri ApS Abildvadvej 5, Thorup DK-9610 Nørager Tel. +45 98552000 Company Hereby declares that Machine: Wrapper machine Make type, series no., year a) is manufactured in accordance with decisions made in the Council’s Directive of 14 June 1989 about mutual approach of the member states’...
  • Page 5: Machine Identification

    4. Machine identification When ordering parts please inform the serial number. You will find the serial no. on the left side of the hydraulic tank as shown below. The motor no. is found on the left side of the motor. Serial no.___________________ Motor no.___________________ 5.
  • Page 6: Change From Transport To Wrapping

    6. Change from transport to wrapping  Position the machine with a tractor or telescopic loader in correct direction, on the stack position.  Disconnect the tractor and remove the cable.  Push the emergency stop.  Start motor according to instruction for motor. ...
  • Page 7: Wrapping

    7. Wrapping Start by making a tube of plastic. The plastic ends are fixed to the two round bars positioned on one of the pushers until it is no longer necessary. Run the foil up till the plastic is at the ends of the spears. The start sensor must be adjusted so that the machine starts when the last bale is lifted on.
  • Page 8: Positioning Of Bales Before Wrapping

    7.1. Positioning of bales before wrapping 7.1.1. Square bales 24 metres = 100 bales Big bales: 120 x120 x 240 cm. 2 bales on top of each other and 75 cm between the stacks. 24 metres = 210 bales Mini-big bales: 80 x 90 x 240 cm. 3 bales on top of each other and 75 cm between the stacks. 24 metres = 180 bales Class bales: 70 x 120 x 240 cm.
  • Page 9: Round Bales

    7.1.2. Round bales 24 metres = 100 bales Round bales ø 135 cm: Round bales are stacked in one layer two next to each other and there must be 75 cm between the stacks. 24 metres = 180 bales Round bales ø 180 cm Round bales are stacked in one layer two next to each other and 75 cm between stacks.
  • Page 10: Finishing

    8. Finishing When the foil tube has a length so that the last bales are in position, some extra rounds are wrapped at the end of the foil tube to give a strong edge. Then the plastic is torn. The machine is set to run by itself so that it runs as free of the stack as possible.
  • Page 11: Machine Operations

    Machine operations: 10.1. Electrical box Emergency stop By pushing this switch in all operations stop on the electrical box and to switch on it must be switched out of lock-position and the required operation must be reactivated. Ready When the emergency stop is released the lamp ready is lid.
  • Page 12: Hydraulic System

    10.3. Hydraulic system In front of the machine, 2 or 4 hydraulic handles are positioned: 1) is to adjust the height of the tower in the front. 2) is to adjust the height of the tower in the rear end. 3) is to raise the support in the front.
  • Page 13: Foil Guard

    10.4. Foil guard A foil guard is positioned in one corner, it consists of a bar sensoring the wrapped foil, if only 1 layer plastic is used. If the foil tears the bar falls down and activates a switch that stops the machine.
  • Page 14: Maintenance

    Maintenance  Clean the motor box daily or when needed, to avoid fire.  Bearings are lubricated daily with grease.  Pusher arms and chains are lubricated with chain oil. When replacing chains, use only original chains.  After 1st day, the wheels are adjusted, after that twice a year. Tightening moment = 100 Nm 12.1.
  • Page 15: Good Advice

    Good advice  It is perferred that the wrapping is made either horizontal or upwards.  Considering the wind it is best to operate in direction west or north.  In order to the foil not slipping in the bond, it is best to wrap in calm weather.
  • Page 16: Extra Equipment

    Extra equipment 14.1. Hydraulic lift of tower The tower is raised at the front and rear end alternately so that the chains are tightened. When the tower is run down, 4 bolts are used to fix the chains. See to it that the pre-stretchers are positioned as illustrated and not on the two vertical surfaces.
  • Page 17: Foil Roller Basket

    14.2. Foil roller basket The basket contains app. 15 rollers and 1 roller of end plastic. The inner measurement of the basket: 1000 x 1100 mm - Height = 620 mm It is loaded on the machine with a forklift truck.
  • Page 18: Problems

    Problems Problem Solution Machine − Change the fuel filter Motor pulls too bad. − Clean air filter − Check the hydraulic pressure (120 bar). The pusher arms cannot push the bales.. − Check that the chain rails have the correct Carrier link breaks distance W = 1177 mm −...
