- Page 1 EN ver 1.0_2019 INSTALLATION GUIDE SC SERIES MECHANICAL LOAD 5,400 Pa HAIL IMPACT TEST 25 m/s ENHANCED PID ENVIRONMENT RESISTANCE Copyright 2019. S-Energy all rights reserved.
- Page 2 Rev history edition 2019.09.23 S-Energy PV Module Installation Manual...
-
Page 3: Table Of Contents
2. Safety Precautions 3. Environmental Considerations 4. Caution before Installation 5. Caution when Installed 6. Electrical Installation 7. Grounding Method 8. Mechanical Installation 9. Maintenance 10. Cleaning Instructions 11. Detailed Module Specification 12. Installation Instructions S-Energy PV Module Installation Manual... -
Page 4: Before Use
For the detailed quality warranty policy of the product, please refer the quality assurance provided by S-Energy Co., Ltd.. When the contents of this manual conflict with the quality assurance, the quality assurance takes precedence. -
Page 5: Safety Precautions
PV module should be installed by a two person team. the frame areas when moving/installing. And do not Be careful when handling because the shock may allow direct shock or hit to the module. cause damage or low performance. S-Energy PV Module Installation Manual... -
Page 6: Environmental Considerations
6 times the cable diameter when wiring.] Cable wiring securely fixed to prevent shaking Do not touch with wet hands or equipment, in the wind with cable tie. which can result in electric shock. [However, consider summer/winter thermal expansion/contraction.] S-Energy PV Module Installation Manual... -
Page 7: Caution Before Installation
If it is installed at a different angle or direction, it may adversely affect an annual generation capacity. In case of horizontal installation, S-Energy recommends regular cleaning to remove dust on the surface. PV module generates the voltage even without load connection. So, be careful for sparks especially when assembling / disassembling PV module. -
Page 8: Electrical Installation
90 ℃. ] Use copper wire for all wiring. · Diameter: At least larger than minimum 12AWG. [4mm [wiring diameter should confirm the local regulation, and S-Energy Co., Ltd. recommends the customer use wires with a diameter larger than the above number at minimum.] · Module configuration[Series wiring] [{(Min Temp ℃... -
Page 9: Grounding Method
Such devices, where supplied with the module and evaluated through the requirements in UL 1703, may be used for grounding connections in accordance with the instructions provided with the module. S-Energy PV Module Installation Manual... -
Page 10: Mechanical Installation
- The heating properties of extremely high gas or vapor (filling stations, gas cylinders, paint, etc.) nearby flame or combustible materials. Mounting Grounding Hole Hole Drainage Hole Junction [2.16] [3.54] 20.5 [8.07] < Back View > Unit: mm 120 Cells Series Position 1002 1684 1660 Module thickness 1000 Cable length S-Energy PV Module Installation Manual... - Page 11 In case of failure to use the accessories recommended by S-Energy Co., Ltd., it may affect the long term reliability of the module, and S-Energy Co., Ltd. do not take any responsibility for life-shortening of the module resulting from such use.
-
Page 12: Maintenance
※ Cleaning Instructions The front glass of the modules produced in S-Energy Co., Ltd. is using the general low iron glass and the ARC glass to minimize with light reflection. Cleaning time is taking into account the thermal shock and power generation, please proceed early in the morning and cloudy weather. -
Page 13: Detailed Module Specification
Value Temperature coefficient of I 0.060 % / ℃ Temperature coefficient of V -0.300 % / ℃ Temperature coefficient of power -0.390 % / ℃ NMOT 45±2 ℃ 20℃ ; Irradiance 800W/m ; Wind 1m/s) S-Energy PV Module Installation Manual... -
Page 14: Installation Instructions
Installation Instructions 1) Hole installation method 2) Location and method of clamp installation S-Energy PV Module Installation Manual... - Page 15 For example: --- 18-24 The mounting details are shown in the following figures. Failure to remove accumulated snow on the PV module for long time may cause long-term power reduction. CAUTION S-Energy PV Module Installation Manual...
- Page 16 S-Energy Co., Ltd. www.s-energy.com/en ｜ H E A D O F F I C E Fl3, MiraeAsset Tower, 20, Pangyoyeok-ro 241 beon-gil Bundang-gu, Seongnam, Gyeonggi-do, 13494, Republic of KOREA C O N T A C T ｜ Tel. +82-70-4339-7100 Fax.
