Hotpoint HTN17BBTL Dimensions And Installation Information

HTN17BBT – Hotpoint
®

Front View

B
A
Specification Created 4/09
410466
'94 TMNF Refer
ENERGY STAR 16.6 Cu. Ft. Top-Freezer Refrigerator
®
C
D
Top View
H
G
E
F
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers'
standards.
Height to top of hinge (in.) A
Height to top of case (in.) B
Height to mid-freezer (in.)
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
Width (in.) G
Width with door open 90° with door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
Note: Before installing, consult installation instructions packed with product
for current dimensional data.
Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your left and the
hinges are on your right.
All Top-Freezer No-Frost Left-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your right and the
hinges are on your left.
Listed by
Underwriters
Laboratories
64-3/4
64-1/4
54-3/8
25-7/8
29-1/8
29-1/8
54-7/8
28
28-5/8
3/4
1
1
As an EnErgy STAr ®
partner, gE has determined
that this product meets the
EnErgy STAr guidelines
for energy efficiency.
