Safety Information
Connecting Electricity . . . . . . . . . . 3
Safety Precautions . . . . . . . . . . . . . . 2
Operating Instructions
Automatic Icemaker . . . . . . . . . . . .8
Care and Cleaning . . . . . . . . . . 9, 10
Shelves . . . . . . . . . . . . . . . . . . . . .5, 6
Storage Drawers . . . . . . . . . . . . . .6, 7
Temperature Controls . . . . . . . . . . .4
Preparing to Install
the Refrigerator . . . . . . . . . . . . . . 11
Reversing the Door Swing . . . 16-22
Water Line Installation . . . . . . 12-16
Troubleshooting Tips
Before You Call
For Service . . . . . . . . . . . . . . . .24, 25
Normal Operating Sounds . . . . . .23
Consumer Support
Consumer Support . . . . Back Cover
Product Registration . . . . . . . . 29, 30
Warranty . . . . . . . . . . . . . . . . . . . . 31
Write the model and serial numbers here:
Model #__________________________
Serial # __________________________
You can find them on a label on the upper
left side of the fresh food compartment.
Owner's Manual and
Installation Instructions
16, 17, 18
162D6736P010 39-60454 01-06 JR
Advertisement
Table of Contents
Related Manuals for Hotpoint HTS16BBS - 15.7 cu. Ft. Top-Freezer Refrigerator
Summary of Contents for Hotpoint HTS16BBS - 15.7 cu. Ft. Top-Freezer Refrigerator
-
Page 1: Table Of Contents
Safety Information Owner’s Manual and Connecting Electricity ..3 Installation Instructions Extension Cords ....2 Safety Precautions ....2... -
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! Use this appliance only for its intended purpose as described in this Owner’s Manual. SAFETY PRECAUTIONS When using electrical appliances, basic safety precautions should be followed, including the following: This refrigerator must be properly installed In refrigerators with automatic icemakers, and located in accordance with the Installation avoid contact with the moving parts of the... -
Page 3: How To Connect Electricity
WARNING! HOW TO CONNECT ELECTRICITY Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, this appliance must be properly grounded. The power cord of this appliance is equipped This provides the best performance and also... -
Page 4: Control Settings
About the temperature control dial. Turning the dial to 0 stops cooling in both compartments—fresh food and freezer. It does not shut off power to the refrigerator. Control Settings Temperature Control Dial The temperature control dial has nine settings plus 0. 1 is the warmest. 9 is the coldest. At first, set the dial at 5. -
Page 5: Models
About the fresh food compartment shelves. www.Hotpoint.com Shelf supports at various levels allow you to custom-space your shelves. Not all features are on all models. Half-Width Shelves One end of the shelf rests on a molded NOTE: The shelf to the right of the track is 2 Lift up and out side-wall support;... - Page 6 About the freezer compartment shelves. Some models have an ice-tray shelf and some have a full-width step shelf. Ice-Tray Shelf Plug Supports To remove the ice-tray shelf, lift the left side of the shelf off its supports, then pull the shelf to the left to free it of the plug supports.
- Page 7 About storage drawer and cover removal. www.Hotpoint.com Not all features are on all models. Adjustable Humidity Drawer (on some models) Slide the control all the way to the Slide the control all the way to the LOW HIGH setting to provide high humidity setting to provide lower humidity levels recommended for most vegetables.
-
Page 8: Automatic Icemaker
About the automatic icemaker. A newly-installed refrigerator may take 12 to 24 hours to begin making ice. Automatic Icemaker (on some models) Power Switch Icemaker The icemaker will produce seven cubes Throw away the first few batches of ice per cycle—approximately 100–130 cubes to allow the water line to clear. -
Page 9: Care And Cleaning
Care and cleaning of the refrigerator. www.Hotpoint.com Cleaning the Outside The door handles and trim (on some Do not wipe the refrigerator with a soiled dish cloth or wet towel. These may leave a residue models). Clean with a cloth dampened with soapy water. - Page 10 Care and cleaning of the refrigerator. Behind the Refrigerator Be careful when moving the refrigerator When pushing the refrigerator back, make sure away from the wall. All types of floor you don’t roll over the power cord or icemaker coverings can be damaged, particularly supply line (on some models).
-
Page 11: Before You Begin
Installation Refrigerator Instructions Models 16, 17, 18 If you have questions, call 1.800.GE.CARES www.Hotpoint.com visit our Website at: BEFORE YOU BEGIN CLEARANCES Allow the following clearances for ease of installation, Read these instructions completely and carefully. proper air circulation and plumbing and electrical IMPORTANT –... -
Page 12: Installation Instructions
Installation Instructions INSTALLING THE WATER LINE BEFORE YOU BEGIN WHAT YOU WILL NEED Recommended copper water supply kits are WX8X2, WX8X3 or WX8X4, depending on the amount of tubing you need. Approved plastic water supply lines are refrigerator tubing kits WX08X10002, WX08X10006, WX08X10015 and WX08X10025. - Page 13 Installation Instructions Install the shutoff valve on the nearest frequently used WHAT YOU WILL NEED (CONT.) drinking water line. • A water supply kit (containing tubing, shutoff valve SHUT OFF THE MAIN WATER and fittings listed below) is available at extra cost from your dealer or from Parts and Accessories, SUPPLY 1.888.261.3055.
-
Page 14: The Refrigerator
Installation Instructions INSTALLING THE WATER LINE (CONT.) FASTEN THE SHUTOFF VALVE CONNECT THE TUBING TO THE VALVE Fasten the shutoff valve to the cold water pipe with the pipe clamp. Place the compression nut and ferrule (sleeve) for copper tubing onto the end of the tubing and Pipe Clamp connect it to the shutoff valve. -
Page 15: Shutoff Valve
Installation Instructions CONNECT THE TUBING CONNECT THE TUBING TO THE TO THE REFRIGERATOR REFRIGERATOR (CONT.) Fasten the tubing into the clamp provided to NOTES: hold it in a vertical position. You may need to • Before making the connection to the refrigerator, pry open the clamp. -
Page 16: Reversing The Door Swing
Installation Instructions INSTALLING THE WATER LINE (CONT.) PLUG IN THE REFRIGERATOR START THE ICEMAKER On power switch models, set the icemaker power Arrange the coil of tubing so that it does not vibrate switch to the l (on) position. On feeler arm models, against the back of the refrigerator or against the move the feeler arm to the ON (down) position. -
Page 17: Before You Start
Installation Instructions REMOVE THE FREEZER DOOR BEFORE YOU START (CONT.) 1.1 Unplug the refrigerator from its electrical outlet. 2.2 With a 5/16″ hex-head socket driver, remove the screws that hold the top hinge to the cabinet. 1.2 Empty all door shelves, including the dairy compartment. -
Page 18: Remove The Freezer Door
Installation Instructions REVERSING THE DOOR SWING (CONT.) REMOVE THE FREEZER DOOR REMOVE THE FRESH FOOD (CONT.) DOOR (CONT.) 2.6 Transfer the 2 screws from the opposite side of 3.4 Set the door outside-up on a non-scratching the cabinet to the screw holes vacated by the surface. -
Page 19: Reversing The Door Handles
Installation Instructions REVERSING THE HARDWARE REVERSING THE DOOR HANDLES 4.1 Remove the base grille (if your refrigerator has 5.1 Transfer fresh food door handle one) by pulling it straight out. 5.1.1 Remove the bottom cap by pushing it toward the bottom of the door, and remove the screw underneath. - Page 20 Installation Instructions REVERSING THE DOOR SWING (CONT.) REVERSING THE DOOR HANDLES 5.2 Transfer door stop (cont.) (CONT.) 5.2.2 Move any screws from the left end to the right end. 5.1 Transfer fresh food door handle (cont.) Right Side 5.1.4 With tape-tipped putty knife or thin- blade screwdriver, pry out the plug button from the hinge hole on the left side of the door and insert it into the...
- Page 21 Installation Instructions 5.4 Transfer Freezer Door Handle 5.4 Transfer Freezer Door Handle (cont.) 5.4.1 Remove the screw holding the handle to the 5.4.4 Transfer the door stop as shown on the top of the door and the two screws holding preceding page.
-
Page 22: Rehanging The Doors
Installation Instructions REVERSING THE DOOR SWING (CONT.) REHANGING THE DOORS REHANGING THE DOORS (CONT.) 6.1 Rehang the fresh food door 6.2 Rehang the freezer door 6.1.1 Lower the fresh food door onto the 6.2.1 Lower the freezer door onto the center bottom hinge pin. -
Page 23: Normal Operating Sounds
Normal operating sounds. www.Hotpoint.com Newer refrigerators sound different from older refrigerators. Modern refrigerators have more features and use newer technology. Do you hear what I hear? These sounds are normal. HUMMM... WHOOSH... The new high efficiency compressor may run faster and longer than your old refrigerator and you may You may hear the fans spinning at high speeds. -
Page 24: Before You Call For Service
Before you call for service… Troubleshooting Tips Save time and money! Review the charts on the following pages first and you may not need to call for service. Problem Possible Causes What To Do Refrigerator does not Refrigerator in defrost cycle. •... - Page 25 Problem Possible Causes What To Do Automatic icemaker •On power switch models, set the power switch to the Icemaker power switch does not work I (on) position. On feeler arm models, move the feeler is not on. (on some models) arm to the ON (down) position.
