Page 1: Condensing Unit
Hoshizaki America, Inc. “A Superior Degree of Reliability” www.hoshizaki.com Condensing Unit Serenity Series Model SRK-7H PARTS LIST Number: 71271 Issued: 5-9-2007... -
Page 2: Table Of Contents
CONTENTS Auxiliary Codes ... 3 Note About Ordering Parts ... 3 Material Abbreviations ... 4 A. Condensing Unit ... 5 B. Refrigeration Circuit ... 7 C. Control Box Assembly ... 10 D. Label Location ... 11 E. Accessories ... 1... -
Page 3: Auxiliary Codes
Auxiliary Codes SRK-7H April 007 Auxiliary Code Breakdown Designates the year. "K" indicates the year 000. Years progress or regress in alphabetical order. "J" is 1999, "L" is 001, "M" is 00, and so on. The letters "I" and "O" were skipped. -
Page 4: Material Abbreviations
Material Abbreviations ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene... -
Page 5: Condensing Unit
A. Condensing Unit SRK-7H 19 19a 7b 7c 8 11 11a 1 1a 15 15a 14 14a... - Page 6 Title: A. Condensing Unit Model: SRK-7H Index Description Refrigeration Circuit T Screw Control Box Assembly T Screw Label Location Base Junction Box T Screw Shroud T Screw Shroud (C) T Screw Rear Panel T Screw Fan Motor Bracket Hex Bolt Assembly (LF)
-
Page 7: Refrigeration Circuit
B. Refrigeration Circuit SRK-7H 7 7a 8 10 10a 11 11a 1b 1c 9 9a... - Page 8 Title: B. Refrigeration Circuit Model: SRK-7H Index Description Compressor Grommet Spacer Bolt Assembly Condenser T Screw Suction Accumulator Spacer - Accumulator Hex Bolt Assembly (LF) Receiver Tank Hex Bolt Assembly (LF) Valve Body - Line Valve Body - Hot Gas...
- Page 9 Title: B. Refrigeration Circuit Model: SRK-7H Index Description Bracket - Shutoff Valve Shutoff Valve (access) T Screw Coupling (Male) (liquid line) Tube Holder - L Coupling (Male) (suction line) Crankcase Heater Material or Model Number Part Number GS; See A.
-
Page 10: Control Box Assembly
C. Control Box Assembly SRK-7H Title: C. Control Box Assembly Model: SRK-7H Index Description Control Box Capacitor - Start Capacitor - Run Strap T Screw Starter (Relay) T Screw Capacitor T Screw Terminal Block Pan Head Screw Magnetic Contactor T Screw... -
Page 11: Label Location
D. Label Location SRK-7H Title: D. Label Location Model: SRK-7H Index Description Label - Penguin - HA (R) Caution Label (F) Caution Label (H) Wiring Label Nameplate Instruction Sheet Tag Warning: Electrical Connection Label - 404A Material or Model Number Part Number... -
Page 12: Accessories
E. Accessories SRK-7H Title: E. Accessories Model: SRK-7H Index Description Hex Head Bolt w/ Washer Hex Nut Material or Model Number Part Number 3A3716G01 8×16 SS 7B030816 M8 SS 7N1-0800 1a 1b Required Number...
