Page 1 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1 Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a Clss B digital device, pursuant to part 15 of the FCC Rules. These limit are designed to provide reasonable protection against harmful interference in a residential installation.
Page 2: Table Of Contents
CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지2 Table of Contents 1. Introduction Overview Main Features Motherboard Layout 2. Installation Check List Installation Steps Set Jumpers 1. Clear CMOS RAM 2. CPU Core : Bus Frequency Multiple Installing the System Memory 1. Adding Memory 2.
Page 3 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지3 7. Secondary Fan connector 2-12 8. Front Panel Switch connector 2-12 9. Modem connector 2-12 10. CD input connectors 2-12 11. Power Switch connector 2-12 12. ATX Power Supply connector 2-13 External Connectors 2-14 3. Built-in BIOS Setup Program Starting SETUP Standard CMOS Setup BIOS Features Setup...
Page 4: Introduction
CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-1 CB647M-LX/EX User's Manual 1. Introduction Overview CB647M-LX/EX motherboard integrates the latest advances in pro c e s s o r, m e m o r y, and I/O technologies into a micro ATX form factor(244 x 190mm) that combines performance, flexibility, and easy of use into high integrated capable of meeting a variety of price/performance levels.
Page 5: Main Features
CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-2 1. Introduction Main Features 1. Processor : ● Single Intel Slot 1 connector ● Support to Intel Pentium II - 233/266/300/333 MHz pro c e s s o r ● Support to Intel celeron 266/300/300A/333MHz pro c e s s o r ●...
Page 6 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-3 CB647M-LX/EX User's Manual ● R e a l - Time Clock ● 16-bit counters/timers based 82C54 2-3. ITE 8671F Super I/O Contro l l e r ● Serial ports : Two 16550 compatible UARTs ● Parallel port : Standard / EPP / ECP mode support ●...
Page 7 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-4 1. Introduction 5. Expansion Slots : ● Two 16-bit ISA slots with 100% ISA compatible function.(1 share d ) ● Two 32-bit PCI slots all support PCI master. ▶ PCI specification version 2.2. ● One 32-bit A.G.P slot support up to 528MB/s transfer rate ▶...
Page 8 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-5 CB647M-LX/EX User's Manual 11. USB Connector : ● P rovide the 2 channel USB port. ● Fully supports Universal Host Controller Interface(UHCI) and uses UHCI-compatible software drivers. The 5V lines to these connectors are protected with a poly switch circ u i t , that, like a self-healing fuse, reestablishes the connection after over- c u r rent condition is re m o v e d .
Page 9: Motherboard Layout
CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-6 1. Introduction Motherboard Layout Figure 1-1. CB647M-LX/EX Motherboard Layout 1 - 6...
Page 10: Installation
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-1 CB647M-LX/EX User's Manual 2. Installation This Chapter provides information on how to install and configure the C B 6 4 7 M - L X / E X m o t h e r b o a rd . Check List The standard packing of the C B 6 4 7 M - L X / E X should include : CB647M-LX/EX motherboard...
Page 11: Set Jumpers
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-2 2. Installation Set Jumpers Serveral hard w a re settings are made through the use of jumper cap to connect jumper pins on the motherboard. See motherboard layout on page 1-5 for location of jumpers. The jumper settings will be described numerically such as '1-2', '2-3' or 'On(Short)', 'Off ( O p e n ) ' .
Page 12: Installing The System Memory
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-3 CB647M-LX/EX User's Manual C P U C l o c k H o s t J P 6 J P 7 J P 8 J P 9 F r e q . M u l t i p l i e r C l o c k 2 3 3 M H z 3 .
Page 13: Installing And Removing Dimms
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-4 2. Installation D I M M T O TA L D I M M 1 D I M M 2 18 M B 18 M B D I M M 1 + D I M M 2 The combination of memory 11 6 M B 11 6 M B...
Page 14: Installing The Cpu
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-5 CB647M-LX/EX User's Manual Installing the CPU The C B 6 4 7 M - L X / E X is designed to support single Pentium II processor or c e l e ron pro c e s s o r. The Pentium II processor comes installed in a Single Edge Contact Cartridge (SECC) that connects into “Slot 1”...
Page 15 CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-6 2. Installation Follow the steps below to install the URM : 1. Locate the four Retention Base holes (near each end of the Slot 1 socket). Place the URM Body over each end of the Slot 1 connector. 2.
Page 16: Installing A Cpu
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-7 CB647M-LX/EX User's Manual 2. Installing a CPU Follow the steps below to install the Pentium II pro c e s s o r : 1. Locate the Slot 1 connector. 2. If you are installing the boxed version of the Pentium II pro c e s s o r, follow the instructions in the section “3.
Page 17: Cpu Installation Overview
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-8 2. Installation CPU Installation Overview CPU Installation O v e r v i e w 1. Mount the URM for the CPU. 2. Mount the (optional) heatsink support base onto the system board. 3. Slide the CPU into the U R M .
Page 18: Installing The Cpu(Boxed Version)
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-9 CB647M-LX/EX User's Manual 3. Installing the CPU (Boxed version) A boxed version of the CPU is off e red through Intel. This packing uses an active cooling fan. The mounting hard w a re is described below. For detailed i n s t ructions, please refer to the documentation that is supplied with your C P U .
Page 19: Installing The Celeron Processor
CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-10 2. Installation Installing the celeron processor 1. Installing the URM Installing the URM for celeron processor is same as Installing the URM for Pentium-II pro c e s s o r. 2. Installing a CPU Follow the steps below to install the celeron pro c e s s o r.
Page 20: Installing Cables
CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-11 CB647M-LX/EX User's Manual Installing Cables 1. CPU Fan connector (J27) If you are installing Pentium-II or celeron processor with fan, you can use this header to connect the CPU’s fan cable (3-pin or 2-pin) 2. Primary / Secondary IDE connectors (J18 / J19) These connectors support the provided 40-pin ribbon cable.
Page 21: Internal Modem Ring Connector
CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-12 2. Installation 6. Internal Modem Ring connector (J24) This connector support internal modem ring wake-up function. If you use this function, connect 3-pin cable between this connector & your m o d e m . 7.
Page 22 CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-13 CB647M-LX/EX User's Manual This connector is used to provide a way of the user to turn the system on. Connect it to the power on push button on the front panel. < N o t e > In order to prevent the system from shut down by mistake, the CB647- L X / E X motherboard provides one optional item of the BIOS setup (refer to “3-4 Power Management Setup”).
Page 23: External Connectors
CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-14 2. Installation External Connectors 1. PS/2 Keyboard & Mouse Connector (J3) The CB647M-LX/EX provides one PS/2 keyboard and one PS/2 mouse c o n n e c t o r. Refer to the Figure 2-2 for the direction of keyboard (mouse) cable to install on keyboard (mouse) connector.
Page 24 CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-15 CB647M-LX/EX User's Manual L i n e - i n - Connect this port with cassette re c o rd e r, DAT or CD-Player. It can do playback & re c o rd i n g Line-out - Connect speaker or external AMP M I C - Mic input port MIDI/JOY STICK - Connect MIDI Kit or Joy stick...
Page 25: Built-In Bios Setup Program
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-1 3. Built-In BIOS Setup Program 3. Built-In BIOS Setup Program This chapter contains information about: How the SETUP program allows you to configure the functions and devices of your computer How to configure each item on the SETUP Menus B e f o re the computer can operate, it must know what devices are installed in it.
Page 26 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-2 CB647M-LX/EX User's Manual Accessing SETUP When Powering Up the System To access the SETUP program when powering up the system, turn the computer power on. The system BIOS will first test the system components and then display a message similar to the following : Press <DEL>...
Page 27 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-3 3. Built-In BIOS Setup Program Accessing SETUP Menus SETUP provides access to primary menus from which you modify the system configuration. SETUP always displays the Main Menu when you start the program. Primary menus include : S TANDARD CMOS SETUP- This option allows users to check or modify the basic system configuration.
Page 28 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-4 CB647M-LX/EX User's Manual POWER MANAGEMENT SETUP- This option allows users to set the power saving status for reducing the power consumption. PNP/PCI CONFIGURATION SETUP- This option is used to set the various system function and internal addresses of the PCI devices. Allows users to configure system IRQ and DMA to PCI/ISA PnP or Legacy ISA .
Page 29 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-5 3. Built-In BIOS Setup Program IDE HDD AUTO DETECTION- This option can automatically detect the h a rd disk drive type(s) including the number of cylinders and heads, write precompensation time, read/write head landing zone, and number of sectors per track.
Page 30: Standard Cmos Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-6 CB647M-LX/EX User's Manual 3.1 Standard CMOS Setup ROM PCI/ISA BIOS (CB647MLX) S TANDARD CMOS SETUP AWARD SOFTWARE, INC. Data (mm:dd:yy) : Thu, Jun 12 1997 Time (hh:mm:ss) : 17 : 58 : 42 HARD DISKS TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Primary Master : Auto...
Page 31 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-7 3. Built-In BIOS Setup Program Primary Master/Slave, Secondary Master/Slave - Specifies the physical and electronic properties of the standard hard disk drives installed. Relevant specifications include the type, number of cylinders (CYLS), heads (HEAD), write pre-compensation time (PRECOMP), re a d / w r i t e head landing zone (LANDZ), number of sectors per track (SECTO R ) , and HDD mode (MODE).
Page 32: Bios Features Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-8 CB647M-LX/EX User's Manual 3.2 BIOS Features SETUP ROM PCI/ISA BIOS (CB647MLX) BIOS FEATURES SETUP AWARD SOFTWARE, INC. Virus Warning : Disabled Video BIOS Shadow : Enabled CPU Internal Cache : Enabled C8000-CBFFF Shadow : Disabled External Cache : Enabled CC000-CFFFF Shadow...
Page 33 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-9 3. Built-In BIOS Setup Program Quick Power On Self Te s t - Allows the power on self test to run at either a f a s t or a normal speed. The available options are : - Enabled (default) - Disabled Boot Sequence - Selects the drive where the system would search for the...
Page 34 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-10 CB647M-LX/EX User's Manual Typematic Rate Setting - Defines the setting of the keyboard’s typematic rate. The available options are : - Disabled (default) - Enabled Typematic Rate <Char/Sec> - Specifies the key repeat rate, in seconds, of k e y b o a rd character.
Page 35: Chipset Features Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-11 3. Built-In BIOS Setup Program 3.3 Chipset Features Setup ROM PCI/ISA BIOS (CB647MLX) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC. Auto Configuration : Enabled SDRAM CAS latency Time : 3 DRAM Speed Selection : 60ns CPU Warring Temperature : Disabled MA wait State : Slow Current System Temp.
Page 36 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-12 CB647M-LX/EX User's Manual DRAM Speed Selection - Configures the DRAM read/write speed for the maximum performance. The available options are : - 50ns - 60ns(default) MA Wait State - select FAST or SLOW Memory Address bus timing. The available options are : - Slow(default) - Fast...
Page 37 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-13 3. Built-In BIOS Setup Program C P U - To-PCI IDE Posting - When disabled, the Read/Write cycles are t reated as normal I/O write transactions. The available options are : - Enabled(default) - Disabled System BIOS Cacheable - Allows caching of the diff e rent segments where t h e re is system BIOS shadowing.
Page 38 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-14 CB647M-LX/EX User's Manual AGP Aperture Size(MB) - sets to the effective size of the Graphics Aperture used in the particular PAC configuration. The 256MB aperture size is not practical for most applications and there f o re the size must be set to a smaller practical value.
Page 39: Power Management Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-15 3. Built-In BIOS Setup Program 3.4 Power Management Setup ROM PCI/ISA BIOS (CB647MLX) POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. Power Management : User Define Reload Global Timer Events PM Control by APM : Yes IRQ [3-7, 9-15], NMI : Disabled Video Off Method : DPMS...
Page 40 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-16 CB647M-LX/EX User's Manual Video Off After- Turns off screen after selected standby or suspend mode. The available options are : - Suspend - Standby(default) - Doze - N/A Modem Use IRQ - In order to support resume on ring and to be compliant with APM 1.2, this option is re q u i red to be set same IRQ as the modem a d d - i n - c a rd used.
Page 41 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-17 3. Built-In BIOS Setup Program ZZ Active in Suspend - Determines whether to assert the ZZ signal while in suspend mode or not. The available options are : - Disabled(default) - Enabled VGA Active Monitor - Determines whether to reload burst timer while PCI accesses to VGA I/O addresses or the A and B segment video memory ranges or not.
Page 42 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-18 CB647M-LX/EX User's Manual Wake Up On LAN - sets to turn on the system from power off state. The available options are : - Enabled - Disabled(default) IRQ 8 Break Suspend - The available options are : - Disabled(default) - Enabled The item “Reload Global Timer Events”...
Page 43: Pnp/Pci Configuration Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-19 3. Built-In BIOS Setup Program 3.5 PNP/PCI Configuration Setup ROM PCI/ISA BIOS (CB647MLX) PNP/PCI CONFIGURAT I O N AWARD SOFTWARE, INC. PNP OS Installed : Yes PCI IDE IRQ Map To : PCI-AUTO Resources Controlled By : Auto Primary IDE INT# Reset Configuration Data...
Page 44 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-20 CB647M-LX/EX User's Manual Reset Configuration Data- To clear the ESCD data which is stored in flash ROM, please set “Enable”. This is a one short switch. After clearing the ESCD, the BIOS will change the value back to “Disabled”. The available option are : - Disabled(default) - Enabled PCI IDE IRQ Map To- Most of PCI IDE cards are non-PCI compliant.
Page 45: Load Bios Defaults
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-21 3. Built-In BIOS Setup Program 3.6 Load BIOS Defaults In the event of a loss in memory on the configuration SETUP, the user can re s t o re the information on the BIOS by default values. Loading the BIOS defaults provides safety booting of the system.
Page 46 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-22 CB647M-LX/EX User's Manual IDE HDD Block Mode - Determines whether block transfer mode want to use or not. The available options are : - Enabled(default) - Disabled IDE Primary/Secondary Master/Slave PIO - Sets the advanced hard disk PIO transfer mode which effects your hard disk transfer rate.
Page 47 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-23 3. Built-In BIOS Setup Program KB Power On Password - This option will be shown only when the option “Power On Function” is set to ‘Password’. You’ll be asked to input a p a s s w o rd that you want to use as a password . When the power code is disconnected abruptly or power source is disappeared, you should press the Power Button before enter a password that you decide to power-up the system.
Page 48 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-24 CB647M-LX/EX User's Manual UR2 Mode - Determines which type IR module want to use. The available options are : - standard (default) - IrDA 1.0 - ASK IR If users set this options to “Standard”, the “UR2 Duplex Mode” option below will not be shown on the screen.
Page 49: Supervisor Password
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-25 3. Built-In BIOS Setup Program 3.9 SUPERVISOR PASSWORD The SUPER VISOR PASSWORD utility allows you to set, change, and disable the password which is stored in the BIOS. To change the password setting, press <Enter> on the SUPERVISOR PASSWORD option of the main menu and then type the new password .
Page 50: Ide Hdd Auto Detection
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-26 CB647M-LX/EX User's Manual 3.11 IDE HDD Auto Detection The IDE HDD Auto Detection provides auto configuration of the hard drive installed in the system. It supports LBA, Large, and Normal modes. If the system’s hard disk drive has a capacity of over 528MB and supports LBA functions, you may enable either the LBA mode or the Large mode.
Page 51 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-27 3. Built-In BIOS Setup Program After pressing the <Enter> key on this item of the main menu, the display s c reen will show the following scre e n . Once the program detects the type of hard disk installed, it will display the relative information such as the type, cylinders, heads, write pre - c o m p e n s a t i o n , landing zone, number of sectors per track, size and mode.
Page 52 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-28 CB647M-LX/EX User's Manual 3.13 Qutting SETUP After making all modifications in the SETUP program, go to the option “Save & Exit SETUP” then press the <Enter> key. The program will display the following scre e n . P ress <Y>...
Page 53 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-1 4. Audio 4. Audio Overview CB647M-LX/EX motherboard uses Trident 4DWAVE-DX chipset for PCI audio. This PCI audio controller support 64 voice wavetable synthesizer with DLS, AC’97 CODEC, direct music, direct sound, and direct sound 3D. It is compatible with fully dos game, sound blaster, sound blaster pro , windows sound system, and MPU 401.
Page 54 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-2 4. Audio 5. Select the type of driver to install then click next. 6. Then the setup program will install the Audio Station. 1) Click Next button. 4 - 2...
Page 55 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-3 4. Audio 2) Click Yes button. 3) Click Next button 4 - 3...
Page 56 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-4 4. Audio 4) Click Next button. 5) Click Next button. 4 - 4...
Page 57 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-5 4. Audio 6) Click Next button. 7) Click Next button. 4 - 5...
Page 58 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-6 4. Audio 8) Click Finish button 7. After installing Audio Station your system will detect PCI multimedia device, legacy audio, and direct input driver. 8. Click Finish button to complete setup. 4 - 6...
Page 59 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1 Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a Clss B digital device, pursuant to part 15 of the FCC Rules. These limit are designed to provide reasonable protection against harmful interference in a residential installation.
Page 60 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지2 Table of Contents 1. Introduction Overview Main Features Motherboard Layout 2. Installation Check List Installation Steps Set Jumpers 1. Clear CMOS RAM 2. CPU Core : Bus Frequency Multiple Installing the System Memory 1. Adding Memory 2.
Page 61: Quitting Setup
CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지3 7. Secondary Fan connector 2-12 8. Front Panel Switch connector 2-12 9. Modem connector 2-12 10. CD input connectors 2-12 11. Power Switch connector 2-12 12. ATX Power Supply connector 2-13 External Connectors 2-14 3. Built-in BIOS Setup Program Starting SETUP Standard CMOS Setup BIOS Features Setup...
Page 62: Introduction
CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-1 CB647M-LX/EX User's Manual 1. Introduction Overview CB647M-LX/EX motherboard integrates the latest advances in pro c e s s o r, m e m o r y, and I/O technologies into a micro ATX form factor(244 x 190mm) that combines performance, flexibility, and easy of use into high integrated capable of meeting a variety of price/performance levels.
Page 63: Main Features
CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-2 1. Introduction Main Features 1. Processor : ● Single Intel Slot 1 connector ● Support to Intel Pentium II - 233/266/300/333 MHz pro c e s s o r ● Support to Intel celeron 266/300/300A/333MHz pro c e s s o r ●...
Page 64 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-3 CB647M-LX/EX User's Manual ● R e a l - Time Clock ● 16-bit counters/timers based 82C54 2-3. ITE 8671F Super I/O Contro l l e r ● Serial ports : Two 16550 compatible UARTs ● Parallel port : Standard / EPP / ECP mode support ●...
Page 65 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-4 1. Introduction 5. Expansion Slots : ● Two 16-bit ISA slots with 100% ISA compatible function.(1 share d ) ● Two 32-bit PCI slots all support PCI master. ▶ PCI specification version 2.2. ● One 32-bit A.G.P slot support up to 528MB/s transfer rate ▶...
Page 66 CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-5 CB647M-LX/EX User's Manual 11. USB Connector : ● P rovide the 2 channel USB port. ● Fully supports Universal Host Controller Interface(UHCI) and uses UHCI-compatible software drivers. The 5V lines to these connectors are protected with a poly switch circ u i t , that, like a self-healing fuse, reestablishes the connection after over- c u r rent condition is re m o v e d .
Page 67: Motherboard Layout
CB647M-LX/EX(1장) 00.9.18 3:52 PM 페이지1-6 1. Introduction Motherboard Layout Figure 1-1. CB647M-LX/EX Motherboard Layout 1 - 6...
Page 68: Installation
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-1 CB647M-LX/EX User's Manual 2. Installation This Chapter provides information on how to install and configure the C B 6 4 7 M - L X / E X m o t h e r b o a rd . Check List The standard packing of the C B 6 4 7 M - L X / E X should include : CB647M-LX/EX motherboard...
Page 69: Set Jumpers
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-2 2. Installation Set Jumpers Serveral hard w a re settings are made through the use of jumper cap to connect jumper pins on the motherboard. See motherboard layout on page 1-5 for location of jumpers. The jumper settings will be described numerically such as '1-2', '2-3' or 'On(Short)', 'Off ( O p e n ) ' .
Page 70: Installing The System Memory
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-3 CB647M-LX/EX User's Manual C P U C l o c k H o s t J P 6 J P 7 J P 8 J P 9 F r e q . M u l t i p l i e r C l o c k 2 3 3 M H z 3 .
Page 71: Installing And Removing Dimms
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-4 2. Installation D I M M T O TA L D I M M 1 D I M M 2 18 M B 18 M B D I M M 1 + D I M M 2 The combination of memory 11 6 M B 11 6 M B...
Page 72: Installing The Cpu
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-5 CB647M-LX/EX User's Manual Installing the CPU The C B 6 4 7 M - L X / E X is designed to support single Pentium II processor or c e l e ron pro c e s s o r. The Pentium II processor comes installed in a Single Edge Contact Cartridge (SECC) that connects into “Slot 1”...
Page 73 CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-6 2. Installation Follow the steps below to install the URM : 1. Locate the four Retention Base holes (near each end of the Slot 1 socket). Place the URM Body over each end of the Slot 1 connector. 2.
Page 74: Installing A Cpu
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-7 CB647M-LX/EX User's Manual 2. Installing a CPU Follow the steps below to install the Pentium II pro c e s s o r : 1. Locate the Slot 1 connector. 2. If you are installing the boxed version of the Pentium II pro c e s s o r, follow the instructions in the section “3.
Page 75: Cpu Installation Overview
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-8 2. Installation CPU Installation Overview CPU Installation O v e r v i e w 1. Mount the URM for the CPU. 2. Mount the (optional) heatsink support base onto the system board. 3. Slide the CPU into the U R M .
Page 76: Installing The Cpu(Boxed Version)
CB647M-LX/EX(2장) 00.9.18 3:52 PM 페이지2-9 CB647M-LX/EX User's Manual 3. Installing the CPU (Boxed version) A boxed version of the CPU is off e red through Intel. This packing uses an active cooling fan. The mounting hard w a re is described below. For detailed i n s t ructions, please refer to the documentation that is supplied with your C P U .
Page 77: Installing The Celeron Processor
CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-10 2. Installation Installing the celeron processor 1. Installing the URM Installing the URM for celeron processor is same as Installing the URM for Pentium-II pro c e s s o r. 2. Installing a CPU Follow the steps below to install the celeron pro c e s s o r.
Page 78: Installing Cables
CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-11 CB647M-LX/EX User's Manual Installing Cables 1. CPU Fan connector (J27) If you are installing Pentium-II or celeron processor with fan, you can use this header to connect the CPU’s fan cable (3-pin or 2-pin) 2. Primary / Secondary IDE connectors (J18 / J19) These connectors support the provided 40-pin ribbon cable.
Page 79: Internal Modem Ring Connector
CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-12 2. Installation 6. Internal Modem Ring connector (J24) This connector support internal modem ring wake-up function. If you use this function, connect 3-pin cable between this connector & your m o d e m . 7.
Page 80 CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-13 CB647M-LX/EX User's Manual This connector is used to provide a way of the user to turn the system on. Connect it to the power on push button on the front panel. < N o t e > In order to prevent the system from shut down by mistake, the CB647- L X / E X motherboard provides one optional item of the BIOS setup (refer to “3-4 Power Management Setup”).
Page 81: External Connectors
CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-14 2. Installation External Connectors 1. PS/2 Keyboard & Mouse Connector (J3) The CB647M-LX/EX provides one PS/2 keyboard and one PS/2 mouse c o n n e c t o r. Refer to the Figure 2-2 for the direction of keyboard (mouse) cable to install on keyboard (mouse) connector.
Page 82 CB647M-LX/EX(2장) 00.9.18 3:53 PM 페이지2-15 CB647M-LX/EX User's Manual L i n e - i n - Connect this port with cassette re c o rd e r, DAT or CD-Player. It can do playback & re c o rd i n g Line-out - Connect speaker or external AMP M I C - Mic input port MIDI/JOY STICK - Connect MIDI Kit or Joy stick...
Page 83: Built-In Bios Setup Program
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-1 3. Built-In BIOS Setup Program 3. Built-In BIOS Setup Program This chapter contains information about: How the SETUP program allows you to configure the functions and devices of your computer How to configure each item on the SETUP Menus B e f o re the computer can operate, it must know what devices are installed in it.
Page 84 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-2 CB647M-LX/EX User's Manual Accessing SETUP When Powering Up the System To access the SETUP program when powering up the system, turn the computer power on. The system BIOS will first test the system components and then display a message similar to the following : Press <DEL>...
Page 85 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-3 3. Built-In BIOS Setup Program Accessing SETUP Menus SETUP provides access to primary menus from which you modify the system configuration. SETUP always displays the Main Menu when you start the program. Primary menus include : S TANDARD CMOS SETUP- This option allows users to check or modify the basic system configuration.
Page 86 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-4 CB647M-LX/EX User's Manual POWER MANAGEMENT SETUP- This option allows users to set the power saving status for reducing the power consumption. PNP/PCI CONFIGURATION SETUP- This option is used to set the various system function and internal addresses of the PCI devices. Allows users to configure system IRQ and DMA to PCI/ISA PnP or Legacy ISA .
Page 87 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-5 3. Built-In BIOS Setup Program IDE HDD AUTO DETECTION- This option can automatically detect the h a rd disk drive type(s) including the number of cylinders and heads, write precompensation time, read/write head landing zone, and number of sectors per track.
Page 88: Standard Cmos Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-6 CB647M-LX/EX User's Manual 3.1 Standard CMOS Setup ROM PCI/ISA BIOS (CB647MLX) S TANDARD CMOS SETUP AWARD SOFTWARE, INC. Data (mm:dd:yy) : Thu, Jun 12 1997 Time (hh:mm:ss) : 17 : 58 : 42 HARD DISKS TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Primary Master : Auto...
Page 89 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-7 3. Built-In BIOS Setup Program Primary Master/Slave, Secondary Master/Slave - Specifies the physical and electronic properties of the standard hard disk drives installed. Relevant specifications include the type, number of cylinders (CYLS), heads (HEAD), write pre-compensation time (PRECOMP), re a d / w r i t e head landing zone (LANDZ), number of sectors per track (SECTO R ) , and HDD mode (MODE).
Page 90: Bios Features Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-8 CB647M-LX/EX User's Manual 3.2 BIOS Features SETUP ROM PCI/ISA BIOS (CB647MLX) BIOS FEATURES SETUP AWARD SOFTWARE, INC. Virus Warning : Disabled Video BIOS Shadow : Enabled CPU Internal Cache : Enabled C8000-CBFFF Shadow : Disabled External Cache : Enabled CC000-CFFFF Shadow...
Page 91 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-9 3. Built-In BIOS Setup Program Quick Power On Self Te s t - Allows the power on self test to run at either a f a s t or a normal speed. The available options are : - Enabled (default) - Disabled Boot Sequence - Selects the drive where the system would search for the...
Page 92 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-10 CB647M-LX/EX User's Manual Typematic Rate Setting - Defines the setting of the keyboard’s typematic rate. The available options are : - Disabled (default) - Enabled Typematic Rate <Char/Sec> - Specifies the key repeat rate, in seconds, of k e y b o a rd character.
Page 93: Chipset Features Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-11 3. Built-In BIOS Setup Program 3.3 Chipset Features Setup ROM PCI/ISA BIOS (CB647MLX) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC. Auto Configuration : Enabled SDRAM CAS latency Time : 3 DRAM Speed Selection : 60ns CPU Warring Temperature : Disabled MA wait State : Slow Current System Temp.
Page 94 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-12 CB647M-LX/EX User's Manual DRAM Speed Selection - Configures the DRAM read/write speed for the maximum performance. The available options are : - 50ns - 60ns(default) MA Wait State - select FAST or SLOW Memory Address bus timing. The available options are : - Slow(default) - Fast...
Page 95 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-13 3. Built-In BIOS Setup Program C P U - To-PCI IDE Posting - When disabled, the Read/Write cycles are t reated as normal I/O write transactions. The available options are : - Enabled(default) - Disabled System BIOS Cacheable - Allows caching of the diff e rent segments where t h e re is system BIOS shadowing.
Page 96 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-14 CB647M-LX/EX User's Manual AGP Aperture Size(MB) - sets to the effective size of the Graphics Aperture used in the particular PAC configuration. The 256MB aperture size is not practical for most applications and there f o re the size must be set to a smaller practical value.
Page 97: Power Management Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-15 3. Built-In BIOS Setup Program 3.4 Power Management Setup ROM PCI/ISA BIOS (CB647MLX) POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. Power Management : User Define Reload Global Timer Events PM Control by APM : Yes IRQ [3-7, 9-15], NMI : Disabled Video Off Method : DPMS...
Page 98 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-16 CB647M-LX/EX User's Manual Video Off After- Turns off screen after selected standby or suspend mode. The available options are : - Suspend - Standby(default) - Doze - N/A Modem Use IRQ - In order to support resume on ring and to be compliant with APM 1.2, this option is re q u i red to be set same IRQ as the modem a d d - i n - c a rd used.
Page 99 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-17 3. Built-In BIOS Setup Program ZZ Active in Suspend - Determines whether to assert the ZZ signal while in suspend mode or not. The available options are : - Disabled(default) - Enabled VGA Active Monitor - Determines whether to reload burst timer while PCI accesses to VGA I/O addresses or the A and B segment video memory ranges or not.
Page 100 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-18 CB647M-LX/EX User's Manual Wake Up On LAN - sets to turn on the system from power off state. The available options are : - Enabled - Disabled(default) IRQ 8 Break Suspend - The available options are : - Disabled(default) - Enabled The item “Reload Global Timer Events”...
Page 101: Pnp/Pci Configuration Setup
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-19 3. Built-In BIOS Setup Program 3.5 PNP/PCI Configuration Setup ROM PCI/ISA BIOS (CB647MLX) PNP/PCI CONFIGURAT I O N AWARD SOFTWARE, INC. PNP OS Installed : Yes PCI IDE IRQ Map To : PCI-AUTO Resources Controlled By : Auto Primary IDE INT# Reset Configuration Data...
Page 102 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-20 CB647M-LX/EX User's Manual Reset Configuration Data- To clear the ESCD data which is stored in flash ROM, please set “Enable”. This is a one short switch. After clearing the ESCD, the BIOS will change the value back to “Disabled”. The available option are : - Disabled(default) - Enabled PCI IDE IRQ Map To- Most of PCI IDE cards are non-PCI compliant.
Page 103: Load Bios Defaults
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-21 3. Built-In BIOS Setup Program 3.6 Load BIOS Defaults In the event of a loss in memory on the configuration SETUP, the user can re s t o re the information on the BIOS by default values. Loading the BIOS defaults provides safety booting of the system.
Page 104 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-22 CB647M-LX/EX User's Manual IDE HDD Block Mode - Determines whether block transfer mode want to use or not. The available options are : - Enabled(default) - Disabled IDE Primary/Secondary Master/Slave PIO - Sets the advanced hard disk PIO transfer mode which effects your hard disk transfer rate.
Page 105 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-23 3. Built-In BIOS Setup Program KB Power On Password - This option will be shown only when the option “Power On Function” is set to ‘Password’. You’ll be asked to input a p a s s w o rd that you want to use as a password . When the power code is disconnected abruptly or power source is disappeared, you should press the Power Button before enter a password that you decide to power-up the system.
Page 106 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-24 CB647M-LX/EX User's Manual UR2 Mode - Determines which type IR module want to use. The available options are : - standard (default) - IrDA 1.0 - ASK IR If users set this options to “Standard”, the “UR2 Duplex Mode” option below will not be shown on the screen.
Page 107: Supervisor Password
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-25 3. Built-In BIOS Setup Program 3.9 SUPERVISOR PASSWORD The SUPER VISOR PASSWORD utility allows you to set, change, and disable the password which is stored in the BIOS. To change the password setting, press <Enter> on the SUPERVISOR PASSWORD option of the main menu and then type the new password .
Page 108: Ide Hdd Auto Detection
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-26 CB647M-LX/EX User's Manual 3.11 IDE HDD Auto Detection The IDE HDD Auto Detection provides auto configuration of the hard drive installed in the system. It supports LBA, Large, and Normal modes. If the system’s hard disk drive has a capacity of over 528MB and supports LBA functions, you may enable either the LBA mode or the Large mode.
Page 109 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-27 3. Built-In BIOS Setup Program After pressing the <Enter> key on this item of the main menu, the display s c reen will show the following scre e n . Once the program detects the type of hard disk installed, it will display the relative information such as the type, cylinders, heads, write pre - c o m p e n s a t i o n , landing zone, number of sectors per track, size and mode.
Page 110 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지3-28 CB647M-LX/EX User's Manual 3.13 Qutting SETUP After making all modifications in the SETUP program, go to the option “Save & Exit SETUP” then press the <Enter> key. The program will display the following scre e n . P ress <Y>...
Page 111: Overview
CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-1 4. Audio 4. Audio Overview CB647M-LX/EX motherboard uses Trident 4DWAVE-DX chipset for PCI audio. This PCI audio controller support 64 voice wavetable synthesizer with DLS, AC’97 CODEC, direct music, direct sound, and direct sound 3D. It is compatible with fully dos game, sound blaster, sound blaster pro , windows sound system, and MPU 401.
Page 112 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-2 4. Audio 5. Select the type of driver to install then click next. 6. Then the setup program will install the Audio Station. 1) Click Next button. 4 - 2...
Page 113 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-3 4. Audio 2) Click Yes button. 3) Click Next button 4 - 3...
Page 114 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-4 4. Audio 4) Click Next button. 5) Click Next button. 4 - 4...
Page 115 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-5 4. Audio 6) Click Next button. 7) Click Next button. 4 - 5...
Page 116 CB647M-LX/EX(3장) 00.9.18 3:53 PM 페이지4-6 4. Audio 8) Click Finish button 7. After installing Audio Station your system will detect PCI multimedia device, legacy audio, and direct input driver. 8. Click Finish button to complete setup. 4 - 6...
