CB649M-SI User's Manual
Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
i n s t ructions, may cause harmful interference to radio communications.
H o w e v e r, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
i n t e r f e rence by one or more of the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and re c e i v e r.
- Connect the equipment into an outlet on a circuit diff e rent from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party re s p o n s i b l e
for compliance could void the user's authority to operate the equipment.
1 - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB649M-SI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Daewoo CB649M-SI

  • Page 1 ∆‰¿Ã¡ˆ2-1 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    ∆‰¿Ã¡ˆ2-2 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Table of Contents 1. Introduction 1-1. Overview • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 3: Overview

    Instruction 1-1. Overview The CB649M-SI motherboard integrates the latest advances in pro c e s s o r, memory and I/O technologies into an micro - ATX form factor (244 x 205mm) that combines performance, flexibility and ease of use into high integrated capable of meeting a variety of price/performance levels.
  • Page 4: Main Features

    ∆‰¿Ã¡ˆ2-4 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Caution : There is the danger of an explosion if the battery is incorrectly replaced. Replace the battery with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the battery manufacturer's instructions.
  • Page 5 ∆‰¿Ã¡ˆ2-5 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Two 16C550 UART Compatible Serial Ports One IrDA Compatible Port (Internal) 6. Expansion SLOTs • T h ree 32-bit PCI Slots PCI Specification version 2.2 compliant • Two 16-bit ISA Slots 7. Input/Output Ports •...
  • Page 6 ∆‰¿Ã¡ˆ2-6 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 9. FDD • P rovides One 34-pin Boxed Header • Supports 360K/720K/1.2M/1.44M/2.88M floppy drives. 10. Audio Subsystem : • Trident 4DWAVE-DX-1 PCI Audio Contro l l e r 64-voices polyphony wavetable synthesizer supports all...
  • Page 7 ∆‰¿Ã¡ˆ2-7 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 12. Power-On Function • Power Button On • K e y b o a rd Password Power On • Hotkey Power On • PC98 Keyboard Power On 13. Hardware Monitoring • Integrated SiS5595B like LM78 hard w a re monitor...
  • Page 8: Installation

    Device driver CD 2-2. Installation Steps Installing of the CB649M-SI motherboard depends on the type of case what you use. The CB649M-SI motherboard is designed for the micro ATX form factor and must be installed in an ATX or Micro ATX (chassis).
  • Page 9: Set Jumpers

    ∆‰¿Ã¡ˆ2-9 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 2-3. Set Jumpers Several hard w a re settings are made through the use of jumper caps to connect jumper pins (JP) on the motherboard. Refer to motherboard layout on following page. The jumper settings will be described numerically such as [1-2], [2-3] for connect pins 1&2, connect pins 2&3 re s p e c t i v e l y, or...
  • Page 10: Motherboard Layout

    ∆‰¿Ã¡ˆ2-10 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 2-4. Motherboard Layout <Fig. 2-1> System Board Layout Diagram 2 - 3...
  • Page 11: Connectors And Jumpers

    ∆‰¿Ã¡ˆ2-11 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 2-5. Connectors and Jumpers 1. Connectors Description • J1 SB-Link Connector (Option) • J21 Standby 5V(5VSB) Supply Connector • J 2 VGA Connector • J22 Front Panel (LED,S/W) Connector • J3 PS/2 Mouse and Keyboard Connector • J23 Modem RING Connector •...
  • Page 12 ∆‰¿Ã¡ˆ2-12 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Clear CMOS J P 4 N O R M A L 1 - 2 C L E A R 2 - 3 <Table 2-2> Clear CMOS Jumper • nternal SOUND Setting (JP6) This jumper uses for Enable or Disable the onboard Audio chip.
  • Page 13: Install Dram Modules

    CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 2-6. Install DRAM Modules The CB649M-SI motherboard has two 3.3V unbuff e red 64/72-bit, 168-pin DIMM sockets for upto 1 GB of SDRAM memory. 1. Adding Memory If you use FSB 100MHz CPU(future Intel Celeron CPUs), use PC100 SDRAMs and FSB 66MHz CPU(i.e., 333/366/400/433/466MHz CPUs),...
  • Page 14 ∆‰¿Ã¡ˆ2-14 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual N o t e : In case of using the future Intel Celeron CPUs with FSB 100MHz, please use the DIMM satisfied PC100 specifications. The combination of incorrect DIMM and CPU may cause the system malfunction, or system stability pro b l e m s .
  • Page 15: Install The Cpu

    CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 2-7. Install the CPU The CB649M-SI is designed to support a Intel Celeron Pro c e s s o r. The Celeron processor comes installed in a Zero Insertion Force (ZIF) PPGA370 on the motherboard .
  • Page 16: Connect Cable

    4. IR Connector (J17) CB649M-SI provides one connector which can support IrDA (InfraRed Data Association) receiver module. It gives to users IR wireless data exchange d i rectly from mobile computers, printers and PDAs,. etc.
  • Page 17 ∆‰¿Ã¡ˆ2-17 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 5. Wake On LAN (WOL) Connector (J24) This connector supports Wake On LAN function. If you use Wake on LAN function, connect 3-pin cable between this connector and your LAN Card. Signal Name...
  • Page 18 ∆‰¿Ã¡ˆ2-18 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual < FIG. 2-4> Features of Front Panel Connector Signal Name Signal Name PWR_LED 2 PWR_LED1 Sleep LED2 Ground for PWR_LED 1 Suspend/Resume Switch KBLOCK# Ground for S/R SW Ground for KBLOCK Sleep LED 1...
  • Page 19 NOTE : In order to prevent the system from shutting down by mistake, the CB649M-SI motherboard provides one optional item of the BIOS setup ( refer to the Power Management Setup). This item is called Soft-Off by PWR-BUTTON. The function is as follows: Delay 4 sec: 1.
  • Page 20 ∆‰¿Ã¡ˆ2-20 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Signal Name Signal Name +3.3V +3.3V +3.3V -12V Ground Ground PSON#(Power supply remote on/off control) Ground Ground Ground Ground Ground PWRGD(Power Good) +5VSB(Standby for RTC) +12V 11. +5V Standby Supply Connector (J21) This connector can be used to supply power (+5V Stanby) to an add-on card which can work while the system power is out.
  • Page 21 ∆‰¿Ã¡ˆ2-21 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual N O T E : SB-Link The official explanation of SB-Link (as posted on Creative Labs website) is as follows: SB-LINK combines Intel's PC-PCI and "Serialized IRQ" protocols. These technologies can be found in Intel's TX, LX and newer core logic chip sets.
  • Page 22: Connect External I/Os

    < FIG. 2-5> Layout of Back Panels 1. PS/2 Keyboard and Mouse Connector (J3) The CB649M-SI provides one PS/2 keyboard and one PS/2 mouse c o n n e c t o r. Refer to the Fig. 2.5 for the location of keyboard(lower side) and mouse(upper side) cables and install to keyboard and mouse connectors.
  • Page 23 3. Serial Port 1 & Header for Serial Port 2 (J8 & J9) The CB649M-SI provides two sets of high speed serial port. One is ready for serial devices. An optional second serial port is available using a serial port bracket connected from motherboard to an expansion slot.
  • Page 24 ∆‰¿Ã¡ˆ2-24 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 5. Parallel Port (J10) The CB649M-SI provides one set of high speed parallel port. The parallel port supports bi-direction / EPP / ECP modes. Signal Name Signal Name S t ro b e #...
  • Page 25: Audio Subsystem

    CB649M-SI User’s Manual 2-10. Audio Subsystem (Trident 4DWAVE-DX-1) 2-10-1 Overview The CB649M-SI motherboard has built-in Trident 4DWAVE-DX-1 PCI audio c h i p s e t . It is an advanced PCI audio accelerator providing full legacy compatibility, wavetable synthesis, DirectMusic, DirectSound and Dire c t S o u n d 3 D .
  • Page 26 ∆‰¿Ã¡ˆ2-26 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 2-10-2 Audio I/O Features 1. MIDI/Game Port • S t a n d a rd PC joystick port or Midi device. 2. Inputs and Outputs • Line Out • Line In •...
  • Page 27 ∆‰¿Ã¡ˆ2-27 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual < FIG. 2-7> Layout of Back Panels • LINE-OUT Jack (J28) This is line-out for an external speaker or an amplifier. Signal Name S l e e v e G ro u n d...
  • Page 28 ∆‰¿Ã¡ˆ2-28 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual • MIDI/GAME Port (J33) Connect MIDI Kit or Joystick. Signal Name Signal Name P o w e r P o w e r Joystick button 0 Joystick button 2 Joystick X1 Joystick X1...
  • Page 29 ∆‰¿Ã¡ˆ2-29 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual • Front Panel Audio Connector (J32) : Factory Option This connecter can support front panel line-out and mic-in. It is populated the only for OEMs. Signal Name Left, Line-Out G ro u n d...
  • Page 30 ∆‰¿Ã¡ˆ2-30 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual • I n t e r n al SOUND Enable/Disable Jumper (JP6) This jumper allows user to disable internal PCI audio to change a new sound card or somthing. I n t . S O U N D...
  • Page 31 ∆‰¿Ã¡ˆ2-31 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual When system shows you following window then check lower item and Click "Next" Button. Select "Sound, video and game controllers" and Click "Next". 2 - 2 4...
  • Page 32 ∆‰¿Ã¡ˆ2-32 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Then "Have Disk" Button and insert your Driver CD into the CD-ROM d r i v e . B rowse your Driver CD and find Win95 Folder. This may D:\Sound\Drivers\Wi n 9 5 .
  • Page 33 ∆‰¿Ã¡ˆ2-33 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Click "Finish" Button. System will copy files from CD-ROM drive into your Hard disk drive and system also wants to install "Trident Direct Input Driver", then you can install the same way just you have done before .
  • Page 34 ∆‰¿Ã¡ˆ2-34 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 2. Voyetra Installation Run the Setup.exe at the D:\Sound\Setup.exe or D : \ S o u n d \ A p p s \ Vo y e t r a \ S e t u p . e x e This will setup Audio Driver, DirectX and Voyetra audio Utilities.
  • Page 35 ∆‰¿Ã¡ˆ2-35 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual User Information window appears and waits until enter your Name and Company. Click "Next" Button. Follow the system wants you "Next" or "OK" then finally system shows you "Setup Complete" Click "Finish".
  • Page 36 ∆‰¿Ã¡ˆ2-36 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 3. Audio Station Audio Station includes everything you need to run your PC just like a home s t e reo system. An intuitive hard w a re-style interface lets you play and edit...
  • Page 37 ∆‰¿Ã¡ˆ2-37 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual • Audio Station Menu and Functions Buttons Functions D e s c r i p t i o n s Audio Mixer Dispalys or hides Digital Audio Mixer CD Player Dispalys or hides CD Player...
  • Page 38 ∆‰¿Ã¡ˆ2-38 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual You can see information for an Audio CD on the left-hand-side and it dispalys name of Title, Total Tracks and Total Time for playing. • Making Playlist To play CD, you need to edit tracks which you want to hear. i.e., click "Add"...
  • Page 39 ∆‰¿Ã¡ˆ2-39 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 6. Using Wave Player Wave Player can play various digital audio files(.WAV, .VOC) and you can see their waves. Also you can re c o rd input from external devices such as M i c rophone, CD-ROM drive and Cassette re c o rd e r.
  • Page 40: Integrated Vga

    DM1 slot. NOTE : CB649M-SI motherboard provides built-in AGP video contro l l e r. If you need to change video card for your special purpose, use JP3 to disable the internal VGA.
  • Page 41 ∆‰¿Ã¡ˆ2-41 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Internal VGA Setting (JP3) This jumper uses for Enable or Disable the onboard VGA. Int. VGA J P 3 Enable O F F D i s a b l e 2-11-2 Driver Installation SiS620 VGA Drivers can find in Driver CD.
  • Page 42 ∆‰¿Ã¡ˆ2-42 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual Click "Next" Button. You can see three type of installation, such as Typical, Compact and C u s t o m . You should select "Typical" for install everything what system needs.
  • Page 43 ∆‰¿Ã¡ˆ2-43 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual 2. Changing Display Settings To change the Dispaly setting, click "Display" in the Control panel. Select "Setting" tab, then system shows you "Colors" and "Screen are a " . To change Color depth to the other, use Color's tab.
  • Page 44 ∆‰¿Ã¡ˆ2-44 CB649M-SI(1)¿Ø∏Æ 00.5.12 2:17 PM CB649M-SI User’s Manual At Display Modes, also can change Colors and Screen area(Desktop are a ) If your display monitor has shown irregular figures, such as Pincushion, then check and adjust Refresh rate. If your display monitor has shown irregular figures, such as bluish, then check and adjust Gamma Corre c t i o n .
  • Page 45 5. Select Change from the Adapter Type are a . 6. Select Have Disk of Change Display. 7. Place the CB649M-SI Driver CD into the CD-ROM drive. 8. When the "Install from Disk" dialog box appears, type the dire c t o r y storing the drivers and click "OK".
  • Page 46 5. Remove "VGA adapter device" item of Devmgmt [Device Manager on local computer\Devices]. 6. Restart Computer. 7. Place the CB649M-SI Driver CD into the CD-ROM drive. 8. When WindowsNT 5.0 searches a new VGA hard w a re device driver, indicate driver dire c t o r y.
