CB656M-WE(1) 2000.10.17 3:54 PM 페이지1
Overview
CONTENT
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
3
4
8
8
9
10
10
12
12
12
13
13
13
15
15
15
15
15
15
16
17
18
18
18
18
19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB656M-WE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo CB656M-WE

Summary of Contents for Daewoo CB656M-WE

  • Page 1: Table Of Contents

    CB656M-WE(1) 2000.10.17 3:54 PM 페이지1 CONTENT 1. Introduction Overview • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 2 CB656M-WE(1) 2000.10.17 3:54 PM 페이지2 5. Universal Serial Bus Connector • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...

  • Page 3: Introduction

    CB656M-WE motherboard supports not only FSB(Front Side Bus) 66Mhz bus but also FSB 100/133Mhz. Celeron PPGA370 333Mhz~500+Mhz with FSB 66Mhz can be supported for the higher performance level .

  • Page 4: Main Features

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지4 Caution : T h e re is the danger of an explosion if the battery is incorre c t l y replaced. Replace the battery with the same or equivalent type recommended by the manufacture r. Discard used batteries a c c o rding to the battery manufacture r’s instru c t i o n s .
  • Page 5 CB656M-WE(2) 2000.10.17 3:54 PM 페이지5 • FWH interface • LPC interface • AC‘97 2.1 interface • IRQ Contro l l e r 3. system BIOS • Phoenix bios • 4MB FWH • Support PnP,APM,ACPI,DMI2.0 & CD-ROM BOOTING 4. DIMM Memory Socket : •...
  • Page 6 CB656M-WE(2) 2000.10.17 3:54 PM 페이지6 AC‘97 Link for audio and modem CODECs. AC‘97 2.1 Compliant 7. Input/Output Ports • PS/2 Keyboard and PS/2 Mouse Set : P rovide Double Height PS/2 keyboard & PS/2 mouse connector Integrated into ITE8712 LPC I/O •...
  • Page 7 CB656M-WE(2) 2000.10.17 3:54 PM 페이지7 P rovide Line-out,Line-in ,Mic-in Jacks 11. Integrated Graphics Controller Integrated 2D and 3D graphic engine Integrated Graphics Memory Contro l l e r ( D . V.M technology) Integrated hard w a re motion compensate engine 4MB Display Cache.

  • Page 8: Installation

    Device driver CD 1 Serial cable (option) Installation Steps Installing of the CB656M-WE motherboard depends on the type of case you use. The CB656M-WE motherboard is designed for the ATX form factor and must be installed in an ATX chassis.

  • Page 9: Set Jumpers

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지9 1. Set Jumpers 2. Install the System Memory 3. Install the CPU 4. Connect Cables Set Jumpers Several hard w a re settings are made through the use of jumper cap to connect jumper pins on the motherboard. Refer to motherboard layout on following page.

  • Page 10: Clear Cmos Ram

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지10 Wa r n i n g ! Computer motherboards and Add-on cards contain very delicate IC chips. To protect them against damage from static electricity, you should follow some precaution whenever you work on your c o m p u t e r.
  • Page 11 CB656M-WE(2) 2000.10.17 3:54 PM 페이지11 MEMORY VOLTAGE SELECT Memory voltage is fixed to 3.3V M E M O RY J P 6 V O LTA G E 1-2, 3-4 N O R M A L 5 - 6 KEYBOARD VOLTAGE SELECT P a s s w o rd function is available from setting this jumper.

  • Page 12: Install The System Memory

    D i s a b l e 1 - 2 Install the System Memory The CB656M-WE motherboard has two 3.3V unbuff e red 64bit, 168-pin DIMM sockets for up to 512MB(using 128Mb DRAM Technology) of SDRAM memory module. 1. Adding Memory The following is a list of rules to follow when installing DIMMs.

  • Page 13: Install And Remove Dimms

    2. With the DIMM free from the release tabs, lift the memory module up and place in the anti-static bag or package. Installing the CPU The CB656M-WE is designed to support Intel Celeron CPU. 1. Installing a CPU U s e r ’ s M a n u a l...

  • Page 14: Install The Cpu

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지14 To install pro c e s s o r, check the direction of CPU and ZIF socket, lift the lever up to the top, put the CPU onto the socket, and lay down the lever of socket and then lock the lever of socket.

  • Page 15: Connect Cables

    4. IR connectors (J33) CB656M-WE provide connectors which can support Standard IrDA (InfraRed Data Association) receiver module. It gives users IR wireless data exchange d i rectly from mobile computers, printers and PDAs, ...etc.

  • Page 16: Front Panel Switch Connector

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지16 This connector supports Wake On LAN function. If you use Wake On LAN function ,connect 3-pin cable between this connector and your LAN Card . P I N Signal Name +5V Standby G ro u n d W O L 6.

  • Page 17: Power Switch Connector

    < N o t e > In order to prevent the system from shut down by mistake, the CB656M-WE m o t h e r b o a rd provides one optional item of the BIOS setup (refer to “Power S e t u p ”...

  • Page 18: External Connectors

    (mouse) connector. 2. Serial Port COM1 and COM2 (J10 & J11) The CB656M-WE provides two sets of high speed serial port. Each serial port is 16550 UART compatible. One is 9 pin D-sub connector and the other is 10 pin header for optional serial port cable.

  • Page 19: Vga Port

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지19 4.VGA PORT The CB656M-WE Privides VGA port which can support a DDC monitor . 5.Universal Serial Bus(USB) Connector The CB656M-WE provides stacked USB Ports. 6. Audio Jacks The CB656M-WE supports AC97 2.1 Audio. It provides Line-out,Line-in,Mic jacks and MIDI/Game port.

  • Page 20: Installing The Inf Files From Driver Cd

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지20 The files for Windows 95 are designed to work solely with Windows 95 (all versions). The files for Windows 98 are designed to work solely with Windows 98. 1 . I N S TALLING THE INF FILES From Driver CD 1.

  • Page 21: Installing The Vga Driver From Cd-Rom

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지21 2. Close any running applications. You may experience some difficulties if other applications are still ru n n i n g . 3. Enter the directory “Infinst” and Run Setup.EXE. 4. You will be prompted to agree to the license agreement.
  • Page 22 CB656M-WE(2) 2000.10.17 3:54 PM 페이지22 5. A new window appears, prompting either for Windows to search for a device driver or to select one manually. Click the option for “Display a list of all the driver in a specific location, so you can select the driver you want.”...

  • Page 23: Ac97 Audio Wdm Driver Installation

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지23 4.AC97 Audio WDM Driver Installation 1. Click on Start 2. Select settings 3. Select Control Panel 4. Double click on System icon 5. Click on device manager tab 6. Click on View devices by Type button 7.
  • Page 24 CB656M-WE(2) 2000.10.17 3:54 PM 페이지24 15. Select Next 16. Windows 98 should display that the following driver has been found: 82801AA/AB AC’97 Audio Contro l l e r 17. Select Next 18. Select Finish U s e r ’ s M a n u a l...

  • Page 25: Setup

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지25 Setup The SETUP program is a built-in program that allows configuration of functions and devices of the system. This chapter provides information on how the setup program allows you to c o n f i g u re the function and device of your computer and how to configure each item on the setup menus.

  • Page 26: Main Setup Menu

    CB656M-WE(2) 2000.10.17 3:54 PM 페이지26 4. <+>,<-> and the space bar will scroll the current field’s value. 5. To change a value of configuration, repeat the pro c e d u re 2 through 4. 6. If you press<ESC>, the Exit menu will be displayed.
  • Page 27 CB656M-WE(2) 2000.10.17 3:54 PM 페이지27 Phoenix BIOS Setup Utility M a i n A d v a n c e d S e c u r i t y P o w e r B o o t E x i t...
  • Page 28 CB656M-WE(2) 2000.10.17 3:54 PM 페이지28 -System Date This option displays the current system date. Use <+> and <-> keys to change the values. P ress <Enter> to move from the Month to the Date to the Year field. -Legacy Diskette A : / Legacy Diskette B : These options define wether to use the ’A’...

  • Page 29: Advanced Setup Menu

    CB656M-WE(2) 2000.10.17 3:55 PM 페이지29 -Extended Memory Displays the amount of extended system memory detected during bootup. 2. Advanced Setup Menu Use this menu to set the Advanced Features available on your system’s c h i p s e t .
  • Page 30 CB656M-WE(2) 2000.10.17 3:55 PM 페이지30 - P rocessor Serial Number C o n t rols detection of processor Serial Number. (Note : This option would show only if there is pentium Ⅲ p rocessor in your s y s t e m . )

  • Page 31: Security Setup Menu

    CB656M-WE(2) 2000.10.17 3:55 PM 페이지31 • Disabled : Disable the Local Bus IDE adapter. • Primary : Use only the primary Local Bus IDE. • Secondary : Use only the Secondary Local Bus IDE. • Both : Use both Local Bus IDE adapters.
  • Page 32 CB656M-WE(2) 2000.10.17 3:55 PM 페이지32 PhoenixBIOS Setup Utility M a i n A d v a n c e d S e c u r i t y P o w e r B o o t E x i t...
  • Page 33 CB656M-WE(2) 2000.10.17 3:55 PM 페이지33 To clear the current password, just hit <Enter> on New Password and confirm P a s s w o rd.(Maximum five characters can be used for a password . ) - P a s s w o rd on boot If ‘Enabled’, entry of the password is re q u i red to boot up system.

  • Page 34: Power Setup Menu

    CB656M-WE(2) 2000.10.17 3:55 PM 페이지34 (Ctrl + F1/Ctrl + F2/Ctrl + F3/Ctrl + F4) P a s s w o rd : It allows you to power on the system by the password that you e n t e re d .
  • Page 35 CB656M-WE(2) 2000.10.17 3:55 PM 페이지35 -PowerButton Override Specify power button option as Following : Enabled : Use Power Button as the Suspend/Resume Button and Support 4sec Power override. Disabled : Use Power Button as Softoff Button. -Power Savings Specify Power Savings option as following: •...

  • Page 36: Boot Setup Menu

    CB656M-WE(2) 2000.10.17 3:55 PM 페이지36 (Standby Timeout : 16 Minutes, Auto Suspend Timeout : 60Minutes) • Disabled : Turn off Power Management. • Customized : Can define the ‘Standby Timeout’ and ‘Auto Suspend Ti m e o u t ’ .
  • Page 37 CB656M-WE(2) 2000.10.17 3:55 PM 페이지37 PhoenixBIOS Setup Utility M a i n A d v a n c e d S e c u r i t y P o w e r B o o t E x i t Item specific Help Use <...

  • Page 38: Exit Setup Menu

    CB656M-WE(2) 2000.10.17 3:55 PM 페이지38 - H a rd Drive If you have more than one hard drive, selecting “Hard Drive” from the Boot Menu. Select the hard to use for booting by using the up-and-down arro w s .
  • Page 39 CB656M-WE(2) 2000.10.17 3:55 PM 페이지39 PhoenixBIOS Setup Utility M a i n A d v a n c e d S e c u r i t y P o w e r B o o t E x i t...
