Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information -
consumer
.
· We appreciate your commitment to Kohler quality. Please
take a few minutes to review this manual before you start
installation. If you encounter any installation or
performance problems, please don t hesitate to contact us.
Our phone numbers and website are listed on the back
cover. Thanks again for choosing Kohler Company.
ORDERING INFORMATION
PURIST Toilet.............................................................K-3492K
NOTES
DANGER: Risk of electric shock.
before servicing.
WARNING: Risk of electric shock.
circuits protected by Ground-Fault Circuit-Interrupters
(GFCI s) or Earth-Leakage Circuit-Breakers (ELCB s).
'
CAUTION: Risk of hazardous gases.
is not installed immediately, temporarily place a rag in
the floor flange opening.
NOTICE: Follow all local plumbing and electrical codes.
NOTICE:
Receptacles installed in bathrooms to be located at
least 1 meter from a bathtub or shower if practical, but in no
case less than 500 mm.
·
Observe all local plumbing and building codes.
·
Carefully inspect the new toilet for damage.
·
Water and electrical supplies may be wall or floor
mounted. Floor mount supplies are recommended for a
more aesthetic look.
·
There is a wiring schematic on inside of the of the junction
box cover.
WARNING: Risk of electric shock for handwire
installations/through-floor electrical supply:
only to properly-grounded, dedicated 220 VAC, 15A,
50Hz circuit protected by a Class A Ground-Fault
Circuit-Interrupter (GFCI) or Earth-Leakage Circuit-
Breaker (ELCB).
1061926-T01-A
please leave instructions for the
'
Disconnect power
Connect only to
If a new toilet
·
·
·
·
GFCI
'
·
·
·
·
Connect
106 2
324
INSTALLATION INSTRUCTIONS
.............................................................
ELCB
500
220V 15
200131
ã
ã
Copyright Kohler China Ltd., 2006
PURIST
TOILET
K-3492K
-
K-3492K
50
, 2006
