MODULAR CRESCENT CUBER
HOSHIZAKI
MODEL
KM-500MAF
KM-500MWF
KM-500MRF
(FINAL) PARTS LIST
NO.
71153
ISSUED:
NOV. 2, 1999
REVISED: JUNE 26, 2002

Advertisement

loading
Need help?

Need help?

Do you have a question about the KM-500MAF and is the answer not in the manual?

Questions and answers

Related Manuals for Hoshizaki KM-500MAF

Summary of Contents for Hoshizaki KM-500MAF

  • Page 1 MODULAR CRESCENT CUBER KM-500MAF KM-500MWF KM-500MRF (FINAL) PARTS LIST HOSHIZAKI MODEL 71153 ISSUED: NOV. 2, 1999 REVISED: JUNE 26, 2002...

  • Page 3: Material Abbreviations

    ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitritrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene SI.R...

  • Page 4: Ice Cuber Assembly

    KM-500MAF A. ICE CUBER ASSEMBLY J-0, J-1, K-0, L-0, L-1...
  • Page 5 M O D E L K M -5 0 0M A F IN D E X D E S C R IP T IO N N O . R E F R IG E R A T IO N C IR C U IT W A T E R C IR C U IT C O N T R O L B O X A S S E M B L Y T 2 S C R E W...
  • Page 6 M O D E L K M -500M A F IN D E X N O . D E S C R IP T IO N FR O N T P A N E L LO U V E R (B ) B A R R IE R T2 S C R E W TA P P IN G S C R E W ( B LA C K )
  • Page 7 KM-500MWF A. ICE CUBER ASSEMBLY J-0, J-1, K-0, L-0...
  • Page 8 MODEL KM-500MWF TITLE INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONTROL BOX ASSEMBLY T2 SCREW LABEL LOCATION EVAP. CASE BASE FT SCREW FRAME TRUSS HEAD SCREW TRUSS HEAD SCREW SQUARE WASHER SCREW - GROUNDING TOP FRAME T2 SCREW SIDE FRAME T2 SCREW BULB HOLDER SPACER THUMBSCREW...
  • Page 9 MODEL KM-500MWF TITLE INDEX DESCRIPTION CONTROL BOX COVER T2 SCREW FRONT PANEL DEFLECTOR GASKET (A) TOP PANEL GASKET INSULATION FRONT COVER SIDE PANEL (R) – BASE BARRIER – INSULATION T2 SCREW GASKET A. ICE CUBER ASSEMBLY MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER...
  • Page 10 KM-500MRF A. ICE CUBER ASSEMBLY J-0, J-1, K-0, L-0...
  • Page 11 MODEL KM-500MRF TITLE INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONTROL BOX ASSEMBLY T2 SCREW LABEL LOCATION EVAP. CASE BASE FT SCREW FRAME TRUSS HEAD SCREW TRUSS HEAD SCREW SQUARE WASHER SCREW - GROUNDING TOP FRAME T2 SCREW SIDE FRAME T2 SCREW BULB HOLDER SPACER THUMBSCREW...
  • Page 12 MODEL KM-500MRF INDEX DESCRIPTION FRONT PANEL DEFLECTOR GASKET (A) TOP PANEL GASKET INSULATION JUNCTION BOX COVER T2 SCREW BUSHING FRONT COVER SIDE PANEL (R) – BASE BARRIER – INSULATION T2 SCREW GASKET TITLE A. ICE CUBER ASSEMBLY MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER...

  • Page 13: Refrigeration Circuit

    KM-500MAF B. REFRIGERATION CIRCUIT J-0, J-1, K-0...
  • Page 14 KM-500MAF B. REFRIGERATION CIRCUIT L-0, L-1...
  • Page 15 M O D E L K M -500M A F IN D E X N O . D E S C R IP T IO N C O N D E N S E R T2 S C R E W S H R O U D T2 S C R E W B A R R IE R...
  • Page 16 M O D E L K M -500M A F IN D E X D E S C R IP T IO N N O . TR U S S H E A D S C R E W PR ESSU RE SW ITC H P R E S S U R E S W ITC H B R A C K E T T2 S C R E W...
  • Page 17 KM-500MAF TITLE MODEL INDEX DESCRIPTION INSULATION HOLDER T2 SCREW INSULATION TUBE INSULATION TUBE INSULATION TUBE WIRE SADDLE COPPER TUBE ACCESS VALVE BRACKET VALVE BODY COIL VALVE BOLT COPPER TUBE (E) HIGH SIDE - B. REFRIGERATION CIRCUIT MATERIAL PART REQUIRED NUMBER...
  • Page 18 KM-500MWF B. REFRIGERATION CIRCUIT J-0, J-1, K-0, L-0...
  • Page 19 M O D E L K M -500M W F IN D E X D E S C R IP T IO N N O . R E A R P A N E L T2 S C R E W C O M P R ESSO R M O T O R P R O C T E C T O R B O LT...
  • Page 20 M O D E L K M -50 0 M W F IN D E X D E S C R IP T IO N N O . C O P P E R T U B E (A ) - H IG H S ID E C O P P E R T U B E (B ) - H IG H S ID E...
  • Page 21 KM-500MWF TITLE MODEL INDEX DESCRIPTION INSULATION - THERMISTOR RUBBER INSULATION (A) RUBBER INSULATION (B) INSULATION HOLDER T2 SCREW INSULATION TUBE INSULATION TUBE INSULATION TUBE WIRE SADDLE COPPER TUBE – ACCESS VALVE B. REFRIGERATION CIRCUIT MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER PE FOAM...
  • Page 22 KM-500MRF B. REFRIGERATION CIRCUIT J-0, J-1, K-0, L-0...
  • Page 23 M O D E L K M -500M R F IN D E X D E S C R IP T IO N N O . R E A R P A N E L T2 S C R E W C O M P R ESSO R M O T O R P R O TE C TO R B O LT...
  • Page 24 MODEL KM-500MRF TITLE INDEX DESCRIPTION VALVE BRACKET T2 SCREW VALVE BODY COIL - VALVE BOLT TRUSS HEAD SCREW COPPER TUBE (A) - HIGH SIDE COPPER TUBE (B) - HIGH SIDE COPPER TUBE (D) - HIGH SIDE COPPER TUBE (E) - HIGH SIDE COPPER TUBE (F) - HIGH SIDE...
  • Page 25 MODEL KM-500MRF TITLE INDEX DESCRIPTION INSULATION - THERMISTOR INSULATION - THERMISTOR RUBBER INSULATION (A) RUBBER INSULATION (B) INSULATION HOLDER T2 SCREW INSULATION TUBE INSULATION TUBE INSULATION TUBE WIRE SADDLE CRANKCASE HEATER SILICONE HOSE T2 SCREW B. REFRIGERATION CIRCUIT MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER...

  • Page 26: Water Circuit

    KM-500MAF, MWF, MRF C. WATER CIRCUIT J-0, J-1, K-0, L-0, L-1...
  • Page 27 M O D E L K M -5 0 0 M A F , M W F , M R F IN D E X D E S C R IP T IO N N O . P U M P M O T O R A S S E M B L Y T R U S S H E A D S C R E W F L A T W A S H E R S P L IT L O C K W A S H E R...
  • Page 28 M O D E L K M -5 0 0 M A F , M W F , M R F IN D E X D E S C R IP T IO N “O ” R IN G C O N N E C T O R – F L O A T S W IT C H F L O A T S W IT C H T 2 S C R E W...
  • Page 29 KM-500MAF, MWF, MRF TITLE MODEL INDEX DESCRIPTION RUBBER HOSE (C) PLUG INSULATION (E) WATER SUPPLY TUBE C. WATER CIRCUIT MATERIAL PART OR MODEL NUMBER NUMBER 4A1551-03 EPDM 4A0176-01 PE FOAM 4A0392-01 2A0079-01 REQUIRED NUMBER K-0 L-0...

  • Page 30: Control Box Assembly

    KM-500MAF, MWF, MRF D. CONTROL BOX ASSEMBLY J-0, J-1, K-0, L-0, L-1...
  • Page 31 M O D E L K M -500M A F, M W F, M R F IN D E X D E S C R IP T IO N N O . C O N TR O L ASSEM BLY T2 S C R E W C O N TR O L B O X C A P A C ITO R...

  • Page 32: Label Location

    KM-500MAF E. LABEL LOCATION J-0, J-1, K-0, L-0, L-1...
  • Page 33 M O D E L IN D E X D E S C R IP T IO N N O . E M B LE M M O D E L N U M B E R LA B E L LA B E L –...
  • Page 34 KM-500MWF E. LABEL LOCATION J-0, J-1, K-0, L-0...
  • Page 35 MODEL KM-500MWF INDEX DESCRIPTION EMBLEM MODEL NUMBER LABEL LABEL – PENGUIN – HA (R) MAINTENANCE LABEL WIRING LABEL NAMEPLATE INSTRUCTION SHEET MANUAL LABEL TAG – WARNING: ELECTRICAL CONNECTION OPERATION LABEL – VALVE LABEL – R404A CAUTION LABEL (K) INSTRUCTION LABEL LABEL –...
  • Page 36 KM-500MRF E. LABEL LOCATION J-0, J-1, K-0, L-0...
  • Page 37 KM-500MRF TITLE MODEL INDEX DESCRIPTION EMBLEM MODEL NUMBER LABEL LABEL – PENGUIN – HA (R) MAINTENANCE LABEL WIRING LABEL NAMEPLATE INSTRUCTION SHEET MANUAL LABEL TAG – WARNING: ELECTRICAL CONNECTION OPERATION LABEL – VALVE LABEL – R404A CAUTION LABEL (K) INSTRUCTION LABEL LABEL –...

  • Page 38: Pump Motor Assembly

    KM-500MAF, MWF, MRF F. PUMP MOTOR ASSEMBLY J-0, J-1, K-0, L-0, L-1...
  • Page 39 MODEL KM-500MAF, MWF, MRF INDE DESCRIPTION PUMP MOTOR RETAINER MECHANICAL SEAL (B) “O” RING PLATE – PUMP PUMP GASKET IMPELLER PUMP HOUSING TRUSS HEAD SCREW PLUG HOUSING TITLE F. PUMP MOTOR ASSEMBLY MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER...

  • Page 40: Control Assembly

    KM-500MAF, MWF, MRF G. CONTROL ASSEMBLY J-0, J-1, K-0, L-0, L-1...
  • Page 41 MODEL KM-500MAF, MWF, MRF TITLE INDE DESCRIPTION CONTROL BOX (C) TOGGLE SWITCH THERMOSTAT TRUSS HEAD SCREW CONTROL LABEL G. CONTROL ASSEMBLY MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER 446559-01 7K63K6 443119-01 A30-3815-00 4A0824-01 7C31-0408 446542-01...
  • Page 42 KM-500MAF, MWF, MRF H. ACCESSORIES J-0, J-1, K-0, L-0, L-1...
  • Page 43 MODEL KM-500MAF, MWF, MRF TITLE INDEX DESCRIPTION INSTRUCTION MANUAL LABEL – FASTENER UNIVERSAL BRACE HEX HEAD BOLT TURSS HEAD SCREW PACKAGING PALLET WOOD BLOCK – B TRAY SIDE PROTECTOR CORNER POST WOOD BLOCK – C CORNER POST SIDE PROTECTOR CARTON H.
