Cisco Catalyst 2975 Getting Started Manual

Cisco systems catalyst 2975 switch getting started guide
Hide thumbs Also See for Catalyst 2975:
Table of Contents

Advertisement

Quick Links

G
S
ETTING
TARTED
Catalyst 2975 Switch Getting Started Guide
1
About this Guide
2
Unpacking the Switch
3
Running Express Setup
4
Managing the Switch
5
Planning Switch Stacks
6
Rack-Mounting
7
In Case of Difficulty
8
Obtaining Documentation and Submitting a Service Request
G
UIDE

Advertisement

Table of Contents
loading

Related Manuals for Cisco Catalyst 2975

Summary of Contents for Cisco Catalyst 2975

  • Page 1 ETTING TARTED UIDE Catalyst 2975 Switch Getting Started Guide About this Guide Unpacking the Switch Running Express Setup Managing the Switch Planning Switch Stacks Rack-Mounting In Case of Difficulty Obtaining Documentation and Submitting a Service Request...

  • Page 2: About This Guide

    Cisco.com. For translations of the warnings that appear in this publication, see the Regulatory Compliance and Safety Information for the Catalyst 2975 Switch on the documentation CD. The product warranty information is also included on the documentation CD.

  • Page 3: Running Express Setup

    Before running Express Setup, disable any pop-up blockers or proxy settings in your browser software and any wireless client running on your PC. During Express Setup, the switch acts as a DHCP server. If your PC has a static IP address, change your PC settings before you begin to temporarily use DHCP.
  • Page 4 IP information. The VLAN ID range is 1 to 1001. • In the IP Address field, enter the IP address of the switch. In the IP Subnet Mask field, click the drop-down arrow, and select an IP Subnet Mask.

  • Page 5: Refreshing The Pc Ip Address

    When you click Submit, the switch is configured and exits Express Setup mode. The PC displays a warning message and then tries to connect with the new switch IP address. If you configured the switch with an IP address that is in a different subnet from the PC, connectivity between the PC and the switch is lost.

  • Page 6: Managing The Switch

    Using the Device Manager The simplest way to manage the switch is by using the device manager in the switch memory. This web interface offers quick configuration and monitoring. You can access the device manager from anywhere in your network through a web browser.

  • Page 7: Other Management Options

    0.5-meter cable is supplied. If you need the 1-meter cable or the 3-meter cable, you can order it from your Cisco supplier. • Access to the switch rear panel and to the rear of the rack. If you do not have access to the rear panel, make sure that you cable the switches before you rack-mount them.

  • Page 8: Cabling Guidelines

    Cabling Guidelines These illustrations show the recommended switch stack configurations with redundant stack cabling connections for optimized stack bandwidth. For more configuration examples, see the hardware installation guide on Cisco.com. In this example, the stack uses the 0.5-meter stack cable to make redundant connections.

  • Page 9: Rack Mounting

    – • Confirm that you have access to the switch rear panel to connect the optional RPS 2300 or the RPS 675. If you do not have access to the rear panel, you should cable the switches before you rack-mount them.

  • Page 10: Installation Warning Statements

    Before Attaching the Brackets To install the switch in a rack, you must first remove the screws from the switch chassis so that the mounting brackets can be attached. For attachment at the front-mounting position remove one Phillips truss-head screw from the switch side panels. For attachment at the mid-mounting position, remove two screws.

  • Page 11: Attaching The Brackets

    Attaching the Brackets Use two number-8 Phillips flat-head screws to attach the long side of each bracket to the switch in one of three mounting positions. S TA C K CO NS OL S TA C K Front-mounting position Number-8 Phillips flat-head screws...

  • Page 12: Rack-Mount The Switch

    Rack-Mount the Switch Use the four number-12 Phillips machine screws to attach the brackets to the rack. Use the black Phillips machine screw to attach the cable guide to the left or right bracket. ST AC K CO NS OL...

  • Page 13: Connect To The Switch Ports

    Secure the screws tightly. Insert the other end of the cable into the connector of the other switch, and secure the screws tightly. Always use a Cisco-approved stack cable to connect the switches. Connect only Catalyst 2975 switches in a switch stack. The Catalyst 2975 switch does not support mixed stack configurations.

  • Page 14: In Case Of Difficulty

    Verify Port Connectivity After you connect a device to the switch port, the port LED turns amber while the switch establishes a link. This process takes about 30 seconds. Then the LED turns green when the switch and the attached device have an established link. If the LED is off, the device might not be turned on, there might be a cable problem, or there might be a problem with the adapter installed in the device.

  • Page 15: Resetting The Switch

    Resetting the Switch This section describes how to reset the switch by rerunning Express Setup. These are reasons why you might want to reset the switch: • You installed the switch in your network and cannot connect to it because you assigned an incorrect IP address.

  • Page 16: Obtaining Documentation And Submitting A Service Request

    Version 2.0. Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
