- Page 1 CLA-VAL D35 Communicating Valve Controller User Manual CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 1 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish...
-
Page 2: Table Of Contents
9.1 Installation Checkup ........................ 11 9.2 Simplified / Advanced Mode ....................12 CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 2 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... - Page 3 10.2 Non-Conformity Return (NCR) ....................29 Accessories ........................29 CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 3 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish...
-
Page 4: Introduction
Installation and electrical connection should be carried out in accordance with local regulations and only by qualified technicians! The protection level is guaranteed only if D35 has been installed by technicians instructed by CLA-VAL personnel and thereafter correctly maintained. During installation and maintenance, the inside of D35 must remain completely dry. Humidity may drastically shorten the life of the battery and electronics. -
Page 5: D35 Characteristics
Refer to the latest wiring diagram for the correct wiring! CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 5 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... -
Page 6: Sensor Mounting
Installation is not recommended below a value of -95 dBm. As the cellular network quality may fluctuate strongly across the site, it is recommended to test at different locations. If network quality at the installed location is not sufficient, it may be necessary to relocate the D35 or deport its antenna with adequate CLA-VAL extension cables. -
Page 7: Orientation In Space
Communicating Valve Controller ORIENTATION IN SPACE The D35 should be mounted in an upright position (antenna side up, cable gland down) to guarantee a good cellular connectivity. D35 may have difficulties transmitting when submerged (e.g. in a manhole after rainfall). To guarantee reliable transmission it is recommended to install it as high as possible. -
Page 8: Orientable Bracket Mounted Installation
5.3.4 STRANDARD INSTALLATION The standard installation of the D35 on the wall should be, as close as possible to the well opening, but not further than 1.5 m from the pressure sensor(s) connection(s) on the valve. The minimum signal strength is - 80 dBm for optimum data communication at the valve level. -
Page 9: Network Quality Between -80 Dbm And -95 Dbm
NETWORK QUALITY BETWEEN -80 dBm and -95 dBm If the signal quality at the valve level is between -80 dBm and -95 dBm, check if the D35 can be installed closer to the well opening, while maintaining a maximum distance of 1.5 m to the pressure sensors. If this is not possible, an antenna extension with optional CLA-VAL antenna extension cables might be necessary. -
Page 10: D35 Assembly
In "Standby" mode you can remove the SIM card or SD card, as well as connect or disconnect physical inputs. The "Acquisition" mode is the operating mode of the D35. In this mode, the device acquires the signals from the connected sensors and inputs and saves them to the internal memory. -
Page 11: Installation Validation
CLA-VAL D35 Communicating Valve Controller INSTALLATION VALIDATION The simplest and fastest way to verify the successful start of the product is to use the D35 LED. The LED flashes green every 10 seconds when in "Acquisition" mode. ACTIVATING D35 Once the following actions are performed ... -
Page 12: Simplified / Advanced Mode
Click on " Inputs" to display the input configuration page. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 12 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... - Page 13 When done, click "SAVE" to apply your changes. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 13 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish...
-
Page 14: Setting Up A Flowmeter
Choose the units in which the flow rate is displayed. Click "SAVE" to apply the changes. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 14 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... -
Page 15: Setting The Parameters Of A Solenoid Valve
When you exit the "Configuration" mode all outputs that have been forced are automatically released. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 15 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... -
Page 16: Event Setting
Click "SAVE" to apply the changes. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 16 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... -
Page 17: Valveflow™ Setting (Option)
To activate the operation of the ValvApps, check the "Enabled" box. Click on "SAVE". CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 17 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... -
Page 18: Import/Export
An action allows you to activate or deactivate a solenoid valve according to its configuration and conditions. You can create up to 4 actions. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 18 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... -
Page 19: Action " Configuration
Volume + Calendar Chapter 9.8.4 Chapter 9.8.4 Chapter 9.8.5 CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 19 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... - Page 20 When?: The list of days and months where the condition is valid. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 20 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish...
- Page 21 When?: The list of days and months where the condition is valid. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 21 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish...
-
Page 22: Custom Sim Card (Communication Option)
Click the "SAVE" button in the "SIM Card Settings" section to apply the configuration. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 22 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... -
Page 23: Checking The Quality Of The Network (Communication Option)
Check the dBm value by hovering over the network quality icon. CLA-VAL Europe www.cla-val.ch cla-val@cla-val.ch 23 - D35001UE - 08/22 © Copyright CLA-VAL Europe - Specifications subject to change without notice - no contractual illustrations. Reduce your waste - Sort your rubbish... -
Page 24: Register On Link2Valves (Communication Option)
Choose the transfer interval and the time from which the interval will start. This interval will determine the frequency of communications of the D35 and Link2Valves. Please note that a faster interval will have a negative impact on the battery life of the unit and generate potential additional costs. -
Page 25: Logging Setting
Associate the D35 unit with your Link2Valves user account. First, enter the email address of your Link2Valves account. If you do not have one, please contact CLA-VAL to get one for free. Then click on "REGISTER NOW" and wait for the message "Success! ". -
Page 26: Basic System Settings
Periodic synchronization is recommended. This operation can only be performed if the D35 is connected to the cellular network (option). If not, go directly to step 8. -
Page 27: Battery Control
Communicating Valve Controller Click on "SYNCHRONIZE NOW" to update your unit's clock immediately. This operation can only be performed if the D35 is connected to the cellular network (option). If not, go directly to step 8. Check that the time displayed on the clock below the navigation menu is correct. If not, you can set the time manually in "Manually set date and time". -
Page 28: Firmware Update
Click on the "UPLOAD FIRMWARE" button and wait a few minutes. Completely power off the D35 to apply the update. To do so, press the product button for 5 seconds to turn off the WiFi. Make sure the LED flashes green every 10 seconds, indicating that the product is in "Acquisition" mode Then press the main button for 10 seconds to completely switch off the D35 (a red flash appears after 10 seconds) ... -
Page 29: Support
D35 will flash purple for a few minutes. Do not disconnect the power during this time! Note: Before upgrading firmware on a D35, please check on the CLA-VAL website (https://cla-val.ch) for the latest version of the software & firmware. 10 SUPPORT 10.1 MAINTENANCE AND RETROFIT...
